| Ref | Part Number | Description |
|---|
| 1 |
482624 |
Rod, Deck Lift Linkage Price: Call Us |
| 2 |
04020-28 |
Nut, Jam 1/2-20 LH Thread Price: Call Us |
| 3 |
481766 |
Rod End, 1/2-20 Female Thread Price: Call Us |
| 4 |
04050-10 |
Retaining Ring, 1/2" External "E" Price: Call Us |
| 5 |
483062 |
Slide, Deck Height Adjust Price: Call Us |
| 6 |
43487 |
Pin, Deck Lift Price: Call Us |
| 7 |
423463 |
Bracket, Cutting Height Adjustment Price: Call Us |
| 8 |
04001-22 |
Bolt, Hex Head 3/8-16 x 2-3/4" Price: Call Us |
| 9 |
43668 |
Bushing .502" OD Price: Call Us |
| 10 |
04021-09 |
Nut, Elastic Stop 3/8-16 Price: Call Us |
| 11 |
461874 |
Lever, Deck Latch Price: Call Us |
| 12 |
422346 |
Slide, Cutting Height Price: Call Us |
| 13 |
04014-03 |
Screw, Cap 5/16-18 x 3" FHHS Price: Call Us |
| 14 |
422381 |
Guide, Short Price: Call Us |
| 15 |
04003-04 |
Bolt, Carriage 5/16-18 x 1" Price: Call Us |
| 16 |
422380 |
Guide, Long Price: Call Us |
| 17 |
483177 |
Spring, Helper Price: Call Us |
| 18 |
04021-05 |
Nut, 3/8-16 Center Lock Price: Call Us |
| 19 |
04040-09 |
Flatwasher, 5/8-.656 x 1.312 x .095" Price: Call Us |
| 20 |
04019-04 |
Nut, 3/8-16 Serr. Flange Price: Call Us |
| 21 |
04001-32 |
Bolt, Hex Head 3/8-16 x 1-1/4", Kawasaki FX / FT & FT-EFI Price: Call Us |
| 22 |
43678 |
Swivel Joint LH Price: Call Us |
| 23 |
04061-07 |
Cotter Pin, 3/16 x 1" Price: Call Us |
| 24 |
04019-04 |
Nut, Serr. Flange 3/8-16 Price: Call Us |
| 25 |
04001-20 |
Bolt, Hex Head 3/8-16 x 1-1/2" B&S 32BV Price: Call Us |
| 26 |
04019-04 |
Nut, Serr. Flange 3/8-16 Price: Call Us |
| 27 |
04021-09 |
Nut, Elastic Stop 3/8-16 Price: Call Us |
| 28 |
48540 |
Chain Price: Call Us |
| 29 |
48114-04 |
Grease Fitting, 1/4-28 Self Tap Price: Call Us |
| 30 |
483181 |
Torsion Spring Price: Call Us |
| 31 |
461929 |
Lever Assy., Deck Level Price: Call Us |
| 32 |
04004-45 |
Stud, 1/2-13 x 20" Price: Call Us |
| 33 |
04067-09 |
Pin Price: Call Us |
| 33 |
481547 |
Lanyard Price: Call Us |
| 34 |
04020-07 |
Nut, 1/2-13 Price: Call Us |
| 35 |
43679 |
Swivel Joint RH Price: Call Us |
| 36 |
04001-155 |
Bolt, Hex Head 1/2-13 x 5" Price: Call Us |
| 37 |
481765 |
Rod End, 1/2-20 Female RH Thread Price: Call Us |
| 38 |
04001-77 |
Bolt, Hex Head 3/8-16 x 3-1/2" Price: Call Us |
| 39 |
43572 |
Spacer Price: Call Us |
| 40 |
04021-02 |
Locknut, 1/4-20 Price: Call Us |
| 41 |
43630 |
Spacer Price: Call Us |
| 42 |
04020-27 |
Nut, 1/2-20 UNF-2B Price: Call Us |
| 43 |
04021-10 |
Nut, Elastic Stop 5/16-18 Price: Call Us |
| 44 |
04041-14 |
Flatwasher, 1.0-1.062 x 1.5 x .048" Price: Call Us |
| 44 |
04050-08 |
Retaining Ring, 1" ext. Price: Call Us |
| 44 |
45904 |
Lift Bellcrank Weldment, LH Rear Price: Call Us |
| 44 |
45905 |
Lift Bellcrank Weldment, RH Rear Price: Call Us |
| 45 |
04062-04 |
Hair Pin Cotter, .177 x 3-1/4" Price: Call Us |
