| Ref | Part Number | Description |
|---|
| a |
951-16207 |
CHOKE SHAFT Price: $8.00 |
| aa |
None |
Sheetmetal Housing |
| b |
951-16208 |
CHOKE RETURN SPRING Price: $6.88 |
| bb |
736-04638A |
LOCK WASHER This part replaces 736-04638. Price: $2.88 |
| c |
None |
Flat Steel Washer |
| cc |
None |
Screw M3×5 |
| d |
None |
Choke Plate |
| dd |
None |
Throttle Plate |
| e |
None |
Carburetor Body |
| ee |
None |
Throttle Shaft |
| f |
711-06036 |
HINGE FLOAT PIN This part replaces 711P06036. Price: $0.60 |
| ff |
None |
Idle Jet Assembly |
| g |
751P14036A |
NEEDLE VALVE Price: $5.16 |
| gg |
None |
Idle Jet Rivet |
| h |
732P05251A |
NEEDLE VALVE SPRING This part replaces 732P05021. Price: $1.70 |
| i |
None |
Float |
| j |
951-11970 |
FUEL BOWL GASKET Price: $5.95 |
| k |
None |
Square-Ring |
| l |
None |
Idle Mixture Screw |
| m |
736-04629 |
WASHER Price: $3.56 |
| n |
710-06098 |
Screw M3x5 Price: Call Us |
| o |
951-14972 |
CARBURETOR SOLENOID VALVE ASM Price: $40.38 |
| p |
None |
Solenoid Valve Washer |
| q |
951-12772 |
SEAT/FUEL BOWL BOLT O-RING Price: $3.63 |
| r |
None |
Fuel Bowl Bolt |
| s |
910-06752 |
DRAIN BOLT Price: $4.45 |
| t |
951-11349A |
FUEL DRAIN PLUG GASKET This part replaces 951-11349. Price: $3.66 |
| u |
751P16210 |
FUEL BOWL Price: $5.97 |
| v |
None |
Main Jet |
| w |
None |
Emulsion Tube |
| x |
None |
Idle Speed Adjusting Screw |
| y |
736P05037 |
FIBER WASHER Price: $0.12 |
| z |
None |
Nylon/Plastic O-Ring |
| 1 |
710-04968 |
BOLT M6 x 16 Price: $5.77 |
| 2 |
951-15654 |
VALVE COVER Price: $13.13 |
| 3 |
951-15655 |
ROCKER ARM ASSEMBLY Price: $10.52 |
| 4 |
951-15656 |
ROCKER ARM BASE Price: $5.25 |
| 5 |
951-14912A |
VALVE CAP This part replaces 951-14912. Price: $3.03 |
| 6 |
951-14911A |
VALVE SPRING SEAT This part replaces 951-14911. Price: $4.64 |
| 7 |
951-12078 |
VALVE SPRING Price: $3.49 |
| 8 |
951-11964A |
INTAKE VALVE SEAL This part replaces 951-11964. Price: $9.96 |
| 9 |
951-15923 |
INTAKE VALVE Price: $13.79 |
| 10 |
951-15924 |
EXHAUST VALVE Price: $24.13 |
| 11 |
710-06291 |
BOLT M10-1.25 x 70 Price: $4.31 |
| 12 |
751P17928 |
CYLINDER HEAD Price: $94.45 |
| 13 |
951-10292A |
SPARK PLUG (F6RTC/RN11YC/BPR6ES) This part replaces 951-10292. Price: $6.35 |
| 14 |
710-06615 |
STUD - M8 x 102 Price: $5.35 |
| 15 |
951-15658 |
EXHAUST GASKET Price: $6.66 |
| 16 |
951-15659 |
ENGINE SHROUD Price: $18.44 |
| 17 |
951-15660 |
MUFFLER Price: $78.84 |
| 18 |
951-15661 |
MUFFLER GUARD Price: $27.75 |
| 19 |
710-04916 |
BOLT M6-1 x 14 GR8.8 Price: $3.86 |
| 20 |
751-15427 |
NUT M8 Price: $3.64 |
| 21 |
710-04915 |
BOLT M6-1 x 12 GR8.8 Price: $3.82 |
| 22 |
951-15707 |
THERMAL SWITCH Price: $28.08 |
| 23 |
951-15708 |
THERMAL LEVER Price: $5.08 |
| 24 |
951-15709 |
AIRVANE CHOKE Price: $8.76 |
| 25 |
951-14734 |
PIVOT VANE STUD Price: $5.48 |
| 26 |
751P17930A |
INSULATOR This part replaces 751P17930. Price: $7.55 |
| 27 |
951-15711 |
O-RING 36 x 2.5 Price: $4.91 |
| 28 |
951-15712A |
INTAKE MANIFOLD This part replaces 951-15712. Price: $12.30 |
| 29 |
710-06292 |
BOLT M6 x 22 Price: $4.40 |
| 30 |
951-14947 |
INTAKE GASKET Price: $7.16 |
| 31 |
651P06415 |
CARBURETOR Price: $77.35 |
| 32 |
921-04745 |
AIR FLTER GASKET Price: $6.13 |
| 33 |
710-06319 |
STUD M6-1.00 x 92 Price: $5.48 |
| 34 |
951-15713 |
AIR FILTER BASE ASSEMBLY Price: $22.83 |
| 35 |
710-05234 |
SCREW M6-1:50:CL5. Price: $5.38 |
| 36 |
712-05015 |
HEX NUT Price: $5.78 |
| 37 |
937-05129A |
AIR FILTER W/PREFILTER This part replaces 937-05129. Price: $20.50 |
| 38 |
951-05557 |
AIR FILTER COVER ASSEMBLY Price: $19.11 |
| 39 |
951-15714 |
BUSHING - 11X6X30 Price: $4.19 |
| 40 |
721-04974 |
CARB FUEL DRAIN GASKET Price: $0.70 |
| 41 |
951-15715 |
CHOKE LEVER Price: $4.19 |
| 42 |
710-06447 |
SELF TAPPING SCREW 4.8 x 16 Price: $4.45 |
| 43 |
751P17931 |
CYLINDER HEAD GASKET Price: $3.59 |
| 44 |
715-04122 |
DOWEL PIN Price: $3.52 |
| 45 |
951-15717 |
PUSH ROD - INDIVIDUAL Price: $7.02 |
| 46 |
951-11962A |
TAPPET This part replaces 951-11962. Price: $5.88 |
| 47 |
951-05248 |
PISTON RING SET Price: $25.28 |
| 48 |
951-14905 |
PISTON Price: $48.83 |
| 49 |
911-06415 |
PISTON PIN Price: $8.96 |
| 50 |
951-11953A |
PISTON PIN SNAP RING This part replaces 951-11953. Price: $3.42 |
| 51 |
951-15775 |
CONNECTING ROD ASSEMBLY Price: $35.11 |
| 52 |
951-15720 |
WIRE ROD Price: $4.19 |
| 53 |
915-05026 |
DOWEL PIN Price: $4.40 |
| 54 |
710-06286 |
BOLT M8-1.25 x 80 Price: $4.40 |
| 56 |
951-05549A |
ELECTRIC STARTER This part replaces 951-05549. Price: $333.70 |
| 57 |
951-15721 |
HOOK Price: $4.88 |
| 58 |
925-06299 |
REGULATOR Price: $35.01 |
| 59 |
951-16206 |
IDLE SPRING Price: $5.15 |
| 60 |
712-04276A |
ACORN NUT M6-1 This part replaces 712-04276. Price: $5.38 |
| 61 |
736-05109 |
WASHER Price: $5.34 |
| 62 |
710-05305 |
HOOK BOLT Price: $3.56 |
| 63 |
751P17929 |
SHROUD Price: $8.45 |
| 64 |
710-05303 |
BOLT 5.5 x 25 Price: $3.56 |
| 65 |
751P17966 |
FLYWHEEL SCREEN Price: $5.06 |
| 66 |
751P17967A |
STUD M6x9 This part replaces 751P17967. Price: $2.53 |
| 67 |
912-05102 |
NUT M20 x 1.5 Price: $7.35 |
| 68 |
751P17968 |
FLYWHEEL Price: $106.72 |
| 69 |
710-06448 |
BOLT M5 x 28 Price: $3.32 |
| 70 |
951-15726 |
ALTERNATOR Price: $86.04 |
| 71 |
937-05134 |
OIL SEAL - 35X52X7 Price: $7.02 |
| 72 |
710-06290 |
BOLT M5-.8 x 10 Price: $4.31 |
| 73 |
951-15727 |
WIRE PLATE Price: $4.57 |
| 74 |
750-05314 |
BUSHING Price: $3.53 |
| 75 |
951-14922 |
BREATHER SCREEN Price: $4.31 |
| 76 |
751P17969 |
CRANKCASE Price: $194.83 |
| 77 |
710-04943 |
BOLT-M6-1 x 28 GR8.8 Price: $3.76 |
| 78 |
994-00136A |
IGNITION COIL This part replaces 994-00136. Price: $68.49 |
| 79 |
951-15729 |
BREATHER COVER Price: $8.76 |
| 80 |
951-15730 |
BREATHER COVER GASKET Price: $7.02 |
| 81 |
732-04718 |
BREATHER VALVE SPRING Price: $3.78 |
| 82 |
951-11614 |
BREATHER VALVE Price: $3.53 |
| 83 |
951-15731A |
DIPSTICK ASSEMBLY This part replaces 951-15731. Price: $17.52 |
| 84 |
921-04739 |
O-RING Price: $4.31 |
| 85 |
921-04946 |
O-RING Price: $3.50 |
| 86 |
951-15732 |
BREATHER HOSE Price: $15.78 |
| 87 |
951-15733 |
THROTTLE DAMPENING SPRING Price: $4.02 |
| 88 |
951-15734 |
THROTTLE LINKAGE Price: $5.78 |
| 89 |
951-15735 |
GOVERNOR GEAR SHAFT Price: $5.08 |
| 90 |
951-11902A |
OIL SEAL This part replaces 951-11574. Price: $3.36 |
| 91 |
714-04078 |
COTTER PIN Price: $3.66 |
| 92 |
951-15738 |
GOVERNOR SPRING Price: $8.76 |
| 93 |
951-15739 |
GOVERNOR ARM ASSEMBLY Price: $6.34 |
| 94 |
951-15740 |
CONTROL BRACKET ASSEMBLY Price: $12.96 |
| 95 |
951-11700A |
CARBURETOR HOSE CLAMP This part replaces 951-11700. Price: $3.60 |
| 96 |
993-00171 |
FUEL HOSE 6.3 x 12.5 x 250 Price: $8.12 |
| 97 |
723-04071A |
FUEL LINE SUPPORT CLAMP This part replaces 723-04071. Price: $2.77 |
| 98 |
951-14091 |
PLUG Price: $4.09 |
| 99 |
951-15741 |
CLIP Price: $3.50 |
| 100 |
951-15742 |
CRANKCASE GASKET Price: $15.78 |
| 101 |
715-04096A |
DOWEL PIN 9 X 14 This part replaces 715-04096. Price: $3.66 |
| 102 |
751P17970 |
CRANKSHAFT Price: $116.65 |
| 103 |
751P10307A |
WOODRUFF KEY This part replaces 951-10307. Price: $2.01 |
| 104 |
751P17971 |
BALANCE SHAFT Price: $26.54 |
| 105 |
936-05112 |
WASHER 17.2 x 26 x 1 Price: $4.40 |
| 106 |
951-15745 |
CAMSHAFT ASSEMBLY Price: $50.92 |
| 107 |
951-15746 |
GOVERNOR GEAR Price: $17.52 |
| 108 |
951-14895 |
PRESSURE RELEASE COVER Price: $4.69 |
| 109 |
932-05290 |
PRESSURE RELEASE SPRING Price: $4.40 |
| 110 |
951-15588 |
OIL PUMP STEEL BALL Price: $3.50 |
| 111 |
951-15747 |
CRANKCASE COVER Price: $158.05 |
| 112 |
951-12253 |
SCREW JOINT OIL FILTER ADAPTER Price: $6.87 |
| 113 |
951-15748 |
WASHER - 6.2X1.5X13 Price: $2.98 |
| 114 |
951-12690 |
ENGINE OIL FILTER Price: $15.89 |
| 115 |
951-05247 |
OIL PUMP ASSEMBLY Price: $51.44 |
| 116 |
921-04742 |
GASKET Price: $6.13 |
| 117 |
951-14896 |
OIL SEPARATOR Price: $4.69 |
| 118 |
710-05306 |
BOLT M8 x 40 Price: $3.56 |
| 119 |
951-11644 |
ENGINE PLUG 3/8 NPT Price: $8.96 |
| 120 |
937-05069 |
BREATHER FILTER SCREEN Price: $4.20 |
| 121 |
951-15749 |
OIL SCREEN PLATE Price: $4.34 |
| 122 |
951-15750 |
WASHER - 35.4X1X52 Price: $3.50 |
| 123 |
751P17972 |
LIFT HOOK Price: $1.94 |
| 124 |
751P17987 |
CLIP Price: $0.77 |
| 125 |
751P17986 |
FLYWHEEL HUB COVER Price: $3.77 |
| 126 |
710-06449 |
BOLT M5 x 18 Price: $3.56 |
| 127 |
751P17989 |
COOLING FAN Price: $7.29 |
| 128 |
710-04914 |
BOLT M6-1 x 10 GR8.8 Price: $3.71 |
| 129 |
710-04919 |
BOLT M6-1 x 25 GR8.8 Price: $3.86 |
