| Ref | Part Number | Description |
|---|
| 1 |
121-1579-0P |
PLATE-FENDER, RH This part replaces 121-1579-03. Price: $69.27 |
| 1 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532184992. Price: $149.99 |
| 2 |
120-4113 |
FENDER-RH Price: $186.72 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
136-4358 |
NUT-COUPLING Price: $29.99 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532182493. Price: $17.99 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $6.99 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 15 |
87-6630 |
WASHER-PLAIN Price: $0.39 |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 17 |
120-4115 |
COVER-BATTERY Price: $105.88 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
121-1588 |
ROD-HINGE Price: $21.72 |
| 19 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 20 |
3274-31 |
SCREW-HSBH Price: $0.89 |
| 21 |
121-1586-0P |
MOUNT-COVER This part replaces 121-1586-03. Price: $43.43 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
127-3706 |
PLATE-COVER Price: $10.13 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 23 |
104-7201 |
NUT-HF Price: $0.69 |
| 24 |
3269-23 |
RIVET-POP Price: $0.25 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 26 |
127-3705 |
PLATE-COVER Price: $7.81 |
| 30 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 31 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 32 |
69-6260 |
MAGNET Price: $58.32 |
| 34 |
3255-7 |
WASHER-LOCK/EXT Price: $1.39 |
