| Ref | Part Number | Description |
|---|
| 1 |
104-4620 |
SEAT Price: $273.15 |
| 1 |
532144569 |
Shaft, Pump Price: $182.99 |
| 2 |
106-7090 |
HARNESS-WIRE, SEAT SWITCH Price: $26.16 |
| 2 |
532142928 |
Wire Retaining Ring This part replaces 532122716. Price: $3.99 |
| 3 |
532122745 |
Bearing, Ball Price: $61.99 |
| 3 |
92-6282 |
SWITCH-SEAT Price: $31.99 |
| 4 |
110-9730 |
SEAT SUSPENSION ASM This part replaces 76-1970. Price: $776.63 |
| 4 |
532122715 |
Spacer Price: $5.46 |
| 5 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 5 |
532142932 |
Seal, Lip This part replaces 532122700. Price: $9.99 |
| 6 |
532122699 |
Ring, Retaining Price: $2.38 |
| 6 |
93-0140 |
GROMMET-RUBBER Price: $3.94 |
| 8 |
532122767 |
Bearing, Cradle Price: $12.44 |
| 9 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 10 |
104-7048 |
CAP-HOUSING Price: $5.21 |
| 11 |
104-7050 |
TUBE-MANUAL Price: $8.76 |
| 12 |
2412-133 |
CLAMP-R Price: $3.19 |
| 12 |
532122717 |
Seal, Lip Price: $2.68 |
| 13 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 13 |
532122748 |
Arm, Trunnion Price: $146.13 |
| 14 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 14 |
532122749 |
Guide, Slot Price: $4.99 |
| 15 |
322-3 |
SCREW-HH Price: $0.79 |
| 15 |
532144571 |
Housing Kit, Transmission Price: $75.04 |
| 16 |
2412-93 |
CLAMP-R Price: $1.02 |
| 17 |
532150771 |
BEARING, THRUST This part replaces 532122770. Price: $23.99 |
| 18 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 19 |
112-0169 |
SEATBELT ASM-SERVICE This part replaces 21-4191. Price: $283.31 |
| 19 |
532144572 |
Center Section Kit Price: $762.99 |
| 21 |
532122722 |
Seal, Lip Price: $4.99 |
| 22 |
532144573 |
Shaft, Motor Price: $103.99 |
| 23 |
532144574 |
Washer, Block Thrust Price: Call Us |
| 25 |
532127148 |
Swashplate, Variable Price: $163.93 |
| 32 |
532144577 |
Block Assembly Price: Call Us |
| 37 |
532122786 |
Pin, Stainless, Headless Price: $2.38 |
| 38 |
532122718 |
Gasket, Center Section Price: $3.99 |
| 42 |
532144578 |
Check Valve Kit Price: $46.99 |
| 43 |
532144578 |
Check Valve Kit Price: $46.99 |
| 44 |
532144579 |
Charge Relief Kit Price: $5.99 |
| 47 |
532122752 |
Screw, Socket Head, Cap Price: $2.99 |
| 53 |
532127153 |
Bypass Valve Kit Price: $96.99 |
| 60 |
532144580 |
Block Spring Price: Call Us |
| 62 |
532144581 |
O-Ring Price: $3.99 |
| 63 |
532144582 |
Charge Pump Kit Price: $157.88 |
| 64 |
532144583 |
Gerotor Assembly Price: $28.99 |
| 67 |
532144584 |
Screw, Socket Head, Cap Price: $3.08 |
