| Ref | Part Number | Description |
|---|
| 1 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 1 |
596040501 |
Hardware This part replaces 873510500. Price: $2.99 |
| 1 |
759-3300 |
ASSEMBLY-FIELD 5209-101-055 Not Available Price: |
| 2 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 2 |
759-3302 |
ROTOR ASSEMBLY 5209-10 Not Available Price: |
| 3 |
32152-10 |
LOCKNUT Price: $0.81 |
| 3 |
873220600 |
NUT.HEX.3/8-16UNC Price: $4.99 |
| 3 |
959-3303 |
ARMATURE ASSEMBLY Not Available This part replaces 759-3303. Price: |
| 4 |
532432508 |
KIT.BELT.GUARD.RT.TILLER This part replaces 532170127. Price: $37.99 |
| 4 |
70-2780 |
PISTON Price: $133.22 |
| 4 |
759-3305 |
PKG-BRAKE DRUM Not Available Price: |
| 5 |
532154734 |
SCREW, SHIFT LEVER Price: $2.66 |
| 5 |
759-3306 |
PKG-SPRING AND NUT 5208-101-017 Not Available Price: |
| 6 |
532110111 |
LEVER ASM CRT Price: $11.99 |
| 6 |
710-3030 |
SCREW 7/16-14X .750 GR5 Not Available Price: |
| 7 |
736-0171 |
Washer, Lock, 7/16 Price: $3.86 |
| 7 |
872110404 |
BOLT Price: $7.99 |
| 8 |
532008700 |
PANEL.INDICATOR.SHIFT.BLACK Price: $3.99 |
| 8 |
736-3086 |
WASHER-EXT LOCK .450X.750X.0 Not Available Price: |
| 9 |
726-3008 |
Clamp, Cable Price: $4.26 |
| 9 |
817021008 |
SCREW This part replaces 532086777. Price: $3.99 |
| 10 |
532009484 |
CONDUIT.CLIP.PLATED Price: $4.99 |
| 10 |
736-3017 |
Washer, Flat, .47 X 1.5 X .225 Thk Price: $10.08 |
| 10 |
98-7353 |
DISCONTINUED This part replaces 93-7990. Price: Call Us |
| 11 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 11 |
710-3029 |
Screw, Hex Cap, 7/16-20 X 1.25 Lg GR5 Price: $3.82 |
| 12 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $2.99 |
| 12 |
714-0119 |
Key, Square, 1/4 X .75 Lg Price: $7.27 |
| 12 |
75-2120 |
SHAFT W/CLEVIS Price: $252.67 |
| 13 |
711-3006 |
STUD 7/16-14 Not Available Price: |
| 13 |
823230506 |
SET SCREW Price: $2.99 |
| 13 |
93-7991 |
COLLAR Price: $73.29 |
| 14 |
532110652 |
SPACER CRT Price: $4.99 |
| 15 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
| 16 |
532145102 |
SHEAVE, TRANSMISSION Price: $59.99 |
| 19 |
812000028 |
RETAINING RING LT Price: $1.99 |
| 21 |
532156117 |
SPACER-SPLIT.327 X .42 Price: $4.99 |
| 22 |
874770508 |
BOLT Price: $2.99 |
| 23 |
532005015 |
TIRE.16X4-8.CHEVRON.TILLER Price: $99.99 |
| 23 |
532065139 |
VALVE STEM LT This part replaces 532124718. Price: $5.99 |
| 23 |
532128952 |
RIM ASM.2.75 X 8.00.WHITE This part replaces 532124366. Price: $89.99 |
| 24 |
532126875 |
RIVET,DRILLED Price: $2.99 |
| 25 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 26 |
532440438 |
GUARD.BELT.TILLER.ORANGE This part replaces 532166792. Price: $44.99 |
| 27 |
591372401 |
BELT.V.DR.RT TILLER This part replaces 532132801. Price: $14.99 |
| 28 |
532104679 |
PULLEY-IDLER TI Price: $14.99 |
| 29 |
812000032 |
KLIP RING Price: $3.99 |
| 30 |
584289401 |
BRACKET.IDLER.ASM.SHORT This part replaces 532159229. Price: $12.99 |
| 31 |
532102384 |
BOLT.FIN.HEX.3/8-16UNC Price: $7.99 |
| 32 |
532102141 |
SHIFT ARM CRT Price: $6.99 |
| 33 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 34 |
532102383 |
COUNTERWEIGHT.LH.CRT Price: $84.99 |
| 35 |
874760532 |
Bolt, Hex 5/16-18 x 2 Price: $2.99 |
| 36 |
532102331 |
BRACKET LH CRT Price: $11.99 |
| 37 |
532130812 |
RP.ENGINE PULLEY Price: $19.99 |
| 38 |
596218601 |
Bolts This part replaces 874760544. Price: $3.99 |
| 39 |
532140062 |
CAP.PLUNGER.BLACK Price: $4.99 |
| 40 |
532170488 |
SCREW.HEX.WSH.SLT.#10-24X.50 Price: $2.99 |
| 43 |
532069180 |
LOCKNUT Price: $2.99 |
| 44 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
