| Ref | Part Number | Description |
|---|
| 1 |
539105330 |
FUEL TANK DIESEL RT Price: $139.99 |
| 1 |
80-4860 |
PIN-CLEVIS Price: $6.13 |
| 2 |
539105329 |
FUEL TANK DIESEL LT Price: $179.99 |
| 2 |
75-3580 |
PLATE-SEAT Price: $213.06 |
| 3 |
596584001 |
Screws This part replaces 539991034. Price: $2.99 |
| 3 |
75-3530 |
SPRING-COMPRESSION Price: $31.98 |
| 4 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 4 |
539977351 |
GAS LINE 3 1/2" Price: $2.99 |
| 5 |
21500049 |
PLUG EXT HEX VENT 9/16 18 Price: $5.45 |
| 5 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 5 |
539914359 |
FUEL FILTER Price: $4.99 |
| 6 |
3285-19 |
PIN-GROOVE This part replaces 75-3540. Price: $1.79 |
| 6 |
539105532 |
HEX CAP SCREW 1/4 Price: $2.99 |
| 7 |
27105900 |
SCREW,HEX WASHER 1/4-20X1.125 Price: $1.95 |
| 7 |
539105382 |
FUEL LINE 30" This part replaces 539105531. Price: $11.99 |
| 7 |
75-3550 |
BUMPER-SEAT Price: $18.48 |
| 8 |
587044818 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 539105526. Price: $8.99 |
| 8 |
76-2940 |
BUMPER Price: $9.73 |
| 9 |
539105245 |
RUBBER GROMMET Price: $3.99 |
| 9 |
76-1920 |
SLEEVE-BEARING Price: $22.50 |
| 10 |
539105244 |
ELBOW Price: $4.99 |
| 10 |
66-8610 |
DISCONTINUED Price: Call Us |
| 11 |
21500049 |
PLUG EXT HEX VENT 9/16 18 Price: $5.45 |
| 11 |
539107765 |
HOSE, FUEL .25 ID X 26" This part replaces 539105527. Price: $6.99 |
| 11 |
66-8560 |
NUT-PUSH Price: $5.97 |
| 12 |
539105331 |
FUEL VALVE Price: $84.99 |
| 12 |
76-1910 |
DISCONTINUED Price: Call Us |
| 13 |
21543771 |
SEALANT TUBE 10.1OZ. Price: $132.95 |
| 13 |
82-9060 |
DISCONTINUED Price: Call Us |
| 14 |
539912222 |
HOSE CLAMP Price: $2.99 |
| 14 |
76-1940 |
SPRING-EXTENSION Price: $66.03 |
| 15 |
539105411 |
VENT HOSE Price: $2.99 |
| 15 |
66-9290 |
SPACER-SUSPENSION Price: $3.60 |
| 16 |
108-6703 |
ADJUSTER-SEAT This part replaces 66-8530. Price: $183.47 |
| 17 |
66-8520 |
BUMPER-DOWNSTOP Price: $37.56 |
| 18 |
539105529 |
CLAMP Price: $4.99 |
| 18 |
76-1960 |
KNOB KIT This part replaces 77-2870. Price: $357.33 |
| 19 |
106-1031 |
TENSION ADJUSTER KNOB ASM This part replaces 76-1930. Price: $68.93 |
| 19 |
539105530 |
FUEL LINE 34" Price: $6.99 |
| 20 |
3256-46 |
WASHER-FLAT Price: $5.77 |
| 20 |
539105334 |
FUEL VALVE DECAL Price: $6.99 |
| 21 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 22 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 23 |
21545100 |
OIL FILTER, TRANSMISSION Price: $36.95 |
| 23 |
75-3480 |
FRAME-UPPER Price: $323.32 |
| 24 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 25 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 26 |
75-3510 |
BOLT-SHOULDER Price: $14.55 |
| 27 |
93-3164 |
CAP Price: $11.64 |
| 28 |
93-3163 |
SPRING Price: $26.01 |
| 29 |
93-3165 |
BRACKET Price: $37.47 |
| 30 |
21500013 |
Seal, lip .375 x 375 x 325 Price: $4.45 |
| 30 |
322-6 |
SCREW-HH Price: $0.45 |
| 31 |
08622500 |
RING. RETAINING Price: $7.45 |
| 31 |
3253-33 |
WASHER-LOCK Price: $1.19 |
| 33 |
21543846 |
RING, RET .750 Price: $1.55 |
| 34 |
21544046 |
ARM, BYPASS Price: $12.45 |
| 35 |
21543848 |
RING, RTNG . Price: $4.45 |
| 40 |
21543783 |
TRUNNION, SWASHPLATE Price: $56.95 |
| 41 |
21543809 |
SEAL, LIP 18X32X7 Price: $8.45 |
| 45 |
08611200 |
WASHER Price: $3.45 |
| 55 |
21543773 |
WASHER 1.23X1.56X.04 Price: $5.45 |
| 56 |
21543816 |
SEAL, LIP 17X40X7 Price: $11.95 |
| 57 |
21543741 |
RING, RET 1.56 INT Price: $6.45 |
| 60 |
21548902 |
HG THRUST BEARING (51462) Price: $25.45 |
| 64 |
21548904 |
HG 16CC CYLINDER BLOCK (71579) Price: $60.95 |
| 65 |
08609100 |
BEARING. THRUST 30 X 52 X 13 Price: $14.95 |
| 69 |
21543921 |
ASSY, BLOCK 7 PISTON Price: $112.45 |
| 70 |
21543708 |
WASHER .63X1.0X.05 Price: $3.45 |
| 71 |
21543704 |
RING, RET 62 EXT Price: $1.45 |
| 74 |
21543788 |
WASHER .71 X 1.16 X .04 Price: $2.95 |
| 80 |
21543724 |
WASHER .5X1.0X.032 Price: $2.95 |
| 83 |
21543793 |
JACK SHAFT (PIN) Price: $17.95 |
| 90 |
08616500 |
RING, RETAINING Price: $8.45 |
| 91 |
21500035 |
GEAR, 54T Price: $61.45 |
| 93 |
21500082 |
KIT, BEARING Price: $17.95 |
| 95 |
08614000 |
BEARING, BALL 25.4 X 52 X 15 Price: $19.95 |
| 96 |
08614300 |
SEAL, LIP Price: $13.95 |
| 97 |
21544061 |
KIT, HUB 4 BOLT Price: $74.95 |
| 102 |
21544037 |
BRAKE ARM HG 71957 Price: $20.45 |
| 103 |
21544007 |
CLIP,BRAKE ARM HYDROGEAR 52027 Price: $5.45 |
| 140 |
21543870 |
SPACER Price: $9.95 |
| 141 |
21543866 |
ARM, NEUTRAL RIGHT Price: $20.45 |
| 142 |
21543843 |
SHCS 5/16-24X1 PATCH Price: $3.95 |
| 147 |
21544041 |
RTN SPRING HG 51605 Price: $5.45 |
| 158 |
21500038 |
CAP, AXLE Price: $16.45 |
| 159 |
21544052 |
SPRING, TORSION CCW Price: $8.95 |
| 186 |
21500037 |
TUBE, AXLE 2.03 Price: $5.45 |
| 200 |
21543999 |
KIT, SEAL Price: $61.45 |
| 201 |
21500075 |
KIT, CENTER SECTION RH, CHARGE Price: $254.95 |
| 203 |
21544060 |
KIT, CHARGE Price: $76.45 |
| 209 |
21544008 |
HUB PULLER 5 BLT Price: $356.95 |
| 211 |
21544002 |
RTN KIT HYDROGEAR P/N 71597 Price: $27.95 |
