| Ref | Part Number | Description |
|---|
| 1 |
N/A |
Engine |
| 2 |
722-0148 |
Mylar Foam Strip Price: Call Us |
| 3 |
710-0642 |
Hex Wash. Hd. Self-Tap Scr. 1/4-20 x .75" Lg. Price: $4.05 |
| 4 |
13590 |
BELT GUARD Not Available Price: |
| 5 |
712-0798 |
Hex Nut 3/8-16 Thd. Price: $3.86 |
| 6 |
736-0169 |
L-Wash. 3/8" Scr.* Price: $3.33 |
| 7 |
710-1260A |
Hex Wash. Hd. Scr. 5/16-18 x .75" This part replaces 710-0601. Price: $3.34 |
| 8 |
13554 |
PTO SUPPORT BRKT. Not Available Price: |
| 9 |
714-0101 |
Hairpin Cotter 1/2" Dia. Price: $4.13 |
| 10 |
736-0133 |
Fl-Wash. .38" I.D x 1.25 O.D. x .10 Thk. Price: $4.67 |
| 11 |
736-0169 |
L-Wash. 3/8" Scr. Price: $3.33 |
| 12 |
712-0798 |
Hex Nut 3/8-16 Thd. Price: $3.86 |
| 13 |
712-0798 |
Hex Nut 3/8-16 Thd.* Price: $3.86 |
| 14 |
736-0133 |
Fl-Wash. .38 I.D. x 1.25" O.D. x .10 Thk. Price: $4.67 |
| 15 |
13550 |
PTO IDLER ARM ASS'Y. Not Available Price: |
| 16 |
711-0598 |
ADAPTER-IDLER Not Available Price: |
| 17 |
748-0271 |
SPACER-PULLEY Not Available Price: |
| 19 |
736-0217 |
L-Wash. 3/8" Scr. H.D. Price: $3.86 |
| 20 |
710-3144 |
Hex Bolt 3/8-16 x 2" Lg. (Gr. 5) This part replaces 710-0427. Price: $4.02 |
| 21 |
736-0133 |
Fl-Wash. .38" I.D. x 1.25 O.D x .010 Thk. Price: $4.67 |
| 22 |
710-0859 |
Screws 3/8-16X2.5 This part replaces 710-0937. Price: $5.99 |
| 23 |
711-0306 |
Flat Idler Pulley Price: $101.31 |
| 25 |
716-0127 |
Snap Ring Price: $10.97 |
| 27 |
710-0859 |
Screws 3/8-16X2.5 This part replaces 710-0937. Price: $5.99 |
| 28 |
736-0133 |
Fl-Wash. .38" I.D. x 1.25" O.D. x .010 Price: $4.67 |
| 29 |
750-0374 |
SLEEVE Not Available Price: |
| 30 |
910-0224 |
HEX SCREW AB-TAP #10-16 x 0.500 This part replaces 710-0224. Price: $3.19 |
| 31 |
13546 |
CUP-PTO Not Available Price: |
| 32 |
13542 |
PTO BELT GUARD ASS'Y Not Available Price: |
| 33 |
710-1260A |
Hex Wash. Hd. Scr. 5/16-18 x .75" This part replaces 710-0601. Price: $3.34 |
| 34 |
714-0154 |
KEY-HI-PRO #91 Not Available Price: |
| 35 |
710-0528 |
Hex Scr. 5/16-18 x 1.25" Lg. Price: $3.90 |
| 36 |
712-3010 |
HEX NUT 5/16-18 This part replaces 712-0267. Price: $3.89 |
| 37 |
712-3010 |
HEX NUT 5/16-18 This part replaces 712-0267. Price: $3.89 |
| 38 |
936-0119 |
Lock Wash. 5/16" I.D. This part replaces 736-0119. Price: $4.29 |
| 39 |
13553 |
BRACKET-BEARING RETAINER Not Available Price: |
| 41 |
716-0127 |
Snap Ring Price: $10.97 |
| 42 |
710-0451 |
Carr. Bolt 5/16-18 x .75" Lg. Price: $3.53 |
| 43 |
738-0395 |
SPLINE SHAFT Not Available Price: |
| 45 |
710-0514 |
Hex Bolt 3/8-16 x 1" Lg. This part replaces 710-0253. Price: $3.78 |
| 46 |
736-0169 |
L-Wash. 3/8" Scr. Price: $3.33 |
| 47 |
710-0514 |
Hex Bolt 3/8-16 x 1" Lg. This part replaces 710-0253. Price: $3.78 |
| 48 |
736-0169 |
L-Wash. 3/8" Scr.* Price: $3.33 |
| 49 |
712-0798 |
Hex Nut 3/8-16 Thd.* Price: $3.86 |
| 50 |
710-0502A |
Hx Wash Hd. Scr. 3/8-16 x 1.25" This part replaces 710-0502. Price: $5.71 |
| 51 |
946-0341 |
PTO Control Cable This part replaces 746-0341. Price: $93.75 |
| 52 |
710-0599 |
Hex Wash. Hd. Self-Tap Scr. 1/4-20 x .501" Price: $3.86 |
| 53 |
747-0211 |
PTO HANDLE Not Available Price: |
| 54 |
931-0009A |
Shfter Knob This part replaces 720-0175. Price: $13.05 |
| 55 |
13587 |
LEVER ASSEMBLY Not Available Price: |
| 56 |
736-0288 |
FLAT WASHER Not Available Price: |
| 57 |
710-0599 |
Hex Wash. Hd. Self-Tap Scr. 1/4-20 x .50" Lg. Price: $3.86 |
| 58 |
751-0242 |
MUFFLER ASSEMBLY Not Available Price: |
| 59 |
717-0402 |
UNIVERSAL JOINT Not Available Price: |
| 60 |
736-0264 |
Fl-Wash. .312" I.D. x .630" O.D. x .063 Price: $5.99 |
| 61 |
712-3010 |
HEX NUT 5/16-18 This part replaces 712-0267. Price: $3.89 |
| 62 |
13722 |
Shroud Outer-R.H. Price: Call Us |
| 63 |
710-0599 |
Hex Wash. Hd. Self-Tap Scr. 1/4-20 x .50" Lg. Price: $3.86 |
| 65 |
914-0114 |
Sq. Key 1/4" x 1/4" x 2.00" Not Available This part replaces 714-0114. Price: |
| 66 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 67 |
910-0224 |
HEX SCREW AB-TAP #10-16 x 0.500 This part replaces 710-0224. Price: $3.19 |
| 68 |
13720 |
SHROUD-COV Not Available Price: |
| 69 |
710-0157 |
Hex Scr. 5/16-24 x .75" Lg. Price: $3.90 |
| 70 |
936-0119 |
Lock Wash. 5/16" I.D. This part replaces 736-0119. Price: $4.29 |
| 71 |
13723 |
BRACKET-SH Not Available Price: |
| 72 |
13719 |
SHROUD-COV Not Available Price: |
| 73 |
13721 |
Shroud Outer-L.H. Price: Call Us |
| 75 |
13714 |
Shroud Inner Ass'y.-L.H. Price: Call Us |
| 76 |
13717 |
Shroud Inner Ass'y.-R.H. Price: Call Us |
| 77 |
925-0771 |
Solenoid This part replaces 725-0771. Price: $32.55 |
| 78 |
910-0289 |
Hex Bolt 1/4-20 x .50" Lg. This part replaces 710-0289. Price: $3.15 |
| 79 |
753-0685 |
CIRCUIT BREAKER Not Available This part replaces 725-0459. Price: |
| 80 |
710-0351 |
Truss Mach. Scr. #10 x .50" Lg. Price: $3.90 |
| 82 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
