| Ref | Part Number | Description |
|---|
| 1 |
532057079 |
THRUST WASHER Price: $1.99 |
| 1 |
99-6905-03 |
NO. 5 LIFT ARM ASM Price: $807.57 |
| 2 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 2 |
532124416 |
INSERT,STR WHEEL Price: $7.89 |
| 3 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 3 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 4 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 4 |
532100712 |
WASHER Price: $2.42 |
| 5 |
104-1438-03 |
STEP-PERFORATED Price: $33.53 |
| 5 |
532124415 |
STEERING WHEEL Price: $58.99 |
| 6 |
3296-51 |
NUT-LOCK, NI Price: $3.23 |
| 6 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532100711. Price: $7.99 |
| 7 |
328-7 |
SCREW-HH Price: $4.00 |
| 7 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 8 |
532165857 |
SCREW.HX.WSH.HD This part replaces 871070410. Price: $3.99 |
| 8 |
99-6941-03 |
PIVOT ROD ASM Price: $92.29 |
| 9 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 9 |
532004921 |
COTTER PIN Price: $4.99 |
| 10 |
532102670 |
SPRING GTV Price: $3.84 |
| 10 |
98-3929 |
SPRING-TORSION Price: $23.85 |
| 11 |
140-6431 |
PIVOT PIN ASM This part replaces 95-7158. Price: $37.92 |
| 12 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 12 |
873610600 |
NUT Price: $2.99 |
| 13 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 13 |
532124577 |
COVER.FRONT.WHEEL Price: $10.99 |
| 14 |
532121274 |
KNOB.DUCKHEAD.1/2 Price: $8.99 |
| 14 |
94-8946 |
WASHER-THRUST Price: $1.96 |
| 15 |
5-1096 |
CHAIN-LIFT Price: $18.82 |
| 15 |
532110845 |
ROD YTH Price: $8.99 |
| 16 |
282-4 |
SHACKLE Price: $32.98 |
| 16 |
532121631 |
SPRING TORSION Price: $2.42 |
| 17 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 17 |
532108196 |
BRKT CONTROL HYT NLA Price: $8.01 |
| 18 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 18 |
532156544 |
STEERING SHAFT This part replaces 532124043. Price: $64.99 |
| 19 |
256-287 |
BUSHING Price: $1.76 |
| 20 |
104-1413 |
CHAIN-LINK, STRAIGHT Price: $10.05 |
| 20 |
532160395 |
STEERING SHAFT SUPPORT This part replaces 532124035. Price: $8.99 |
| 21 |
104-0028 |
GUIDE-HOSE Price: $46.21 |
| 21 |
596582301 |
Washers This part replaces 532126684. Price: $2.99 |
| 22 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 22 |
531152201 |
SERVICE KIT BRACKET BRKT This part replaces 532124036. Price: $12.99 |
| 23 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 24 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 24 |
812000029 |
RING CLIP Price: $3.99 |
| 25 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 25 |
98-1880-03 |
KNUCKLE-PIVOT Price: $350.23 |
| 26 |
532156365 |
PITMAN SHAFT ASSY This part replaces 532124033. Price: $29.99 |
| 26 |
99-5610 |
PIN Price: $40.16 |
| 27 |
532108972 |
WASHER HYT Price: $2.38 |
| 27 |
98-7993 |
SCREW-HHF Price: $3.05 |
| 28 |
532136874 |
GEAR.SECTOR This part replaces 532124034. Price: $69.99 |
| 28 |
76-2980 |
WASHER-THRUST Price: $5.08 |
| 29 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 30 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 30 |
99-6913-03 |
DISCONTINUED Price: Call Us |
| 31 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 31 |
99-6904-03 |
ARM ASM #4 Price: $728.47 |
| 32 |
532108200 |
WASHER FRIC HYT Price: $2.38 |
| 32 |
98-7974 |
WASHER-THRUST Price: $37.96 |
| 33 |
106-9004 |
BUMPER This part replaces 99-5605. Price: $6.35 |
| 34 |
532108518 |
BOLT HYT Price: $3.52 |
| 34 |
99-6901-03 |
DISCONTINUED Price: Call Us |
| 35 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 35 |
819212016 |
WASHER D Price: $4.99 |
| 36 |
532108201 |
SPACER HYT NLA Price: $6.23 |
| 36 |
93-6693 |
DECAL-PLATE, FLOOR Price: $10.84 |
| 37 |
532121202 |
LINK CONTROL Price: $6.05 |
| 37 |
93-6686 |
DECAL-OIL, HYD Price: $7.01 |
| 38 |
323-6 |
SCREW-HH Price: $0.66 |
| 38 |
532108844 |
SPRING HYT Price: $6.16 |
| 39 |
32128-21 |
NUT-HF Price: $0.39 |
| 39 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 40 |
3256-57 |
WASHER-FLAT Price: $0.41 |
| 40 |
596564405 |
Bolts This part replaces 874760648. Price: $2.99 |
| 41 |
32144-26 |
SCREW-FLOW, TAPTITE Price: $5.75 |
| 41 |
532121209 |
ARM ASM PUMP Price: $16.19 |
| 42 |
532105663 |
SUPPORT-SADDLE LT NLA Price: $8.25 |
| 42 |
98-3936 |
LANYARD Price: $23.28 |
| 43 |
874761060 |
BOLT LT Price: $4.99 |
| 44 |
532105664 |
SUP-SADDLE FRT LT Price: $9.99 |
| 45 |
532130468 |
LINK.DRAG.SOL.BALL JT.20.064 This part replaces 532124032. Price: $64.99 |
| 46 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 47 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 48 |
532170162 |
ROD.ASM.TIE.BALL.JOINT.NOVAN This part replaces 532121334. Price: $79.99 |
| 49 |
873610500 |
This part replaces 873810500. Price: $2.15 |
| 50 |
532156483 |
SPINDLE ASM LH This part replaces 532105656. Price: $22.99 |
| 51 |
819272016 |
WASHER Price: $3.99 |
| 52 |
532155134 |
KIT-AXLE This part replaces 532110438. Price: $13.26 |
| 54 |
532003366 |
BEARING.STEERING.COLUMN Price: $3.99 |
| 55 |
583612401 |
LOCKNUT M This part replaces 873901000. Price: $2.99 |
| 56 |
532108075 |
AXLE ASSY T Price: $62.55 |
| 57 |
532130524 |
SPINDLE This part replaces 532105654. Price: $29.99 |
| 58 |
532000278 |
FITTING LT. Price: $5.99 |
| 59 |
532065139 |
VALVE STEM LT Price: $5.99 |
| 60 |
532059192 |
VALVE CAP Price: $4.99 |
| 61 |
532009040 |
BEARING.FLANGE Price: $6.99 |
| 62 |
532106732 |
RIM.ASM.6X4.5.FRONT.SILVER This part replaces 532124801. Price: $79.99 |
| 63 |
532122073 |
TIRE.15X6-6.TURF.SAVER.FRONT This part replaces 532106222. Price: $59.99 |
| 64 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 65 |
532108212 |
TRUNION HYT Price: $19.99 |
| 66 |
532121750 |
ROD ADJ CONTROL Price: $46.99 |
| 67 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 68 |
532059904 |
TUBE.5.3/4.5/6 Price: $19.99 |
| 72 |
532123186 |
BRACKET Price: $2.38 |
| 73 |
532183226 |
FITTING.GREASE.TAPERED This part replaces 532124836. Price: $4.99 |
| 74 |
532121748 |
WASHER Price: $3.99 |
| 77 |
532124037 |
GEAR.PINION Price: $4.99 |
| 78 |
532109816 |
NYLINER T (7283A) Price: $4.99 |
| 81 |
596134901 |
GSPH This part replaces 819131212. Price: $2.99 |
| 82 |
532121749 |
WASHER Price: $2.99 |
| 83 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 84 |
594976501 |
Washers This part replaces 819151516. Price: $2.99 |
| 85 |
532110739 |
WASHER T Price: $3.99 |
| 86 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 87 |
532121217 |
GUIDE CONTROL Price: $2.38 |
| 88 |
532121216 |
BRKT NLA Price: $2.38 |
| 90 |
817021008 |
SCREW Price: $3.99 |
| 91 |
819070816 |
Washer 7/32 x 1/2 x 16 Gauge Price: $5.99 |
| 94 |
532121204 |
BELLCRANK NLA Price: $5.46 |
| 95 |
532121206 |
BRKT BELLCRANK NLA Price: $2.38 |
