| Ref | Part Number | Description |
|---|
| 1 |
322-3 |
SCREW-HH Price: $0.79 |
| 1 |
74760524 |
BOLT.HEX.5/16-1.5 Price: Call Us |
| 2 |
32107-11 |
NUT-SQUARE Price: $0.22 |
| 2 |
74780652 |
BOLT HEX 3/8-16 Price: Call Us |
| 3 |
19131311 |
WASHER Price: Call Us |
| 3 |
27-7170 |
MOUNTING BAND ASM Price: $48.11 |
| 4 |
3258-19 |
SCREW Price: $0.42 |
| 5 |
27-7100 |
AIR CLEANER ASM Price: $323.10 |
| 5 |
73800600 |
NUT Price: Call Us |
| 6 |
20-4840 |
CLAMP-MUFFLER Price: $15.06 |
| 6 |
9056R550 |
SHIELD.PNT.TINE Price: Call Us |
| 7 |
1949J |
SUB= 1949J500 Price: Call Us |
| 7 |
43-3810-03 |
TUBE-CLEANER, AIR This part replaces 43-3810. Price: $89.59 |
| 8 |
1948J |
ENGINE BRKT LH TI Price: Call Us |
| 8 |
27-7180 |
CAP Price: $70.51 |
| 9 |
10040500 |
LOCKWASHER Price: Call Us |
| 9 |
82-5590 |
HOSE-CLEANER, AIR Price: $79.73 |
| 10 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 10 |
73220500 |
NUT.HEX.5/16-18 Price: Call Us |
| 11 |
3217-6 |
NUT-HEX Price: $1.19 |
| 11 |
74760544 |
SUB= 74780544 Price: Call Us |
| 12 |
151222 |
SUB= 165808 Price: Call Us |
| 12 |
27-7160 |
DECAL-INSTALLATION Price: $19.89 |
| 13 |
32128-20 |
NUT-HF Price: $0.99 |
| 14 |
108-3833 |
FILTER-AIR This part replaces 27-7110. Price: $26.73 |
| 14 |
9173R |
SPLIT SPACER RT Price: Call Us |
| 15 |
27-7120 |
NUT AND GASKET ASM Price: $15.55 |
| 15 |
73510500 |
NUT Price: Call Us |
| 16 |
19091412 |
WASHER Price: Call Us |
| 16 |
27-7140 |
SKIRT-BAFFLE Price: $85.92 |
| 17 |
19092016 |
WASHER Price: Call Us |
| 17 |
27-7130 |
CLAMP ASM Price: $49.80 |
| 18 |
10040400 |
LOCKWASHER Price: Call Us |
| 18 |
80-3330 |
GASKET Price: $18.48 |
| 19 |
27-7150 |
A/C CUP ASM Price: $82.89 |
