| Ref | Part Number | Description |
|---|
| 1 |
5-2942 |
SHACKLE Price: $16.99 |
| 1 |
817060408 |
SCREW Price: $4.99 |
| 2 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 2 |
532132752 |
CONTROL.TH/CH.RH.BLK.FLG.26 Price: $19.99 |
| 3 |
47-3430-01 |
BRACKET-LIFT This part replaces 47-3430. Price: $159.43 |
| 4 |
596134201 |
Screws This part replaces 871070512. Price: $2.99 |
| 4 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 5 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 6 |
283-10 |
PIN-CLEVIS Price: $7.43 |
| 6 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED Price: $8.99 |
| 7 |
323-8 |
SCREW-HH Price: $1.20 |
| 7 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 8 |
47-3280-01 |
NO. 4 LIFT ARM ASM This part replaces 47-3280. Price: $1,463.33 |
| 9 |
3-4636 |
CHAIN Price: $22.51 |
| 9 |
734115441 |
WASHER - 26X6.5X1.6 This part replaces 819101216. Price: $0.99 |
| 10 |
3256-62 |
WASHER-FLAT Price: $0.75 |
| 10 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 11 |
23-2610-01 |
LINK ASM This part replaces 23-2610. Price: $211.99 |
| 12 |
3-0128 |
SHAFT Price: $75.98 |
| 12 |
532137437 |
MUFFLER.SINGLE.B&S.12HP Price: $199.99 |
| 13 |
5-1720 |
WASHER Price: $2.24 |
| 13 |
532101326 |
DEFL MUFFLER LTV Price: $4.01 |
| 14 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 14 |
532161464 |
SCREW.HEX.WS.HD.8-18 X 7/8 This part replaces 817030808. Price: $3.99 |
| 15 |
3211-4 |
SCREW-HH Price: $1.02 |
| 16 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 17 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 This part replaces 817490624. Price: $6.99 |
| 39 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 532128861. Price: $2.99 |
