| Ref | Part Number | Description |
|---|
| 1 |
532439822 |
SEAT.TH150.MS498.GRY.HUSQ.TEX This part replaces 532406621. Price: $159.99 |
| 1 |
94-7422-03 |
PULLEY-PTO This part replaces 94-7422. Price: $249.24 |
| 2 |
323-18 |
SCREW-HH Price: $0.82 |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $11.99 |
| 3 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 3 |
532140675 |
STRAP Price: $5.99 |
| 4 |
29-4730 |
WASHER-FLAT Price: $13.10 |
| 5 |
63-6240 |
V-BELT Price: $54.64 |
| 6 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
139-7798-03 |
PTO SHAFT This part replaces 92-8855. Price: $527.02 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 10 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 10 |
596768801 |
KIT.PLATE.SEAT This part replaces 532196977. Price: $49.99 |
| 11 |
3230-4 |
BOLT-CARR Price: $0.47 |
| 12 |
92-8751-03 |
PTO BEARING BRACKET ASM This part replaces 92-8751. Price: $56.99 |
| 13 |
84-7580 |
PLATE-SUPPORT, BUSHING Price: $74.62 |
| 14 |
92-8799 |
BEARING-FLANGE Price: $126.15 |
| 15 |
32149-1 |
NUT-KEPS Price: $5.59 |
| 16 |
251-77 |
COLLAR-LOCK, BEARING Price: $10.22 |
| 17 |
3246-1 |
SCREW-SET Price: $6.24 |
| 18 |
302-40 |
FITTING-GREASE, 90 DEG Price: $1.70 |
| 19 |
63-8410 |
WASHER Price: $1.76 |
| 20 |
63-9750 |
MOUNT Price: $18.92 |
| 21 |
323-10 |
SCREW-HH Price: $0.89 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
3272-15 |
PIN-COTTER Price: $0.47 |
| 23 |
54-9090 |
YOKE-END Price: $202.33 |
| 24 |
54-9170 |
TUBE-SLIP YOKE Price: $364.94 |
| 25 |
302-58 |
FITTING-STRAIGHT Price: $0.81 |
| 26 |
54-9050 |
SHAFT-SLIP YOKE Price: $200.01 |
| 27 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 28 |
54-9040 |
YOKE-END Price: $246.14 |
| 29 |
32121-34 |
PIN-ROLL Price: $1.31 |
| 30 |
322-9 |
SCREW-HH Price: $3.09 |
| 31 |
54-9180 |
U-JOINT KIT Price: $58.18 |
| 32 |
322-14 |
SCREW-HH Price: $1.01 |
| 37 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 40 |
595088102 |
Handles This part replaces 532197661. Price: $4.99 |
| 41 |
532198200 |
SPRING.LATCH.SEAT.TEX Price: $3.99 |
| 43 |
874760612 |
BOLT Price: $3.99 |
