| Ref | Part Number | Description |
|---|
| 1 |
69-3620 |
DISCONTINUED Price: Call Us |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 2 |
69-3630 |
NUT Price: $39.01 |
| 3 |
69-3640 |
COVER-SERVO Price: $389.32 |
| 4 |
69-3710 |
GASKET-SERVO Price: $58.74 |
| 5 |
69-3610 |
NUT-HEX Price: $1.44 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
69-3600 |
NUT-HEX Price: $1.89 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 7 |
69-3590 |
RING-RETAINING Price: $4.15 |
| 8 |
69-3580 |
GUIDE-SPRING Price: $142.64 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 9 |
69-3130 |
PLUG Price: $62.97 |
| 12 |
69-3230 |
PIN-SPRING Price: $24.22 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 13 |
69-3370 |
BEARING-NEEDLE Price: $49.67 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 587016002. Price: $34.99 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 586840201. Price: $7.99 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 585029802. Price: $14.99 |
| 24 |
69-3250 |
SWASHPLATE-VARIABLE Price: $640.86 |
| 25 |
AU193488A1 |
JOURNAL This part replaces 69-3240. Price: $57.15 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 26 |
94-2878 |
PIN Price: $9.76 |
| 27 |
596933401 |
Washers This part replaces 819211616. Price: $2.99 |
| 27 |
76-4590 |
SCREW Price: $5.43 |
| 28 |
69-3220 |
SCREW Price: $15.55 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
69-3200 |
RING-RETAINING Price: $20.29 |
| 30 |
69-3190 |
SEAL-LIP Price: $94.91 |
| 31 |
69-3170 |
RING-RETAINING Price: $11.40 |
| 32 |
75-0460 |
BEARING-BALL This part replaces 69-3210. Price: $175.71 |
| 33 |
107-4354 |
COVER-FRONT This part replaces 76-4610. Price: $1,302.74 |
| 34 |
69-3500 |
BEARING-SLEEVE Price: $472.61 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 35 |
69-3510 |
PIN Price: $29.51 |
| 36 |
69-3470 |
PIN Price: $1.27 |
| 37 |
69-3180 |
DISCONTINUED Price: Call Us |
| 38 |
76-4600 |
GASKET-COVER, FRONT Price: $81.78 |
| 39 |
107-4379 |
CYLINDER BLOCK KIT This part replaces 69-3910. Price: $2,151.85 |
| 40 |
93-9320 |
PLATE-VALVE, LH Price: $466.03 |
| 41 |
69-3450 |
PIN Price: $3.33 |
| 42 |
69-3820 |
SLEEVE-VALVE, CONTROL Price: $569.45 |
| 43 |
28-3590 |
O-RING Price: $4.60 |
| 44 |
28-3580 |
RING-BACK UP Price: $20.88 |
| 45 |
587016401 |
WASHER.3/8ID.2-3/8OD.12GA.PLTD Price: $2.99 |
| 45 |
69-3880 |
SPRING-RETURN, NEUTRAL Price: $64.49 |
| 46 |
69-3830 |
SPOOL-VALVE, ROTARY Price: $291.51 |
| 47 |
25-2630 |
RING-BACK UP Price: $3.55 |
| 48 |
69-3890 |
BRACKET-RETURN, NEUTRAL Price: $60.82 |
| 49 |
69-3860 |
SCREW Price: $3.87 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 50 |
69-3870 |
HANDLE-VALVE, CONTROL Price: $60.69 |
| 51 |
107-4374 |
WASHER-LOCK This part replaces 69-3900. Price: $0.81 |
| 52 |
69-3840 |
O-RING Price: $1.58 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 53 |
69-3650 |
PISTON-SERVO Price: $852.55 |
| 54 |
69-3690 |
BEARING Price: $153.22 |
| 54 |
874760636 |
BOLT Price: $4.99 |
| 55 |
532414736 |
SPACER.BRACE.AXLE Price: $5.99 |
| 55 |
69-3560 |
O-RING Price: $7.18 |
| 56 |
69-3920 |
PISTON RING AND O-RING KIT This part replaces 69-3570. Price: $181.90 |
| 57 |
69-3720 |
COVER-SERVO Price: $406.84 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 58 |
69-3140 |
BRACKET Price: $30.30 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 60 |
69-3080 |
PLUG Price: $40.47 |
| 61 |
69-3150 |
SCREW Price: $2.17 |
| 62 |
69-3070 |
WASHER Price: $0.28 |
| 63 |
25-2630 |
RING-BACK UP Price: $3.55 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
237-22 |
O-RING Price: $2.43 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 65 |
532194734 |
BRACE.AXLE.FRONT.NLT/N Price: $37.99 |
| 65 |
69-3800 |
VALVE Price: $39.31 |
| 66 |
69-3810 |
VALVE-BY PASS Price: $148.67 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 67 |
69-3780 |
PLUG Price: $47.78 |
| 68 |
237-80 |
O-RING Price: $6.10 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 69 |
69-3770 |
SHIM Price: $51.82 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 585338801. Price: $14.99 |
| 70 |
69-3790 |
SPRING Price: $18.69 |
| 71 |
69-3760 |
PLUG-SPECIAL Price: $67.15 |
| 72 |
110-6342 |
SPRING This part replaces 69-3740. Price: $9.45 |
| 73 |
94-9413 |
SCREW Price: $18.13 |
| 74 |
94-9412 |
SEAL-ADAPTER, SUCTION Price: $129.88 |
| 75 |
587738906 |
KIT.SRVC.STEERINGSHAFT.PINION This part replaces 580683701. Price: $4.99 |
| 75 |
93-9321 |
PLUG ASM Price: $98.84 |
| 76 |
285-17 |
PLUG-PIPE Price: $2.59 |
| 76 |
580683601 |
SCREW HEAD SOCKET LRVB Price: $2.99 |
| 77 |
69-3750 |
O-RING Price: $3.33 |
| 78 |
532057079 |
THRUST WASHER Price: $1.99 |
| 78 |
69-3730 |
RELIEF VALVE KIT Price: $226.03 |
| 79 |
94-9414 |
ADAPTER-SUCTION Price: $211.04 |
| 80 |
69-3460 |
PLUG-EXPANSION Price: $76.84 |
| 81 |
69-3550 |
PIN Price: $3.66 |
| 83 |
69-3400 |
SCREW Price: $1.29 |
| 84 |
69-3430 |
KEY-WOODRUFF Price: $4.89 |
| 85 |
69-3410 |
ADAPTER-A, FLANGE Price: $516.81 |
| 86 |
69-3420 |
DISCONTINUED Price: Call Us |
| 87 |
69-3440 |
O-RING Price: $16.24 |
| 88 |
69-3540 |
COVER-GEROTOR Price: $538.45 |
| 89 |
69-3390 |
GEROTOR ASM Price: $542.68 |
| 90 |
69-3700 |
GUIDE-SPRING Price: $39.82 |
| 91 |
69-3660 |
SCREW Price: $95.73 |
| 92 |
69-3680 |
STOP Price: $65.27 |
| 93 |
69-3670 |
SPRING-SERVO Price: $194.02 |
| 95 |
92-1352 |
PLUG This part replaces 69-3120. Price: $30.00 |
| 122 |
583576601 |
CAP.GEAR.SECTOR.TEX This part replaces 532444962. Price: $4.99 |
