| Ref | Part Number | Description |
|---|
| 1 |
214010 |
Gear Box Assembly Price: Call Us |
| 1 |
532138956 |
Decal, Operating Instruction (AYP part number) Price: $4.42 |
| 2 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 2 |
532127630 |
Decal, Grille Price: $3.33 |
| 3 |
3217-7 |
NUT-HEX Price: $0.28 |
| 3 |
532142788 |
Decal, Hood, RH Price: Call Us |
| 4 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 4 |
532142789 |
Decal, Hood, LH Price: Call Us |
| 5 |
3233-14 |
SCREW-CARR Price: $1.95 |
| 5 |
532142337 |
Decal, Insert Strg Whl (AYP part number) Price: $2.42 |
| 6 |
21-0500 |
DISCONTINUED Price: Call Us |
| 6 |
532137963 |
Decal, Scl Cold Start Hyd Price: Call Us |
| 7 |
21-3720 |
DISCONTINUED Price: Call Us |
| 7 |
532137259 |
Decal, Warning Multi-Language (AYP part number) Price: $8.99 |
| 8 |
27-0190 |
DISCONTINUED This part replaces 21-3710. Price: Call Us |
| 8 |
581578001 |
DECAL.PARKING.BRAKE.SADDLE.LT This part replaces 532140837. Price: $1.99 |
| 9 |
3296-45 |
NUT-HEX Price: $3.79 |
| 9 |
532133900 |
Decal, Fender (AYP part number) Price: $3.33 |
| 10 |
21-0770 |
DISCONTINUED X-REF Price: Call Us |
| 10 |
532133795 |
Decal, Caution (AYP part number) Price: $4.62 |
| 11 |
21-0860 |
DISCONTINUED Price: Call Us |
| 11 |
532101892 |
Decal, Clutch/Brake (AYP part number) Price: $6.60 |
| 12 |
23-2360 |
DISCONTINUED Price: Call Us |
| 12 |
532142342 |
Decal, D-Bar Ctrl. Mvt Hyd YT/GT (AYP part number) Price: $3.99 |
| 13 |
3231-28 |
SCREW-CARR Price: $1.92 |
| 14 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 14 |
532139346 |
Decal, V-Belt Schematic (AYP part number) Price: $2.38 |
| 15 |
5-2942 |
SHACKLE Price: $16.99 |
| 16 |
283-10 |
PIN-CLEVIS Price: $7.43 |
| 17 |
21-3770-01 |
LIFT STRAP-DECK, RIGHT REAR This part replaces 21-3770. Price: $15.29 |
| 18 |
21-0890 |
V-BELT Price: $32.90 |
| 19 |
3234-6 |
SCREW-HHF Price: $3.19 |
| 19 |
532121549 |
Decal, Battery (AYP part number) Price: $6.02 |
| 20 |
21-0640 |
WASHER-BELLEVILLE Price: $9.78 |
| 21 |
21-3990 |
PULLEY WA Price: $222.87 |
| 22 |
323-4 |
SCREW-HH Price: $1.02 |
| 23 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 24 |
21-3660 |
DISCONTINUED Price: Call Us |
| 25 |
21-0830 |
SPINDLE KEY Price: $0.98 |
| 26 |
251-257 |
BEARING-BALL Price: $13.99 |
| 27 |
23-2390 |
LH SPINDLE SHAFT Price: $165.08 |
| 28 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 29 |
26-7120 |
DISCONTINUED This part replaces 21-3960. Price: Call Us |
| 30 |
323-6 |
SCREW-HH Price: $0.66 |
| 31 |
21-0740 |
DISCONTINUED Price: Call Us |
| 32 |
21-0820 |
DISCONTINUED Price: Call Us |
| 33 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 34 |
3274-15 |
SCREW-HSH Price: $0.42 |
| 35 |
21-0790 |
SPINDLE END CAP Price: $165.77 |
| 36 |
23-2400 |
DISCONTINUED Price: Call Us |
| 37 |
23-2410-03 |
BLADE-HIGH SAIL, 25 INCH, LH This part replaces 23-2410. Price: $43.26 |
| 38 |
21-0930 |
SPECIAL WASHER Price: $9.30 |
| 39 |
125-1736 |
WASHER-BELLEVILLE This part replaces 22-8520. Price: $3.89 |
| 40 |
17-0980 |
NUT-SPECIAL Price: $9.99 |
| 41 |
302-51 |
ZERK Price: Call Us |
| 42 |
323-18 |
SCREW-HH Price: $0.82 |
| 43 |
21-0650 |
DISCONTINUED Price: Call Us |
| 44 |
23-2380 |
DISCONTINUED Price: Call Us |
| 45 |
253-133 |
SEAL-OIL Price: $21.11 |
| 46 |
3231-4 |
SCREW-CARR Price: $3.59 |
| 47 |
323-8 |
SCREW-HH Price: $1.20 |
| 48 |
21-3940 |
DISCONTINUED Price: Call Us |
| 49 |
3247-4 |
SCREW-SET Price: $0.54 |
| 50 |
21-0880 |
DISCONTINUED Price: Call Us |
| 51 |
68-8340 |
DECAL-TORQUE This part replaces 25-0440. Price: $19.99 |
