| Ref | Part Number | Description |
|---|
| 1 |
3231-10 |
SCREW-CARR Price: $1.22 |
| 2 |
32151-72 |
RING-RETAINING Price: $1.59 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 589818701. Price: $44.99 |
| 3 |
63-8410 |
WASHER Price: $1.76 |
| 4 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 5 |
130-6043 |
DECAL-SERVICE Price: $37.66 |
| 6 |
120-4195 |
TANK-FUEL Price: $630.36 |
| 7 |
2412-98 |
CLAMP-HOSE Price: $1.39 |
| 8 |
104-5228 |
FITTING-ELBOW, 90 DEG Price: $17.50 |
| 9 |
120-8908 |
PIPE-STAND Price: $26.42 |
| 9 |
596501502 |
Keepers This part replaces 501832602. Price: $9.99 |
| 10 |
46-6560 |
BUSHING Price: $2.94 |
| 11 |
587255001 |
CLUTCH. 5.0 PD. 2.5 OFFSET Price: $229.99 |
| 11 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 12 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 12 |
586899601 |
PULLEY.EXTENDED.SHAFT.GROUND Price: $29.99 |
| 13 |
32122-24 |
SCREW-PTH Price: $0.27 |
| 14 |
121-1688 |
GAUGE-FUEL Price: $197.80 |
| 15 |
121-1707 |
GASKET-FUEL, VITON Price: $22.66 |
| 15 |
529998404 |
FUEL TANK, 4GAL, 2.25"NECK, 20 This part replaces 532438018. Price: $199.99 |
| 16 |
125-9171 |
CAP-FUEL Price: $46.70 |
| 17 |
121-1514-03 |
BRACKET-LATCH, RH Price: $31.14 |
| 18 |
120-4190-0P |
TANK SUPPORT ASM [PRIMED] This part replaces 120-4190-03. Price: $263.49 |
| 18 |
585124801 |
CAP ASSY FUEL 3" GRAY Price: $17.99 |
| 19 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 20 |
120-4193-0P |
BRACKET-FUEL TANK This part replaces 120-4193-03. Price: $16.84 |
| 20 |
587631703 |
THROTTLE.KOHL.PRO.#88PAD_46" Price: $27.99 |
| 21 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 21 |
583533301 |
SCREW.#10X.750 (2 2) This part replaces 532438562. Price: $2.99 |
| 22 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 24 |
99-5414 |
STRAP-CLEANER, AIR Price: $48.46 |
| 25 |
104-3563 |
INDICATOR Price: $58.60 |
| 26 |
99-5410 |
AIR CLEANER ASM Price: $381.32 |
| 27 |
322-6 |
SCREW-HH Price: $0.45 |
| 28 |
32144-1 |
SCREW-TAPTITE Price: $3.19 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
121-1513-03 |
BRACKET-LATCH, LH Price: $31.14 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532186054 |
GASKET.EXHAUST.KOHL.CV18-CV26 Price: $5.99 |
| 70 |
583954501 |
PIPE.EXHAUST.LH.CV18/20 Price: $19.99 |
| 71 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 Price: $17.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 85 |
501606701 |
BOLT.HEX.7/16-20X5.GR5.GREEN Price: $7.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 116 |
539132624 |
KNOB - SHIFT Price: $6.99 |
