| Ref | Part Number | Description |
|---|
| 1 |
20-4840 |
CLAMP-MUFFLER Price: $15.06 |
| 2 |
3217-6 |
NUT-HEX Price: $1.19 |
| 3 |
27-7160 |
DECAL-INSTALLATION Price: $19.89 |
| 4 |
108-3833 |
FILTER-AIR This part replaces 27-7110. Price: $26.73 |
| 5 |
27-7120 |
NUT AND GASKET ASM Price: $15.55 |
| 6 |
27-7140 |
SKIRT-BAFFLE Price: $85.92 |
| 7 |
27-7130 |
CLAMP ASM Price: $49.80 |
| 8 |
27-7150 |
A/C CUP ASM Price: $82.89 |
| 9 |
2412-3 |
CLAMP-HOSE Price: $3.49 |
| 10 |
95-1836 |
AIR CLEANER HOSE This part replaces 80-0060. Price: $43.61 |
| 11 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 12 |
80-3330 |
GASKET Price: $18.48 |
| 13 |
322-3 |
SCREW-HH Price: $0.79 |
| 14 |
32107-11 |
NUT-SQUARE Price: $0.22 |
| 15 |
27-7170 |
MOUNTING BAND ASM Price: $48.11 |
| 16 |
3258-19 |
SCREW Price: $0.42 |
| 17 |
27-7100 |
AIR CLEANER ASM Price: $323.10 |
| 18 |
43-3810-03 |
TUBE-CLEANER, AIR This part replaces 43-3810. Price: $89.59 |
| 19 |
83-9150 |
DECAL-FLUID, STARTING Price: $20.09 |
| 20 |
27-7180 |
CAP Price: $70.51 |
| 21 |
32128-20 |
NUT-HF Price: $0.99 |
| 501466901 |
501466901 |
SCREW Price: $7.99 |
| 501468601 |
507430749 |
SHUTTER-CHOKE This part replaces 501468601. Price: $2.99 |
| 501468701 |
501468701 |
SCREW Price: $6.99 |
| 501666101 |
501666101 |
FUEL INLET SCREEN Price: $12.99 |
| 501666201 |
501666201 |
COVER, PUMP SIDE Price: $5.99 |
| 501666701 |
501666701 |
THROTTLE STOP Price: $0.83 |
| 501666901 |
501666901 |
GASKET, PUMP SIDE Price: $14.99 |
| 501667001 |
501667001 |
GASKET, METERING SIDE Price: $6.99 |
| 501667201 |
502254701 |
PUMP DIAPHRAGM This part replaces 501667201. Price: $19.99 |
| 501667301 |
501667301 |
METERING DIAPHRAGM Price: $64.99 |
| 501667701 |
501667701 |
SPRING Price: $7.99 |
| 501667801 |
530035121 |
IDLE SCREW SPRING This part replaces 501667801. Price: $2.99 |
| 501668301 |
501668301 |
LEVER Price: $14.99 |
| 501876401 |
501876401 |
NEEDLE IDLE Price: $2.41 |
| 502254601 |
502254601 |
THROTTLE FLAP Price: $2.54 |
| 503108701 |
503584601 |
SCREW This part replaces 503108701. Price: $2.99 |
| 503176301 |
503176301 |
COVER METERING DIAPHR. Price: $4.99 |
| 503281019 |
503281019 |
CARBURETOR CPL HDA-98 WALBRO Price: $199.99 |
| 503520201 |
501876301 |
NEEDLE HIGH SPEED This part replaces 503520201. Price: $2.99 |
| 503562101 |
503562101 |
Choke Shaft Price: $3.68 |
| 503562401 |
503562401 |
SPRING Price: $6.99 |
| 503562501 |
537158101 |
SPRING This part replaces 503562501. Price: $9.99 |
| 503563401 |
503563401 |
INLET NEEDLE Price: $14.99 |
| 503614501 |
503614501 |
Price: $5.31 |
| 503614801 |
503614801 |
IDLE SPEED SCREW Price: $2.99 |
| 503625201 |
503625201 |
SCREW Price: $0.55 |
| 504210048 |
504210048 |
THROTTLE SPRING Price: $0.53 |
| 504350915 |
504350915 |
Nipple Price: $1.23 |
| 504860408 |
537158201 |
LEVER This part replaces 504860408. Price: $3.99 |
| 505316717 |
505316717 |
SCREW Price: $6.99 |
| 505520125 |
505520125 |
FULCRUM PIN Price: $6.99 |
| 530035015 |
530035015 |
SCREW SHUTTERS Price: $2.99 |
