| Ref | Part Number | Description |
|---|
| 1 |
590486802 |
WHEEL.CARLSTAR.11X4-5".MS417 This part replaces 581199701. Price: $74.99 |
| 1 |
66-6370 |
LIFT ARM ASM Price: $430.43 |
| 2 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 2 |
576588602 |
WHEEL ASSY, WIDE, RZ Price: $99.99 |
| 3 |
32136-2 |
NUT-SHH Price: $3.55 |
| 3 |
586650309 |
YOKE CASTER ASSY 6INCH YOKE.PN This part replaces 576588801. Price: $49.99 |
| 4 |
21-3020-01 |
MOUNT-BALLJOINT, RH This part replaces 21-3020. Price: $178.87 |
| 4 |
539115638 |
ZERK, 3/16, DRIVE IN Price: $4.99 |
| 5 |
21-1830 |
SPRING-EXTENSION Price: $34.62 |
| 5 |
539103300 |
ZERK Price: $2.99 |
| 6 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 6 |
539112660 |
BEARING FLANGED Price: $19.99 |
| 7 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 7 |
539117901 |
BUSHING, CASTER Price: $8.99 |
| 8 |
3217-8 |
NUT-HEX Price: $1.34 |
| 8 |
595281301 |
Caps This part replaces 539102535. Price: $4.99 |
| 9 |
596301001 |
Casters This part replaces 539115749. Price: $2.99 |
| 9 |
66-7150 |
ARM-PUSH, RH Price: $536.26 |
| 10 |
3272-24 |
PIN-COTTER Price: $0.54 |
| 10 |
539105543 |
SPACER Price: $8.99 |
| 11 |
24-9510 |
PIN Price: $77.49 |
| 11 |
596388901 |
Casters This part replaces 539115747. Price: $2.99 |
| 12 |
596319901 |
Screws This part replaces 539115566. Price: $2.99 |
| 12 |
61-3610 |
WARNING DECAL Price: $16.67 |
| 13 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 13 |
576601503 |
NUT.HEX.1/2-13 CENTRLK GR5 (BL This part replaces 576601501. Price: $9.99 |
| 14 |
46-8840-01 |
SPRING-LIFT ARM This part replaces 46-8840. Price: $35.71 |
| 14 |
539200100 |
NUT 1/2-13 HEX CNTRLK GR 5 ZD Price: $3.99 |
| 15 |
5-1754 |
WASHER-FLAT Price: $2.17 |
| 15 |
587653903 |
Nuts This part replaces 539101173. Price: $3.99 |
| 16 |
256-126 |
BUSHING Price: $9.36 |
| 16 |
596319801 |
Washers This part replaces 539115675. Price: $2.99 |
| 17 |
3272-33 |
PIN-COTTER Price: $0.54 |
| 18 |
23-1950-01 |
SUPPORT-REINFORCEMENT This part replaces 23-1950. Price: $69.64 |
| 19 |
324-4 |
SCREW-HH Price: $0.95 |
| 20 |
3-7292 |
PIN-CLEVIS Price: $44.11 |
| 21 |
5-3126 |
PIN-LYNCH Price: $0.73 |
| 22 |
3241-7 |
SCREW-SQH This part replaces 324-12. Price: $3.39 |
| 23 |
21-3750 |
SUPPORT PLT Price: $14.42 |
| 24 |
21-2860-01 |
PUSH ARM BRACKET ASM This part replaces 21-2860. Price: $154.46 |
| 25 |
32121-84 |
PIN-SPIRAL Price: $1.29 |
| 26 |
21-2990 |
SHAFT-PIVOT Price: $227.21 |
| 27 |
32128-42 |
NUT-HF Price: $0.98 |
| 28 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 29 |
21-2960 |
ARM-PUSH, LH Price: $519.38 |
| 30 |
21-2900-01 |
SPRING-TORSION, LH This part replaces 21-2900. Price: $566.83 |
| 31 |
21-2890-01 |
SPRING-TORSION, RH This part replaces 21-2890. Price: $566.83 |
| 32 |
21-3050-01 |
LH BALL JOUNT MOUNT ASM This part replaces 21-3050. Price: $153.41 |
| 33 |
86-8100-01 |
BALL JOINT ASM This part replaces 21-0160. Price: $137.53 |
| 34 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 35 |
21-3000-01 |
NUT-JAM, PUSH ARM This part replaces 21-3000. Price: $37.02 |
| 36 |
3-1365 |
CHAIN Price: $72.97 |
| 37 |
68-3270 |
BUMPER-RUBBER This part replaces 67-9800. Price: $37.99 |
| 38 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 39 |
5-2942 |
SHACKLE Price: $16.99 |
