| Ref | Part Number | Description |
|---|
| 1 |
532166627 |
STEERING WHEEL Price: $64.99 |
| 1 |
83-9350 |
ROD-ADJUSTING Price: $83.93 |
| 2 |
322-17 |
SCREW-HH Price: $2.62 |
| 2 |
532193542 |
AXLE.ASM.LT.CAST.LGHTWGHT This part replaces 532165854. Price: $119.99 |
| 3 |
32128-44 |
NUT Price: $2.69 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 4 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 5 |
61-3990-03 |
BRAKE-PARKING ASM This part replaces 61-3990. Price: $432.36 |
| 6 |
5-7290 |
SPRING-TENSION Price: $23.15 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
237-30 |
O-RING Price: $2.50 |
| 7 |
819272016 |
WASHER Price: $3.99 |
| 8 |
340-105 |
FITTING-ELBOW, 90 DEG Price: $39.67 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
237-80 |
O-RING Price: $6.10 |
| 10 |
3257-15 |
KEY-WOODRUFF Price: $11.84 |
| 10 |
532169832 |
DRAGLINK.15".TIRES Price: $64.99 |
| 11 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
3256-16 |
WASHER-FLAT Price: $0.39 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 13 |
83-9340 |
SHIELD-BRAKE, GRASS Price: $9.96 |
| 14 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 15 |
321-5 |
SCREW-HH Price: $0.22 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 16 |
70-9840 |
SHOE-BRAKE Price: $60.36 |
| 17 |
531166901 |
SERVICE KIT SHAFT ASM ST This part replaces 532156546. Price: $42.99 |
| 17 |
70-9880 |
SPRING-RETURN Price: $11.81 |
| 18 |
10-6821 |
BRAKE DRUM ASM Price: $170.90 |
| 18 |
532057079 |
THRUST WASHER Price: $1.99 |
| 19 |
10-6870-03 |
HUB-WHEEL This part replaces 10-6870. Price: $150.01 |
| 19 |
532160395 |
STEERING SHAFT SUPPORT Price: $8.99 |
| 20 |
119-3516 |
TIRE-TRACTION This part replaces 231-127. Price: $86.20 |
| 21 |
217-60 |
RIM Price: $110.16 |
| 22 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 22 |
532165857 |
SCREW.HX.WSH.HD Price: $3.99 |
| 23 |
26-3790 |
NUT-LOCK Price: $24.46 |
| 23 |
531154301 |
SERVICE.KIT SHAFT ASSY SHAFT A This part replaces 532165851. Price: $22.99 |
| 24 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 25 |
104-7708 |
BRAKE CAM & E-RING ASM This part replaces 70-9860. Price: $42.42 |
| 25 |
532154406 |
BRACKET STEERING Price: $6.99 |
| 26 |
85-6540 |
STUD-DRIVE Price: $7.41 |
| 27 |
532136874 |
GEAR.SECTOR Price: $69.99 |
| 27 |
70-9870 |
PLATE-BACKING Price: $183.14 |
| 28 |
325-11 |
SCREW-HH Price: $1.93 |
| 29 |
147-3595 |
BRACKET-BRAKE This part replaces 84-2000. Price: $8.08 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 30 |
99-4997 |
HYDRAULIC MOTOR KIT This part replaces 66-5291. Price: $2,061.97 |
| 31 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 32 |
532170162 |
ROD.ASM.TIE.BALL.JOINT.NOVAN Price: $79.99 |
| 32 |
84-1990 |
ROD-ADJUSTING Price: $17.37 |
| 33 |
3220-2 |
NUT-JAM Price: $0.50 |
| 34 |
282-2 |
YOKE Price: $30.04 |
| 35 |
104-7708 |
BRAKE CAM & E-RING ASM This part replaces 70-9850. Price: $42.42 |
| 36 |
532155106 |
KIT.BUSHING.STEERING This part replaces 532155099. Price: $8.99 |
| 36 |
83-9250 |
BRAKE LEVER WA(LOWER) Price: $70.31 |
| 37 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
532172092 |
INSERT.CAP.STRG.WH (3 2) (L B) This part replaces 532166626. Price: $12.99 |
| 39 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 39 |
819132411 |
Washer 13/32 x 1-1/20 x 11 Gauge Price: $2.99 |
| 40 |
83-9270 |
DISCONTINUED Price: Call Us |
| 40 |
873610600 |
NUT This part replaces 532124701. Price: $2.99 |
| 41 |
532159945 |
STEERING WHEEL ADAPTOR Price: $6.99 |
| 41 |
83-9330 |
SHAFT-BRAKE Price: $81.90 |
| 42 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 42 |
532145054 |
STEERING BOOT, GRAY This part replaces 532169634. Price: $11.99 |
| 43 |
340-17 |
FITTING-ELBOW, 90 DEG Price: $42.29 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 44 |
237-65 |
O-RING Price: $2.50 |
| 44 |
532153721 |
SHAFT EXT STEERING This part replaces 532153720. Price: $54.99 |
| 45 |
340-103 |
FITTING-HYD, 45 DEG Price: $36.92 |
| 46 |
237-78 |
O-RING Price: $3.85 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 47 |
237-21 |
O-RING Price: $0.70 |
| 47 |
532183226 |
FITTING.GREASE.TAPERED This part replaces 532124836. Price: $4.99 |
| 48 |
32128-20 |
NUT-HF Price: $0.99 |
| 49 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 50 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 51 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 54 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 62 |
584371701 |
KIT.STEER.ASM.P/L This part replaces 532167902. Price: $119.99 |
| 63 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $5.99 |
| 66 |
532154404 |
BEARING ARM Price: $3.99 |
| 67 |
872110618 |
BOLT CARRIAGE Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 79 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 80 |
874950612 |
BOLT.HX.NYLON3/8-16X Price: $4.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532169835. Price: $19.99 |
