| Ref | Part Number | Description |
|---|
| 1 |
120-8086 |
FRONT FRAME ASM Price: $5,122.88 |
| 2 |
120-8007-03 |
FRAME-REAR Price: $3,094.30 |
| 4 |
3234-38 |
SCREW-HHF Price: $3.33 |
| 5 |
104-5584-0P |
PLATE-REINFORCEMENT,ROPS This part replaces 104-5584-03. Price: $36.27 |
| 6 |
325-33 |
SCREW-HH Price: $11.49 |
| 7 |
32128-49 |
NUT-HHF Price: $1.04 |
| 8 |
104-5516-0P |
SUPPORT-TUBE This part replaces 104-5516-01. Price: $9.23 |
| 9 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 10 |
32128-20 |
NUT-HF Price: $0.99 |
| 11 |
119-0006 |
ACCESS PLATE ASM Price: $170.08 |
| 12 |
75-1410-01 |
PLATE-ACCESS, FLOOR Price: $142.43 |
| 13 |
125-4614 |
TREAD-FOOT, CENTER Price: $65.72 |
| 14 |
3234-7 |
SCREW-HHF Price: $1.99 |
| 17 |
106-6754 |
DECAL-DANGER Price: $9.57 |
| 19 |
127-6448 |
DECAL-DANGER, CE (21 DEG) Price: $8.44 |
| 21 |
136-2900 |
LH ROPS ASM Price: $586.28 |
| 22 |
136-2901 |
RH ROPS ASM Price: $586.28 |
| 23 |
136-2885 |
TOP TUBE ASM Price: $820.46 |
| 24 |
114-8419 |
SCREW-HHF Price: $4.17 |
| 25 |
136-2899 |
STANDOFF Price: $49.46 |
| 26 |
114-1925 |
BUMPER-RUBBER Price: $24.99 |
| 27 |
3234-36 |
SCREW-HHF Price: $0.75 |
| 28 |
136-2890 |
SPACER Price: $22.56 |
| 29 |
136-2893 |
WASHER-PLASTIC Price: $3.94 |
| 30 |
325-17 |
SCREW-HH Price: $2.90 |
| 31 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 32 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 33 |
136-2892 |
PIN ASM Price: $18.53 |
| 34 |
80-1890 |
SPACER Price: $9.06 |
| 35 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 36 |
116-4701 |
SCREW-HHF Price: $2.59 |
