| Ref | Part Number | Description |
|---|
| 1 |
783-0678C |
Deck Lift Link Price: $21.13 |
| 2 |
647-04096A-0637 |
Handle Assembly, PTO This part replaces 647-04096. Price: $36.03 |
| 3 |
738-04237A |
SHOULDER SCREW This part replaces 738-04237. Price: $5.30 |
| 4 |
710-0599 |
Screw, 1/4-20, 0.500 Price: $3.86 |
| 6 |
783-05389A |
BRACKET This part replaces 783-05389. Price: $5.81 |
| 7 |
714-0145 |
Pin, Click, .092 x 1.64 Price: $4.42 |
| 8 |
720-04049A |
Grip, Handle, 3/8 Price: $14.09 |
| 9 |
732-04276A |
Spring, Extension Price: $8.55 |
| 10 |
736-0171 |
Washer, Lock, 7/16 Price: $3.86 |
| 11 |
736-0300 |
Washer, Flat, .406 x .875 x .059 Price: $3.93 |
| 12 |
736-0322 |
Washer, Flat, .450 x 1.250 x .164 Price: $8.42 |
| 13 |
741-04119A |
Bearing, PTO This part replaces 741-04119. Price: $4.56 |
| 14 |
946-04173E |
Deck Engage Cable This part replaces 746-04173B. Price: $55.45 |
| 15 |
783-04753 |
Frame Support Bracket Price: $60.75 |
| 17 |
725-04363 |
Switch, Interlock Price: $13.25 |
| 19 |
710-04484 |
SCREW 5/16-18 x .750 Price: $3.19 |
| 20 |
683-04649B-0691 |
FRAME ASSEMBLY (BLACK JACK) Not Available This part replaces 683-04163B. Price: |
| 21 |
783-04536B |
Pedal Support Bracket Price: $5.28 |
| 22 |
710-0604A |
Screw, 5/16-18, 0.625 Price: $3.96 |
| 23 |
712-04064 |
Nut, Flange Lock, 1/4-20, GrF Price: $3.64 |
| 24 |
732-04035 |
Spring, Compr. , 1.28 OD x 3.125 Price: $9.61 |
| 25 |
783-04462A |
LIFT BRACKET 50" DECK Not Available This part replaces 783-04462. Price: |
| 26 |
747-04744A |
BATTERY ROD ASSEMBLY This part replaces 683-04448. Price: $9.09 |
| 27 |
783-04869A-0637 |
Battery Bracket This part replaces 783-04869A. Price: $7.91 |
| 28 |
783-04548D-0637 |
Seat Frame Bracket This part replaces 783-04548C. Price: $51.45 |
| 29 |
783-04637 |
RUNNINGBOARD BRACKET Price: $11.69 |
| 32 |
712-04065 |
Nut, Flange Lock, 3/8-16, GrF Price: $3.68 |
| 33 |
714-04043 |
Pin, Cotter .08 x 1.56 Intern. RH Price: $4.24 |
| 33 |
714-0470 |
Pin, Cotter .080 x 1.25 Intern. LH Price: $3.90 |
| 34 |
716-0106A |
Ring, E-Type, .625 Dia. Price: $4.42 |
| 35 |
720-0311 |
Grip, Handle, 1/2 Price: $13.26 |
| 36 |
732-04225 |
Spring, Torsion 38/42" Decks Price: $10.75 |
| 37 |
738-04130A |
Shoulder Screw, .625 x .175, 3/8-16 This part replaces 738-04130. Price: $8.20 |
| 38 |
941-0225 |
FLANGE BEARING This part replaces 741-0225. Price: $6.55 |
| 39 |
747-04393 |
Rod, Lift Price: $20.87 |
| 41 |
783-04494C |
DECK LIFT ARM (RH) This part replaces 783-04494. Price: $17.72 |
| 41 |
783-04711 |
Lift Arm, Deck - LH Price: $18.71 |
| 42 |
710-04666 |
Screw, Carriage, 1/4-20, .75, Gr5 Price: $6.04 |
| 43 |
712-0271 |
Nut, Sems, 1/4-20 Price: $3.78 |
| 44 |
925-1707D |
BATTERY Not Available This part replaces 725-1737A. Price: |
| 45 |
683-04195 |
Support Bracket Assembly Price: $30.37 |
| 46 |
710-0134 |
Carriage Screw, 1/4-20 x .62 Price: $3.71 |
| 47 |
710-3025 |
Screw, 5/16-18 x .625 Price: $3.64 |
| 48 |
712-04063 |
Flange Lock Nut, 5/16-18 Price: $3.56 |
| 49 |
712-0429 |
Hex Lock Nut, 5/16-18 Price: $3.56 |
| 50 |
736-0173 |
Flat Washer, .28 x .74 x .063 Price: $3.76 |
| 51 |
710-3008 |
SCREW 5/16-18 x .75 GR5 Price: $3.76 |
| 53 |
720-0298 |
Grip, Handle, 5/8 Price: $37.92 |
| 55 |
732-0934 |
Extension Spring Price: $10.43 |
| 56 |
736-0140 |
Washer, Flat, .385 x .62 x .063 Price: $6.20 |
| 57 |
736-0226 |
Washer, Flat, .474 x .879 x .064 Price: $3.64 |
| 58 |
738-0380 |
Bolt, Shldr. .500 x .270 3/8-16 Price: $7.34 |
| 59 |
738-0754 |
Screw, Shldr. , .437 x .54 Price: $3.76 |
