| Ref | Part Number | Description |
|---|
| A |
530026442 |
Model XR-20-T1 Price: $3.33 |
| A |
530026636 |
Model XR-20-T 2 Price: $3.33 |
| A |
530027345 |
Model XR-20-T3; Model XR-20T-T1 Price: $3.33 |
| B |
530026598 |
Model XR-20-T1 & 2 Price: $3.33 |
| B |
530027226 |
Model XR-20-T3; Price: $3.33 |
| B |
530027227 |
Model XR-20-T3; Price: $3.33 |
| B |
530027559 |
Model XR-20-T1 & 2 (Not a serviceable part) Price: Call Us |
| B |
530027631 |
Model XR-20T-T1 Price: $3.33 |
| 1 |
18-0630 |
DISCONTINUED Price: Call Us |
| 1 |
530027569 |
Handle-Starter This part replaces 530026735. Price: $1.99 |
| 2 |
3272-9 |
PIN-COTTER Price: $0.20 |
| 2 |
530069178 |
Fan Housing Kit (Inc.16,18,19,20,45) Price: $39.99 |
| 3 |
18-0760 |
DISCONTINUED Price: Call Us |
| 4 |
530021036 |
Switch Spring Insulation Price: $3.33 |
| 4 |
603773 |
LOCKNUT This part replaces 32146-2. Price: $2.09 |
| 5 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 5 |
530024371 |
Air Filter Price: $2.99 |
| 6 |
18-1270 |
DISCONTINUED Price: Call Us |
| 7 |
32140-32 |
SCREW-HH Price: $1.19 |
| 7 |
530024436 |
Fuel Tank Housing Bumper Price: $1.99 |
| 8 |
18-0750 |
DISCONTINUED Price: Call Us |
| 8 |
530024656 |
Handle & Fuel Tank Housing Price: $3.33 |
| 9 |
32153-3 |
NUT-HEX, SIDE DEFORM This part replaces 32146-5. Price: $5.59 |
| 9 |
530015247 |
Screw Price: $1.99 |
| 10 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 10 |
530024661 |
Handle Cover Price: $3.33 |
| 11 |
18-0560 |
DISCONTINUED Price: Call Us |
| 11 |
530026679 |
Kill Switch Button Price: $3.33 |
| 12 |
18-0770 |
DISCONTINUED Price: Call Us |
| 12 |
530015123 |
Kill Switch Washer Price: $1.99 |
| 13 |
322-2 |
SCREW-HH Price: $0.69 |
| 13 |
530015407 |
Screw Price: $0.56 |
| 14 |
322-1 |
SCREW-HH Price: $0.22 |
| 14 |
530024365 |
Throttle Trigger Price: $3.33 |
| 15 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 15 |
545008009 |
KIT STARTER SPRING This part replaces 530042067. Price: $5.99 |
| 16 |
18-3230 |
DISCONTINUED Price: Call Us |
| 16 |
530026035 |
Air Baffle Price: $2.99 |
| 17 |
530026048 |
Starter Pulley Price: $9.99 |
| 17 |
66-6140 |
DECAL This part replaces 18-2180. Price: $25.48 |
| 18 |
19-6060 |
DISCONTINUED Price: Call Us |
| 19 |
19-2970 |
DISCONTINUED Price: Call Us |
| 20 |
18-1290 |
DISCONTINUED Price: Call Us |
| 20 |
530026122 |
Spacer Price: $1.99 |
| 21 |
3218-1 |
NUT-JAM Price: $1.29 |
| 21 |
530069232 |
Rope Kit Price: $3.99 |
| 22 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 23 |
530626605 |
Flywheel Nut Price: $1.99 |
| 24 |
530023817 |
Spring-Starter Dog This part replaces 530042059. Price: $1.99 |
| 25 |
530015127 |
Washer Price: $1.99 |
| 26 |
530039114 |
Flywheel Ass'y. (Inc.24) Price: Call Us |
| 27 |
530024461 |
Trigger Spring Price: $2.99 |
| 28 |
530024407 |
Kill Switch Spring Price: $1.99 |
| 29 |
530015814 |
Screw-Line Limiter This part replaces 530015367. Price: $1.99 |
| 30 |
530039103 |
High Tension Lead Ass'y. (Inc.36,37,38) Price: Call Us |
| 33 |
530024158 |
Lead Wire Switch Price: $4.99 |
| 34 |
530069181 |
Module Kit Price: $3.33 |
| 35 |
530024303 |
Choke Knob Price: $5.99 |
| 36 |
530039082 |
High Tension Lead Wire Price: Call Us |
| 37 |
530003934 |
Spark Plug Boot Price: Call Us |
| 38 |
507475326 |
Spark Plug Boot This part replaces 530003933. Price: $3.99 |
| 39 |
530030077 |
Spark Plug Price: $2.27 |
| 41 |
530012096 |
Model XR-20-T 1 Price: $3.33 |
| 41 |
530026547 |
Model XR-20-T 2 & 3; Model XR-20T-T 1 Price: $3.33 |
| 42 |
530015376 |
Screw Price: $3.33 |
| 43 |
530093802 |
Pinch Clamp Bolt Price: $3.13 |
| 44 |
530015168 |
Screw Price: $1.46 |
| 47 |
530015590 |
Screw Price: $0.12 |
| 48 |
530015274 |
Washer Price: $0.99 |
| 49 |
530015163 |
Screw Price: $1.99 |
| 50 |
530015610 |
Nut Price: $0.99 |
| 51 |
530026560 |
Clamp Price: $1.99 |
| 52 |
530015609 |
Screw Price: $1.99 |
