| Ref | Part Number | Description |
|---|
| a |
None |
Choke Lever |
| b |
None |
Choke Shaft |
| c |
None |
Choke Plate |
| d |
None |
Carburetor Body |
| e |
None |
Float Pin |
| f |
None |
Needle Valve |
| h |
None |
Float |
| i |
951-11589 |
FUEL BOWL O-RING Price: $6.04 |
| j |
None |
Float Bowl |
| k |
951-11348A |
FUEL BOWL GASKET This part replaces 951-11348. Price: $5.07 |
| l |
710-04945 |
BOLT M8-1 x 10 Price: $3.66 |
| m |
None |
Throttle Shaft |
| n |
None |
Screw, M3×6 |
| o |
None |
Washer |
| p |
None |
Throttle Plate |
| q |
None |
Gasket |
| r |
None |
Idle Jet |
| s |
None |
Idle Adjusting Screw |
| t |
None |
Mixture Screw |
| u |
None |
Nozzle Tube |
| v |
None |
Main Jet |
| w |
951-11349A |
FUEL DRAIN PLUG GASKET This part replaces 951-11349. Price: $3.66 |
| 1 |
710-04968 |
BOLT M6 x 16 Price: $5.77 |
| 2 |
951-11054B |
VALVE COVER Price: $13.54 |
| 3 |
951-15045 |
BREATHER HOSE Price: $5.68 |
| 4 |
751P11565B |
VALVE COVER GASKET Price: $8.97 |
| 6 |
951-15139 |
ROCKER ARM BASE Price: $5.70 |
| 7 |
951-12000 |
INTAKE VALVE SPRING RETAINER Price: $3.53 |
| 8 |
751P12002A |
EXHAUST VALVE ADJUSTER This part replaces 951-12002. Price: $2.36 |
| 9 |
951-12003 |
EXHAUST VALVE SPRING RETAINER Price: $3.53 |
| 10 |
751P12004A |
VALVE SPRING This part replaces 951-12004. Price: $1.74 |
| 11 |
951-11894 |
INTAKE VALVE SEAL Price: $9.48 |
| 12 |
710-06080 |
BOLT-M8-1.25 x 60 GR10.9 Price: $5.45 |
| 13 |
951-10292A |
SPARK PLUG (F6RTC/RN11YC/BPR6ES) This part replaces 951-10292. Price: $6.35 |
| 14 |
712-04214 |
NUT Price: $3.86 |
| 15 |
751P18511 |
MUFFLER Price: $46.09 |
| 16 |
751P18508 |
MUFFLER SHIELD Price: $15.77 |
| 17 |
751P18509 |
INNER MUFFLER SHIELD Price: $12.88 |
| 18 |
751P18510 |
MUFFLER BODY Price: $30.71 |
| 19 |
751P11289A |
MUFFLER GASKET This part replaces 951-11289. Price: $1.96 |
| 20 |
710-04911 |
STUD M8 x 36 Price: $3.65 |
| 21 |
710-04915 |
BOLT M6-1 x 12 GR8.8 Price: $3.82 |
| 22 |
951-11113 |
AIR SHIELD Price: $8.11 |
| 23 |
710-05101 |
STUD M6-1 x 110 GR8.8 Price: $3.71 |
| 24 |
751P11567B |
CARBURETOR INSULATOR GASKET Price: $1.73 |
| 25 |
751P11568A |
INSULATOR This part replaces 951-11568. Price: $3.05 |
| 26 |
751P12005B |
CARBURETOR GASKET This part replaces 751P12005A. Price: $4.89 |
| 27 |
751-18653 |
Carburetor Price: Call Us |
| 28 |
951-11571 |
CARBURETOR GASKET PLATE Price: $4.83 |
| 30 |
951-12136 |
AIR CLEANER COVER Price: $16.91 |
| 31 |
951-10794 |
AIR CLEANER WITH PRE-FILTER Price: $13.66 |
| 32 |
751P14261 |
PRE AIR FILTER Price: $1.87 |
| 33 |
751-18467 |
AIR BASE Price: Call Us |
| 34 |
710-06585 |
SCREW M4x20 Price: $3.83 |
| 35 |
951-14315 |
AIR CLEANER HOUSING Price: $27.18 |
| 36 |
712-04213 |
NUT Price: $5.94 |
| 37 |
951-14312 |
CYLINDER HEAD Price: $103.42 |
| 38 |
951-14316 |
CYLINDER HEAD GASKET Price: $10.46 |
| 39 |
715-04108 |
DOWEL PIN Price: $3.65 |
| 40 |
751P14100A |
EXHAUST VALVE This part replaces 951-14100. Price: $3.43 |
| 41 |
751P14099A |
INTAKE VALVE This part replaces 951-14099. Price: $3.53 |
| 42 |
751P14105A |
PUSH ROD This part replaces 951-14105. Price: $2.40 |
| 43 |
951-11899 |
TAPPET Price: $7.14 |
| 44 |
951-14317A |
PISTON RING SET This part replaces 951-14317. Price: $23.87 |
| 45 |
951-11632 |
PISTON PIN SNAP RING Price: $3.53 |
| 46 |
951-15052 |
PISTON Price: $36.19 |
| 47 |
951-11633 |
PISTON PIN Price: $6.66 |
| 48 |
751P11573A |
CONNECTING ROD This part replaces 951-11573. Price: $8.87 |
| 49 |
710-04932 |
BOLT M8-1.25 x 32 GR5.8 Price: $3.66 |
| 50 |
951-11578 |
OIL SEAL 25 x 41.25 x 6 Price: $13.04 |
| 51 |
931-09966A |
OIL PLUG This part replaces 931-09966. Price: $4.81 |
| 52 |
951-11577 |
O-RING 15.8 x 2.5 Price: $3.53 |
| 53 |
751P17706 |
CRANKCASE COVER This part replaces 951-12125. Price: $29.04 |
| 54 |
751P11371B |
CRANKCASE GASKET This part replaces 951-11371A. Price: $3.07 |
| 55 |
715-04096A |
DOWEL PIN 9 X 14 This part replaces 715-04096. Price: $3.66 |
| 56 |
951-11369 |
BEARING Price: $30.42 |
| 57 |
751P18547 |
CRANKSHAFT Price: $58.61 |
| 58 |
751P10307A |
WOODRUFF KEY This part replaces 951-10307. Price: $2.01 |
| 59 |
951-15128 |
CAMSHAFT Price: $42.97 |
| 60 |
951-05020C |
DIPSTICK ASSEMBLY This part replaces 951-05020A. Price: $13.22 |
| 61 |
921-04663A |
O-RING This part replaces 921-04663. Price: $5.05 |
| 62 |
951-12397 |
OIL FILL TUBE O-RING Price: $4.39 |
| 63 |
715-04096A |
DOWEL PIN 9 X 14 This part replaces 715-04096. Price: $3.66 |
| 64 |
751P11576A |
GOVERNOR GEAR This part replaces 951-11576. Price: $3.00 |
| 65 |
710-05103 |
BOLT M6-1 x 12 GR8.8 Price: $3.52 |
| 66 |
951-14776 |
GOVENOR GEAR BRACKET Price: $13.79 |
| 67 |
951-11067 |
THROTTLE KNOB Price: $3.38 |
| 68 |
710-04905 |
BOLT M6-1 x 67 Price: $3.86 |
| 69 |
951-11914 |
ENGINE/DIPSTICK COVER Price: $13.09 |
| 70 |
951-10917B |
FUEL CAP This part replaces 951-10917A. Price: $14.56 |
| 71 |
651-05261 |
Fuel Tank Price: Call Us |
| 72 |
951-14965 |
FUEL INLET NIPPLE Price: $9.02 |
| 73 |
951-11700A |
CARBURETOR HOSE CLAMP This part replaces 951-11700. Price: $3.60 |
| 74 |
951-14123 |
FUEL HOSE (6.3x12.5x123MM) Price: $18.95 |
| 75 |
951-14089 |
GOVERNOR LEVER Price: $6.67 |
| 76 |
712-05015 |
HEX NUT Price: $5.78 |
| 77 |
951-11585 |
GOVERNOR SPRING Price: $6.50 |
| 78 |
751P10664A |
THROTTLE SPRING This part replaces 951-10664. Price: $2.01 |
| 79 |
751P10665A |
THROTTLE LINKAGE This part replaces 951-10665. Price: $1.53 |
| 80 |
714-04078 |
COTTER PIN Price: $3.66 |
| 81 |
951-11902A |
OIL SEAL This part replaces 951-11902. Price: $3.36 |
| 82 |
736-04461 |
O-RING Price: $3.50 |
| 83 |
951-14053 |
GOVERNOR SHAFT Price: $13.94 |
| 84 |
710-07374 |
OIL DRAIN PLUG Price: $3.00 |
| 85 |
951-14119 |
CRANKCASE Price: $155.25 |
| 86 |
951-12126 |
OIL SEAL-25 x 41.25 x 6 Price: $12.42 |
| 87 |
951-15030 |
LOWER SHIELD Price: $10.44 |
| 88 |
710-05192 |
SCREW M6-1 x 20 CL5.8 Price: $5.38 |
| 89 |
951-10792 |
IGNITION COIL Price: $84.66 |
| 90 |
710-04919 |
BOLT M6-1 x 25 GR8.8 Price: $3.86 |
| 91 |
951-14320 |
FLYWHEEL Price: $104.09 |
| 92 |
951-10909B |
COOLING FAN This part replaces 951-10934. Price: $20.39 |
| 93 |
951-14887 |
STARTER CUP Price: $12.71 |
| 94 |
712-04287A |
FLYWHEEL NUT M14-1.5 This part replaces 712-04287. Price: $5.33 |
| 95 |
651-05474 |
Recoil Starter Price: Call Us |
| 96 |
951-11583 |
BLOWER HOUSING Price: $84.66 |
| 97 |
951-15603 |
RECOIL STARTER Price: $43.06 |
| 98 |
736-04455B |
FLAT WASHER This part replaces 736-04455. Price: $5.94 |
| 99 |
710-06354 |
BOLT M6 x 10 Price: $5.73 |
| 100 |
751-18546 |
Crankshaft Price: Call Us |
| 101 |
951-15130 |
DRIVE TIMING GEAR Price: $12.54 |
| 102 |
710-06119 |
BOLT M5-.8 x 8 CL10.9 Price: $5.14 |
| 103 |
710-06118 |
BOLT M5-.8 x 12 CL10.9 Price: $5.22 |
