| Ref | Part Number | Description |
|---|
| 1 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 1 |
539111376 |
DECK W/DECALS 48" HUS Price: $3,299.99 |
| 2 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 2 |
539103295 |
IDLER BUSHING Price: $12.99 |
| 3 |
3-8514 |
WASHER-THRUST Price: $1.58 |
| 3 |
539101341 |
HCS 3/8C X 3 Price: $4.99 |
| 4 |
539103257 |
IDLER PULLEY Price: $49.99 |
| 4 |
69-8390 |
SPINDLE PULLEY ASSEMBLY Price: $162.41 |
| 5 |
253-154 |
SEAL-OIL Price: $5.48 |
| 6 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 6 |
71-2530 |
BEARING/SPACER KIT Price: $160.66 |
| 7 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 7 |
522023401 |
WASHER, 3/8 THICK Price: $2.99 |
| 8 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 8 |
69-1530 |
HOUSING-SPINDLE Price: $227.62 |
| 9 |
32128-21 |
NUT-HF Price: $0.39 |
| 9 |
539976941 |
HCS 3/8C X 1 1/4 GR5 Price: $3.99 |
| 10 |
138-6388 |
SHAFT-SPINDLE This part replaces 69-6760. Price: $189.44 |
| 10 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 11 |
138-6416 |
SPACER-SPINDLE, SHAFT This part replaces 69-6950. Price: $18.44 |
| 11 |
539103256 |
SPRING Price: $9.99 |
| 12 |
69-6920-03 |
BLADE-20 IN. This part replaces 69-6920. Price: $31.92 |
| 12 |
966956101 |
KIT HSG ASM 52/61 This part replaces 539131383. Price: $129.99 |
| 13 |
539990627 |
HCS 5/16C X 1 1/4 Price: $3.99 |
| 13 |
67-7561 |
CUP-SCALP, ANTI Price: $40.99 |
| 14 |
3253-8 |
WASHER-LOCK Price: $0.47 |
| 14 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 15 |
51-4060 |
SCREW-BLADE Price: $7.39 |
| 15 |
539100340 |
BLADE OEM 16 1/4" Price: $22.99 |
| 16 |
539103299 |
HCS 5/8F X 1 1/4 Price: $5.99 |
| 17 |
539990333 |
LOCKWASHER 5/8 Price: $2.99 |
| 18 |
539112141 |
PULLEY 42-48 Price: $37.99 |
| 19 |
598490501 |
Nuts This part replaces 539130653. Price: $7.99 |
| 20 |
539112120 |
HCS 7/16-20 GD 8 SPEC Price: $24.99 |
| 21 |
539111949 |
BELT, DECK 48" Price: $84.99 |
| 22 |
539990839 |
NUT 7/16C CENTERLOCK Price: $2.99 |
| 23 |
596029501 |
Pins This part replaces 539990365. Price: $2.99 |
| 24 |
596770301 |
Washers This part replaces 539103303. Price: $4.99 |
| 27 |
539111812 |
DECAL, TUNNEL RAM 6" Price: $11.99 |
| 28 |
505256501 |
SWIVEL, DECK HEIGHT ADJ Price: $14.99 |
| 29 |
539114404 |
SPACER Price: $6.99 |
| 30 |
539119227 |
BOLT, EYE Price: $14.99 |
| 31 |
539114698 |
EYEBOLT, 1/2-13 X 5.88 Price: $22.99 |
| 32 |
595316401 |
Washers This part replaces 539109554. Price: $2.99 |
| 33 |
596438501 |
Bolts This part replaces 539108073. Price: $2.99 |
| 34 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 35 |
539115550 |
WASHER-.533IDX1.37OD Price: $3.99 |
| 36 |
510254502 |
SHIELD DUST This part replaces 510254501. Price: $3.99 |
| 37 |
539108450 |
TOP DUST CAP Price: $4.99 |
| 38 |
596917301 |
Washers This part replaces 539111897. Price: $4.99 |
| 39 |
532133957 |
WHEEL GAGE DONUT This part replaces 539107610. Price: $11.99 |
| 40 |
539108366 |
HCS 1/2-13 X 4 GR 5 ZD Price: $5.99 |
| 41 |
539990258 |
NUT HEX 1/2 Price: $3.99 |
| 42 |
539130778 |
CHUTE, RUBBER DISCHARGE 42/48" Price: $64.99 |
| 43 |
539130923 |
PIVOT BRACKET - RUBBER CHUTE Price: $37.99 |
| 44 |
539130925 |
BRACKET, REINF-CHUTE Price: $139.99 |
| 45 |
539131813 |
PIN, CHUTE PIVOT Price: $6.99 |
| 46 |
596030801 |
Bolts This part replaces 539102933. Price: $3.99 |
| 47 |
596671401 |
Bolts This part replaces 539100472. Price: $3.99 |
| 48 |
539130391 |
ARM-IDLER W/BRG Price: $37.99 |
| 49 |
596581801 |
Bolts This part replaces 539130235. Price: $2.99 |
| 50 |
539107042 |
HCS 3/8-16 X 1-1/2 Price: $2.99 |
| 51 |
596433501 |
NUT NUT.3/8-16.HEX.JAM.Z 3/8-1 This part replaces 539109332. Price: $2.99 |
| 52 |
539130242 |
BUSHING, IDLER Price: $2.99 |
| 53 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 539990122. Price: $2.99 |
| 54 |
539114823 |
CAP, VINYL Price: $2.99 |
| 55 |
510206301 |
PIVOT, BEARING Price: $3.99 |
| 56 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 57 |
539108449 |
BOTTOM DUST CAP Price: $3.99 |
| 58 |
539108754 |
SHAFT SEAL Price: $6.99 |
| 59 |
539977326 |
PLUG-VENTED Price: $8.99 |
