TRANSMISSION 3
Parts (22)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 120-5118 | SHAFT-ADJUSTER Price: $44.64 |
| 1 | 506985803 | SPINDLE Price: $179.99 |
| 2 | 120-5116 | WASHER-WAVE Price: $9.17 |
| 2 | 738210504 | Ball Bearing 6005-2rs Price: $28.99 |
| 3 | 106-5344 | BUSHING-FLANGE, KEYED Price: $2.37 |
| 3 | 738211004 | BALL BEARING 6010 2RS1 Price: $39.99 |
| 4 | 108-0015 | WASHER-FLAT Price: $0.39 |
| 4 | 735314010 | CIRCLIP SGH 47 Price: $4.99 |
| 5 | 3296-33 | NUT-LOCK, NI Price: $2.39 |
| 5 | 735312600 | RETAINING RING SGA 25 Price: $2.99 |
| 6 | 137-6130 | SCREW-ADJUSTER, BEDBAR This part replaces 115-7039. Price: $25.42 |
| 6 | 506985901 | SHAFT Price: $44.99 |
| 7 | 119-4155 | WASHER-HARDENED Price: $4.16 |
| 7 | 735312600 | RETAINING RING SGA 25 Price: $2.99 |
| 8 | 120-5120 | SPRING-COMPRESSION Price: $2.89 |
| 8 | 506773401 | WASHER Price: $3.99 |
| 9 | 740681421 | V-RING Price: $3.99 |
| 10 | 535406001 | BRACKET Price: $299.99 |
| 11 | 506986102 | BUSHING Price: $14.99 |
| 40 | 725236651 | SCREW Price: $2.99 |
| 41 | 506889901 | DRAW RING Price: $17.99 |
| 42 | 725249371 | Screw M10x25 Price: $1.82 |
