| Ref | Part Number | Description |
|---|
| 1 |
136-8483 |
FRAME-PULL, RH This part replaces 92-9177. Price: $382.66 |
| 2 |
3220-3 |
NUT-HJ Price: $0.28 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
137-9706 |
DECAL-WARNING This part replaces 93-8064. Price: $4.48 |
| 4 |
147-3120 |
BALL JOINT RECEIVER ASM This part replaces 94-2959. Price: $16.35 |
| 8 |
62-2440 |
LIFT ARM ASM Price: $130.13 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 9 |
94-5588-01 |
BAR ASM-LIFT, R/H This part replaces 94-5588. Price: $131.34 |
| 10 |
63-8750 |
PIN-PIVOT Price: $4.20 |
| 11 |
57-7650 |
SPRING-TORSION Price: $11.81 |
| 11 |
583389701 |
KIT.SVC.CLUTCH.ELE.180505 This part replaces 532180505. Price: $299.99 |
| 12 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 13 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 14 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 15 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 15 |
581290101 |
TANK.ASSEMBL.2.5GAL.NON-EPA This part replaces 532407489. Price: $99.99 |
| 16 |
5-1226 |
WASHER Price: $3.90 |
| 17 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532197725. Price: $22.99 |
| 18 |
HY4486 |
NUT UNF 1/2"NYLOC EXT THIN5/16 This part replaces 283-8. Price: $1.36 |
| 19 |
140-5248 |
PIN-PIVOT RAM, WELDED This part replaces 10-6060. Price: $25.64 |
| 20 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 20 |
532175437 |
CONTROL.THROTTLE.BLACK This part replaces 532178385. Price: $24.99 |
| 21 |
322-1 |
SCREW-HH Price: $0.22 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
105-3822 |
HYD CYLINDER ASM This part replaces 83-2580. Price: $533.45 |
| 22 |
532189591 |
Choke Control Price: Call Us |
| 23 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 24 |
115-3259 |
KIT-SERVICE, PIN This part replaces 10-6110. Price: $39.21 |
| 25 |
10-7820 |
PIVOT HINGE ASM Price: $504.57 |
| 26 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 27 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 28 |
11-0160 |
ROLLER SHAFT SCREW ASM Price: $28.16 |
| 28 |
587044822 |
HOSE.1/4".LOW.PERM.FUEL.LN.22" This part replaces 532401137. Price: $9.99 |
| 29 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
3-1506 |
BUSHING Price: $2.42 |
| 31 |
138-6311 |
ARM-PULL-ASSEMBLY-LH This part replaces 92-0586. Price: $29.91 |
| 31 |
532145006 |
PUSH CLIP Price: $2.99 |
| 32 |
3290-317 |
WASHER-SPRING Price: $1.40 |
| 33 |
131-4295 |
PIN-PIVOT This part replaces 10-6090. Price: $51.39 |
| 34 |
138-6303 |
ARM-PULL-ASSEMBLY-RH This part replaces 92-0585. Price: $29.91 |
| 35 |
133-2337 |
ROLLER ASM This part replaces 52-2720. Price: $176.14 |
| 36 |
21-8470 |
SHAFT-ROLLER Price: $62.10 |
| 37 |
133-2378 |
BEARING This part replaces 251-141. Price: $23.28 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 38 |
237-78 |
O-RING Price: $3.85 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN This part replaces 532159955. Price: $27.99 |
| 71 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK This part replaces 532160589. Price: $22.99 |
| 79 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
537171877 |
BOLT 5/1618UNC X 3/4 W/ SEMS Price: $1.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
