| Ref | Part Number | Description |
|---|
| 1 |
00200531 |
ASSY, WHEEL & TIRE - 16X6.5-8 Price: $102.45 |
| 2 |
06500926 |
NUT- WHEEL .50-20 ZCC This part replaces 00960526. Price: $1.45 |
| 4 |
D18311 |
MOTOR, HYDRAULIC WHEEL Price: $662.95 |
| 5 |
00150052 |
WSHR-FL-STL .750X1.250X.048 YZ Price: $4.45 |
| 6 |
00203842 |
ASSY, WHEEL HUB Price: $166.45 |
| 8 |
06300121 |
WSHR, LK-REG .438X.109 ZCC This part replaces 00960603. Price: $2.45 |
| 9 |
D14280 |
BOLT, 3/8-16 X 1 GR8 BLACK Price: $2.45 |
| 10 |
00960602 |
WASHER, .375 MED SPRG LOCK Y Price: Call Us |
| 12 |
06400914 |
WSHR-FL-STL .468X1.00X.125 YZ This part replaces 00960712. Price: $3.45 |
| 13 |
00964040 |
LOCKNUT, 1/4-20 WHIZ Y Price: Call Us |
| 15 |
05901701 |
BLT-HEX .31-18X1.00 G5 ZCC This part replaces 05946900. Price: $1.45 |
| 16 |
03885763 |
SHOE, BRAKE SYSTEM SCAMPER Price: Call Us |
| 17 |
06500820 |
NUT-NYL .31-18 G5 ZCC This part replaces 00967115. Price: $0.95 |
| 18 |
00135292 |
SPRING, EXT .375X.055X2.25 Y Price: $16.95 |
| 19 |
05901738 |
BLT, HEX .25-20X1.25 G5 ZCC This part replaces 05947400. Price: $1.95 |
