| Ref | Part Number | Description |
|---|
| 1 |
539105408 |
WASHER #10 Price: $2.99 |
| 1 |
94-3123 |
CAPSCREW Price: $0.96 |
| 2 |
539111172 |
HOOD Price: $279.99 |
| 2 |
94-3117 |
DISCONTINUED Price: Call Us |
| 3 |
539111175 |
SUPPORT, DRAW LATCH Price: $29.99 |
| 3 |
741-0370 |
ROLLER BEARING CUP Not Available Price: |
| 3 |
94-3116 |
DISCONTINUED Price: Call Us |
| 4 |
539111182 |
INLET TUB Price: $89.99 |
| 4 |
74-7600 |
PLUG (BALL) Price: $6.93 |
| 4 |
741-0371 |
BEARING ASSY, PINION SHAFT REAR CONE Not Available Price: |
| 5 |
539111183 |
MESH, POLY DIAMOND Price: $6.99 |
| 5 |
94-3113 |
DISCONTINUED Price: Call Us |
| 6 |
539102587 |
GROMMET, BUMPER Price: $4.99 |
| 6 |
716-0138 |
RETAINING RING Not Available Price: |
| 6 |
76-5130 |
STUD Price: $2.11 |
| 7 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 7 |
717-3126 |
GEAR-REDUCTION Not Available Price: |
| 7 |
74-8900 |
WASHER-FLAT Price: $2.29 |
| 8 |
597338501 |
Washers This part replaces 539990598. Price: $12.99 |
| 8 |
94-3115 |
NUT Price: $1.30 |
| 9 |
74-6570 |
CUP-VALVE SPRING, LOWER Price: $3.36 |
| 9 |
741-04548 |
Cup Bearing This part replaces 741-0372. Price: $7.72 |
| 10 |
74-6560 |
SPRING-VALVE Price: $14.26 |
| 10 |
741-04549 |
Cone Bearing This part replaces 741-0373. Price: $17.28 |
| 11 |
717-3127 |
RETAINER RING Not Available Price: |
| 11 |
74-6550 |
CUP Price: $4.84 |
| 12 |
726-0216 |
EXPANSION PLUG Not Available Price: |
| 12 |
74-7240 |
COLLAR-SPLIT Price: $5.39 |
| 13 |
715-0146 |
DOWEL PIN 3/8 x 5/8 Not Available Price: |
| 13 |
74-6580 |
INSERT-VALVE (1.65MM) Price: $44.94 |
| 13 |
74-6720 |
INSERT-VALVE (2.400MM) Price: $9.73 |
| 13 |
74-6980 |
INSERT-VALVE (3.050MM) Price: $9.31 |
| 14 |
74-6540 |
TAPPET-VALVE Price: $41.87 |
| 14 |
936-0141 |
Spr. Wash. 7/16" I.D. This part replaces 736-0141. Price: $6.01 |
| 15 |
710-0850 |
HEX SCREW 7/16-14X2.5 Not Available Price: |
| 15 |
74-7570 |
LIFTING HOOK This part replaces 94-3135. Price: $9.76 |
| 16 |
736-0226 |
Washer, Flat, .46 x .875 x .060 Thk Price: $3.64 |
| 16 |
74-7560 |
LOCKWASHER Price: $0.67 |
| 17 |
710-3238 |
SCREW 7/16-14X1.75 GR5 Not Available Price: |
| 17 |
74-8130 |
SCREW - HEX HD This part replaces 76-5440. Price: $1.73 |
| 18 |
74-7630 |
GASKET-COVER, VALVE Price: $30.06 |
| 19 |
74-7640 |
COVER-VALVE Price: $171.54 |
| 20 |
717-3097 |
SHIM, BEARING RETAINER, .004 Not Available Price: |
| 20 |
74-7650 |
WASHER-FLAT Price: $1.03 |
| 21 |
717-3098 |
SHIM, BEARING RETAINER, .007 Not Available Price: |
| 21 |
94-3125 |
DISCONTINUED Price: Call Us |
| 22 |
717-3099 |
Shim, Bearing Retainer, .014 Thk Price: $32.65 |
| 22 |
94-3124 |
SCREW-HH Price: $1.30 |
| 23 |
717-3100 |
SHIM .028 Not Available Price: |
| 23 |
94-3136 |
BRACKET-LIFTING Price: $37.89 |
| 24 |
94-3138 |
SCREW-HH Price: $2.80 |
| 25 |
941-3039 |
ROLLER BEARING CUP This part replaces 741-3039. Price: $19.61 |
| 25 |
98-3840 |
BRACKET This part replaces 94-3137. Price: $9.35 |
| 26 |
94-3139 |
SCREW Price: $14.51 |
| 27 |
94-3174 |
WASHER-REPAIR Price: $10.07 |
| 28 |
703-0833 |
BRACKET-TRANS MTG (LH) Not Available Price: |
| 28 |
74-7270 |
WASHER-FLAT Price: $3.60 |
| 29 |
703-0832 |
BRACKET-TRANS MTG (RH) Not Available Price: |
| 29 |
74-7260 |
BOLT-HEAD Price: $17.07 |
| 30 |
710-3118 |
Bolt, Hex Patch, 3/8-16 x 1.0 LG GR5 Price: $4.77 |
| 30 |
94-3197 |
O-RING Price: $2.63 |
| 31 |
736-0169 |
Washer, Lock, 3/8 Price: $3.33 |
| 31 |
94-3196 |
DISCONTINUED Price: Call Us |
| 32 |
94-3118 |
DISCONTINUED Price: Call Us |
| 33 |
74-7840 |
PLUG Price: $2.02 |
| 34 |
3253-4 |
WASHER-LOCK This part replaces 68-9420. Price: $0.25 |
| 35 |
33114-025 |
SCREW-HH This part replaces 48-9460. Price: $0.70 |
| 36 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 37 |
94-3200 |
DISCONTINUED Price: Call Us |
| 38 |
33114-016 |
SCREW-HH This part replaces 48-7700. Price: $0.27 |
| 39 |
94-3199 |
PIPE-BY PASS Price: $195.25 |
| 40 |
98-8178 |
HOSE W/OUTLET BOX This part replaces 94-3201. Price: $540.50 |
| 41 |
74-7400 |
TUBE Price: $46.54 |
| 42 |
74-7840 |
PLUG Price: $2.02 |
| 43 |
94-3122 |
GASKET Price: $5.17 |
| 44 |
94-3121 |
PLUG Price: $12.11 |
| 45 |
74-7420 |
BALL Price: $1.11 |
| 46 |
74-7430 |
CHAMBER-TURBULENCE Price: $119.14 |
| 47 |
92-7792 |
GUIDE-VALVE (14.29 MM) Price: $25.96 |
| 48 |
74-7450 |
DISCONTINUED Price: Call Us |
| 49 |
74-7480 |
VALVE-INTAKE Price: $55.79 |
| 50 |
92-7794 |
VALVE-EXHAUST Price: $72.59 |
| 51 |
92-7795 |
SEAT-VALVE Price: $56.11 |
| 52 |
92-7791 |
VALVE-SEAL, STEM Price: $9.11 |
| 53 |
94-8132 |
GASKET-HEAD, 1.48 Price: $239.46 |
| 54 |
94-3120 |
BRACKET Price: $216.10 |
