| Ref | Part Number | Description |
|---|
| 1 |
137176X475 |
PANEL.CONTROL. Price: Call Us |
| 1 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 2 |
69-8890 |
CAP-SPINDLE Price: $13.32 |
| 2 |
72140512 |
BOLT Price: Call Us |
| 3 |
32151-10 |
RING-RETAINING Price: $0.81 |
| 3 |
73680500 |
SUB= 73690500 Price: Call Us |
| 4 |
19111116 |
WASHER Price: Call Us |
| 4 |
256-304 |
WASHER-THRUST Price: $3.94 |
| 5 |
2621J |
SUB= 154127 Price: Call Us |
| 5 |
69-6470 |
BUSHING-CASTOR Price: $5.82 |
| 6 |
82-9850-03 |
AXLE-REAR Price: $1,614.33 |
| 6 |
9266R |
SUB= 624A78 Price: Call Us |
| 7 |
74760524 |
BOLT.HEX.5/16-1.5 Price: Call Us |
| 7 |
93-0311-03 |
SPINDLE-WHEEL, LH Price: $378.60 |
| 8 |
3069J |
SUB= 164937 Price: Call Us |
| 9 |
117-8969 |
HUB ASM This part replaces 69-2960-03. Price: $336.24 |
| 9 |
8206H |
GRIP T Price: Call Us |
| 10 |
1685H |
SUB= 68478 Price: Call Us |
| 10 |
93-0310-03 |
SPINDLE-WHEEL, RH Price: $584.69 |
| 11 |
106-6895-03 |
BALL JOINT ASM Price: $258.08 |
| 11 |
3067J |
SUB= 100382K Price: Call Us |
| 12 |
3070J |
SPRING EXT TI Price: Call Us |
| 12 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 13 |
19121414 |
WASHER Price: Call Us |
| 13 |
23-7270 |
NUT-LUG Price: $10.37 |
| 14 |
136376 |
KNOB HANDLE Price: Call Us |
| 14 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 15 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 15 |
471J |
BOLT CT Price: Call Us |
| 16 |
10040500 |
LOCKWASHER Price: Call Us |
| 16 |
82-9210 |
SHAFT-PIVOT Price: $187.73 |
| 17 |
3220-7 |
NUT-JAM Price: $4.09 |
| 17 |
73220500 |
NUT.HEX.5/16-18 Price: Call Us |
| 18 |
93-0309 |
WASHER-TAB Price: $3.52 |
| 18 |
98000129 |
NUT Price: Call Us |
| 19 |
60-3670 |
PIN Price: $12.56 |
| 19 |
72140506 |
BOLT Price: Call Us |
| 20 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 20 |
9209R475 |
PANEL.HANDLE Price: Call Us |
| 21 |
58-6520 |
DECAL-GREASE Price: $2.57 |
| 21 |
72110510 |
BOLT Price: Call Us |
| 22 |
115-8014 |
CYLINDER-HYDRAULIC This part replaces 77-4800. Price: $1,015.97 |
| 22 |
2622J |
SUB= 159764 Price: Call Us |
| 23 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 24 |
48-6660 |
WASHER Price: $5.22 |
| 25 |
48-6640 |
BEARING Price: $10.04 |
| 28 |
32136-13 |
NUT-SHH Price: $2.85 |
| 30 |
69-9870 |
WIDE WHEEL AND 6-PLY TIRE ASM Price: $513.71 |
| 32 |
110-9719-03 |
TIE ROD ASM Price: $380.21 |
| 35 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 36 |
93-0307 |
NUT-LOCK, RETAINER Price: $3.36 |
| 37 |
340-54 |
ELBOW-45 DEG Price: $40.72 |
| 38 |
69-2980 |
SEAL Price: $33.94 |
| 39 |
254-106 |
CONE-BEARING, TAPERED Price: $19.51 |
| 43 |
254-92 |
CONE-BEARING, OUTER Price: $15.84 |
| 44 |
69-2970 |
CAP-HUB Price: $20.74 |
| 45 |
3210-7 |
SCREW-HH Price: $0.61 |
