| Ref | Part Number | Description |
|---|
| 0 |
640225A |
CARBURETOR This part replaces 640226. Price: $78.00 |
| 1 |
108-9083 |
PLATE-SIDE, RH Price: $328.36 |
| 1 |
530057893 |
Knob-Choke Price: $3.99 |
| 1 |
631255 |
SHAFT & LEV Price: $6.36 |
| 2 |
108-9082 |
PLATE-SIDE, LH Price: $328.36 |
| 2 |
530057908 |
Spring-Ign. Switch Price: $2.99 |
| 2 |
631767 |
SPRING Price: $1.25 |
| 3 |
104-3396 |
SCREW-HH Price: $0.75 |
| 3 |
530057891 |
Lever-Ign. Switch Price: $4.99 |
| 4 |
530016080 |
Screw Price: $1.99 |
| 4 |
631184 |
WASHER Price: $1.25 |
| 4 |
99-8662 |
TUBE-SPRING Price: $21.55 |
| 5 |
3218-5 |
NUT-JAM Price: $0.27 |
| 5 |
530071888 |
Kit-Trigger/Lockout Price: $6.99 |
| 5 |
631183 |
WASHER Price: $1.25 |
| 6 |
530069216 |
Kit-Fuel Line (Large) Price: $3.99 |
| 6 |
631036 |
SHUTTER Price: $1.20 |
| 6 |
87-7270 |
WASHER-THRUST Price: $0.89 |
| 7 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 7 |
530069247 |
Kit-Fuel Line (Small) Price: $3.99 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 8 |
530095646 |
Assy-Fuel Pick Up Price: $2.99 |
| 9 |
110-4079 |
SPRING-COMPRESSION Price: $13.57 |
| 9 |
530023877 |
Fitting-Fuel line Price: $1.99 |
| 10 |
530071945 |
Kit-Clutch Washer Price: $3.99 |
| 10 |
631543 |
SHAFT & LEV Price: $6.48 |
| 11 |
530057905 |
Assy-Clutch Drum 3/8" Price: $14.99 |
| 11 |
632042 |
SPRING Price: $3.00 |
| 12 |
110-4069 |
BRACKET Price: $5.57 |
| 12 |
530071945 |
Kit-Clutch Washer Price: $3.99 |
| 13 |
115-2007 |
ROD-SPRING Price: $34.97 |
| 13 |
530057907 |
Assy-Clutch Price: $6.99 |
| 14 |
530016419 |
Washer-Large Clutch Price: $1.99 |
| 14 |
630736 |
SHUTTER Price: $2.19 |
| 14 |
92-2762 |
PIN-HAIR Price: $1.09 |
| 15 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 15 |
580940901 |
FUEL CAP ASSY This part replaces 530047192. Price: $3.99 |
| 15 |
630735 |
SPRING Price: $1.25 |
| 16 |
545227101 |
SCREW 6-19X.437 This part replaces 530016064. Price: $1.99 |
| 16 |
632164 |
FUEL FITTING Price: $5.95 |
| 17 |
530015922 |
Nut-"U" type speed Price: $1.99 |
| 17 |
651025 |
SCREW Price: $1.18 |
| 18 |
110-4058 |
BRACKET-CHAIN Price: $32.43 |
| 18 |
530059635 |
Assy-Flywheel Price: $24.99 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 19 |
107-3258 |
FRAME Price: $331.61 |
| 19 |
530057911 |
Shield-Heat Price: $2.99 |
| 20 |
107-2979 |
BOLT-SHOULDER Price: $3.94 |
| 20 |
530015127 |
Washer-Flywheel Price: $1.99 |
| 20 |
631562 |
ADJ SCREW Price: $3.74 |
| 21 |
3234-19 |
SCREW-HHF Price: $1.73 |
| 21 |
630738 |
SPRING Price: $1.25 |
| 22 |
530021179 |
Screw-Shoulder Price: $1.99 |
| 22 |
630739 |
WASHER Price: $1.25 |
| 22 |
67-9410 |
WASHER Price: $2.04 |
| 23 |
108-4279 |
SPACER-FRAME Price: $8.34 |
| 23 |
530059677 |
Hub-EPS Price: $5.99 |
| 23 |
630740 |
O RING Price: $1.49 |
| 24 |
108-4284 |
TUBE-SUPPORT Price: $60.29 |
| 24 |
530021180 |
Spring-EPS Price: $1.99 |
| 25 |
107-7433 |
CARRIER FRAME ASM Price: $484.72 |
| 25 |
545008013 |
Kit-Starter Spring This part replaces 530042095. Price: $3.99 |
| 26 |
579372101 |
KIT FAN HSG PRO GOLD This part replaces 530058811. Price: $9.99 |
| 27 |
530056402 |
Handle-Starter Price: $2.99 |
| 28 |
530069232 |
Kit-Rope Price: $3.99 |
| 29 |
530016432 |
Screw Price: $1.99 |
| 30 |
530016080 |
Screw Price: $1.99 |
| 31 |
530016134 |
Nut-Flywheel Price: $1.99 |
| 32 |
530058786 |
Assy-Oil Vent Price: $2.99 |
| 33 |
530057236 |
Assy-Oil Cap w/ret. Price: $5.99 |
| 34 |
530057897 |
Handguard Price: $7.99 |
| 35 |
530016416 |
Spring-Handguard Price: $1.99 |
| 37 |
530071893 |
Kit-Chainbrake Price: $17.99 |
| 38 |
530016432 |
Screw Price: $1.99 |
| 39 |
530016133 |
Bolt-Bar Price: $1.99 |
| 40 |
530057910 |
Plate-Bar Price: $1.99 |
| 40 |
640223 |
RESTRICTOR Price: $3.86 |
| 40A |
640053 |
CAP Price: $0.81 |
| 41 |
530015917 |
Nut-Bar Price: $0.99 |
| 42 |
530058934 |
Assy-Clutch Cover This part replaces 530058915. Price: $11.99 |
| 43 |
581562201 |
ACCY P/PP CHN 16" 56DL 3/8 This part replaces 952051547. Price: $19.99 |
| 44 |
952044942 |
Accy-18" Bar Price: $27.95 |
| 46 |
530016432 |
Screw Price: $1.99 |
| 47 |
530057888 |
Handle-Front Price: $14.99 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 48 |
632554 |
WELCH PLUG Price: $1.17 |
| 49 |
530057924 |
Assy-Oil Pick Up Price: $2.99 |
| 50 |
545227101 |
SCREW 6-19X.437 This part replaces 530016064. Price: $1.99 |
| 50 |
630978 |
DIAPHRAGM Price: $4.49 |
| 51 |
581071401 |
OIL PUMP ASSY SAS This part replaces 530057931. Price: $5.99 |
| 51 |
630750A |
GASKET Price: $3.00 |
| 52 |
630751 |
COVER Price: $8.60 |
| 53 |
650545 |
SCREW Price: $1.20 |
| 55 |
630932A |
INLET NEEDLE Price: $4.39 |
| 56 |
630742 |
GASKET Price: $1.25 |
| 57 |
631049 |
SPRING Price: $1.20 |
