| Ref | Part Number | Description |
|---|
| 1 |
3290-322 |
PIN-HAIR Price: $1.09 |
| 2 |
46-1600 |
SPACER Price: $4.40 |
| 2 |
532179758 |
MUFFLER.B&S.MODEL.21.11HP.OHV Price: $69.99 |
| 3 |
283-82 |
PIN-CLEVIS This part replaces 283-23. Price: $3.94 |
| 4 |
39-1470-01 |
HANGER-BELLY SHIELD This part replaces 39-1470. Price: $34.44 |
| 5 |
323-7 |
SCREW-HH Price: $0.65 |
| 6 |
39-1410-01 |
SHIELD BELLY ASM This part replaces 39-1410. Price: $705.69 |
| 7 |
39-1440-01 |
BELLY SHIELD HOOK ASM This part replaces 39-1440. Price: $72.41 |
| 8 |
32128-20 |
NUT-HF Price: $0.99 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 (3 2) Price: $11.99 |
| 12 |
532140186 |
PULLEY.ENG.CL.MECH.SLVR.LT/YT Price: $99.99 |
| 15 |
581289901 |
FUEL.TANK.ASM.NON-EPA This part replaces 532407545. Price: $44.99 |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532430220. Price: $22.99 |
| 20 |
532176636 |
CONTROL.TH/CK.C.BLACK This part replaces 532183897. Price: $27.99 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 69 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED This part replaces 532165291. Price: $8.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 105 |
583383701 |
SHIELD.SRD.LH.SIDE.FRENCH This part replaces 532420894. Price: $12.99 |
| 106 |
583457201 |
SHILED.SIDE.RH.30SD.FRENCH This part replaces 532430257. Price: $7.99 |
| 108 |
583471901 |
COVER.PULLEY.ENGINE.SRD.FRENCH This part replaces 532431689. Price: $84.99 |
| 122 |
532421922 |
EXTENSION DRAIN OIL Price: $24.99 |
