| Ref | Part Number | Description |
|---|
| 1 |
132-6259-0P |
SWITCH MOUNT ASM This part replaces 132-6259-03. Price: $105.94 |
| 1 |
532186093 |
WHEEL.STEERING.LEGND2.GRY This part replaces 532193943. Price: $89.99 |
| 2 |
117-5458 |
SCREW-HHF Price: $0.22 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 3 |
99-3410 |
SWITCH Price: $95.63 |
| 4 |
108-9824 |
NUT-SWITCH Price: $1.97 |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532403087. Price: $14.99 |
| 5 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532403088. Price: $19.99 |
| 6 |
32144-69 |
SCREW-HWHTF Price: $1.58 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
2412-4 |
CLAMP-R Price: $4.22 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
256-236 |
BEARING-MOUNT, FLANGE Price: $27.99 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
120-8899 |
CABLE-BRAKE, LH Price: $97.43 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
322-13 |
SCREW-HH Price: $2.73 |
| 11 |
132-6290-0P |
RACK ASM This part replaces 132-6290-03. Price: $114.51 |
| 12 |
3256-69 |
WASHER-FLAT Price: $0.62 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 13 |
63-7880 |
PIN-LATCH, BRAKE Price: $6.04 |
| 14 |
32121-50 |
PIN-SPRING Price: $1.21 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 15 |
93-8742 |
FOOTPAD-BRAKE Price: $27.95 |
| 16 |
132-6288-01 |
PEDAL-BRAKE, LH Price: $132.21 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532408219. Price: $34.99 |
| 17 |
120-8898 |
CABLE-BRAKE, RH Price: $104.62 |
| 18 |
94-3088 |
SPRING-COMPRESSION Price: $8.24 |
| 19 |
120-9694 |
PIN-CLEVIS Price: $2.17 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 21 |
132-6252 |
PEDAL-BRAKE, RH Price: $122.77 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532194845. Price: $14.99 |
| 23 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 24 |
3231-21 |
SCREW-CARR Price: $0.76 |
| 25 |
94-3050 |
PLATE-SPRING Price: $7.88 |
| 26 |
532193652 |
INSERT.CAP.STRG.WH.GRAY Price: $11.99 |
| 27 |
110-4896 |
LANYARD Price: $40.99 |
| 28 |
3256-57 |
WASHER-FLAT Price: $0.41 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 30 |
132-6247-01 |
MOUNT-BEARING Price: $13.60 |
| 31 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 32 |
137-1632 |
HUB-BRAKE This part replaces 132-6229. Price: $43.71 |
| 33 |
4-2390 |
WASHER-FLAT Price: $0.62 |
| 34 |
32121-125 |
PIN-SPRING Price: $0.54 |
| 35 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 36 |
88-7970 |
CLIP Price: $2.51 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
