| Ref | Part Number | Description |
|---|
| 1 |
125-7245 |
INJECTION VALVE ASM Price: $501.48 |
| 1 |
532166627 |
STEERING WHEEL Price: $64.99 |
| 2 |
125-7133 |
NOZZLE ASM Price: $126.04 |
| 2 |
532193542 |
AXLE.ASM.LT.CAST.LGHTWGHT This part replaces 532184706. Price: $119.99 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 5 |
125-6901 |
NUT Price: $28.96 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
125-7245 |
INJECTION VALVE ASM This part replaces 125-7080. Price: $501.48 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
125-6902 |
SPRING Price: $3.26 |
| 10 |
125-6903 |
SEAT-SPRING Price: $2.99 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $59.99 |
| 11 |
125-6904 |
PLATE Price: $12.98 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
125-6905 |
PIN Price: $4.09 |
| 12 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 13 |
125-6939 |
SHIM SET Price: $90.29 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 17 |
532177883 |
SHAFT ASM STRG Price: $104.99 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 32 |
532171888 |
TIE ROD Price: $59.99 |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 34 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 35 |
873540500 |
NUT, CROWNLOCK Price: $3.99 |
| 36 |
532155108 |
KIT.BUSHING.STEERING. This part replaces 532155105. Price: $6.99 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
532172092 |
INSERT.CAP.STRG.WH (3 2) (L B) This part replaces 532166626. Price: $12.99 |
| 39 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 40 |
125-6964 |
SEAL Price: $30.15 |
| 40 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 41 |
125-6907 |
RETAINER Price: $18.02 |
| 41 |
532159945 |
STEERING WHEEL ADAPTOR Price: $6.99 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 44 |
125-7027 |
BOLT Price: $4.09 |
| 45 |
125-7097 |
RETAINER Price: $38.50 |
| 48 |
125-7027 |
BOLT Price: $4.09 |
| 50 |
125-7082 |
INJECTION PIPE ASM Price: $59.03 |
| 51 |
125-7083 |
INJECTION PIPE ASM Price: $59.03 |
| 52 |
125-7084 |
INJECTION PIPE ASM Price: $59.03 |
| 53 |
125-7085 |
INJECTION PIPE ASM Price: $67.79 |
| 54 |
125-6948 |
PIPE ASM Price: $14.32 |
| 55 |
125-6949 |
PIPE Price: $10.82 |
| 56 |
125-6970 |
CLIP Price: $4.09 |
| 57 |
125-6966 |
BOLT-JOINT, PIPE Price: $13.94 |
| 58 |
125-7081 |
PIPE ASM Price: $127.33 |
| 59 |
125-6967 |
GASKET Price: $10.09 |
| 60 |
125-6968 |
JOINT Price: $29.73 |
| 61 |
125-7174 |
WASHER-SEAL Price: $5.45 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE This part replaces 872140618. Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532169835. Price: $19.99 |
| 87 |
532173966 |
WASHER, FLAT .781 X 1 1/2" Price: $4.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
| 95 |
532188967 |
WASHER.HARDENED Price: $3.99 |
