| Ref | Part Number | Description |
|---|
| 1 |
130-2749-01 |
BRACKET-ROLLER Price: $178.42 |
| 1 |
952030249 |
Spark Plug (RCJ-6Y) Price: $3.99 |
| 1A |
631776A |
SHAFT & LEV This part replaces 631776. Price: $12.00 |
| 2 |
530015953 |
Screw Price: $1.99 |
| 2 |
631970 |
RET SPRING Price: $3.00 |
| 2 |
68-6710 |
ROLLER Price: $59.98 |
| 3 |
530055191 |
Insulator-Heat Price: $1.99 |
| 3 |
631778 |
SHUTTER Price: $1.20 |
| 3 |
68-6840 |
SHAFT-ROLLER Price: $64.07 |
| 4 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 4 |
530016387 |
Screw-Muffler-Internal Price: $1.99 |
| 4 |
650506 |
SCREW Price: $0.87 |
| 5 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 5 |
530015241 |
Screw Price: $1.99 |
| 5 |
630766 |
SPRING Price: $1.25 |
| 5A |
630738 |
SPRING Price: $1.25 |
| 6 |
32104-6 |
SCREW-HH, TAP Price: $3.19 |
| 6 |
651025 |
SCREW This part replaces 650417. Price: $1.18 |
| 7 |
3230-16 |
SCREW-CARR Price: $1.79 |
| 7 |
631779 |
SHAFT & LEV Price: $5.16 |
| 8 |
530071458 |
Gasket-Baffle (kit) Price: $5.99 |
| 8 |
631780B |
RET SPRING This part replaces 631780A. Price: $1.25 |
| 9 |
530071458 |
Gasket-Cylinder (kit) Price: $5.99 |
| 9 |
631753 |
SHUTTER Price: $1.25 |
| 10 |
530071457 |
Kit-Cylinder Price: $11.99 |
| 10 |
630748 |
WELCH PLUG Price: $1.17 |
| 11 |
530019182 |
Grommet-Ign. Module Price: $1.99 |
| 11 |
631027 |
WELCH PLUG Price: $1.17 |
| 12 |
530016357 |
Screw-Ignition Module Price: $1.99 |
| 12 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 13 |
530035505 |
Ignition Module Price: $29.99 |
| 13 |
631022 |
CLIP Price: $1.25 |
| 14 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 15 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 15 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 16 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 16 |
631867 |
FLOAT BOWL Price: $2.34 |
| 17 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 18 |
530071615 |
Kit-Crankcase Seal Price: $4.99 |
| 19 |
530055728 |
Bearing-Outer Price: $6.99 |
| 20 |
530015941 |
Retainer Ring-C'chaft Price: $1.99 |
| 20 |
631781 |
POWER SCREW Price: $9.57 |
| 21 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 21 |
530016190 |
Spacer-Flywheel Price: $2.99 |
| 22 |
530015149 |
Washer Price: $1.99 |
| 23 |
530047534 |
FLYWHEEL ASSY This part replaces 530039209. Price: $22.99 |
| 23A |
630740 |
O RING Price: $1.49 |
| 24 |
630898 |
ADJ SCREW Price: $1.69 |
| 25 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 26 |
530032125 |
Bearing-Inner Price: $11.99 |
| 26 |
632527 |
FUEL FITTING This part replaces 631775. Price: $6.03 |
| 27 |
530012452 |
Assy-Crankshaft Price: $24.99 |
| 27A |
630739 |
WASHER Price: $1.25 |
| 28 |
530071458 |
O-ring-C/case (kit) Price: $5.99 |
| 29 |
530012443 |
Cover-Crankcase Price: $5.99 |
| 30 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 31 |
530071459 |
Foam-219mm (kit) Price: $4.99 |
| 32 |
530029182 |
Eyelet-Flange Price: $1.99 |
| 33 |
530071467 |
Kit-Rope Price: $4.99 |
| 34 |
530054834 |
Handle-Starter Price: $1.99 |
| 35 |
530016326 |
Screw-Rope Price: $1.99 |
| 36 |
530016240 |
Washer-Belleville Price: $1.99 |
| 37 |
530626605 |
Nut Price: $1.99 |
| 38 |
530402043 |
Spring-Return Cover Price: $2.99 |
| 39 |
530049313 |
Inlet Door Price: $4.99 |
| 40 |
530016279 |
Washer-Flat Price: $1.99 |
| 41 |
530069817 |
Assy-Impeller Price: $12.99 |
| 42 |
530056625 |
Seal-Ring Price: $3.99 |
| 43 |
530016349 |
Screw Price: $1.99 |
| 44 |
530055101 |
Housing-Pulley Price: $6.99 |
| 45 |
545008011 |
KIT STARTER SPRING This part replaces 530042086. Price: $5.99 |
| 46 |
545150201 |
PULLEY STARTER This part replaces 530071466. Price: $8.99 |
| 47 |
530055102 |
Fan Housing Price: $14.99 |
| 48 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 49 |
530071459 |
Foam-182mm (kit) Price: $4.99 |
