| Ref | Part Number | Description |
|---|
| 1 |
40-6230 |
SPRING Price: $37.99 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD Price: $69.99 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 3 |
32128-20 |
NUT-HF Price: $0.99 |
| 4 |
43-8480 |
DECAL-DANGER Price: $6.49 |
| 5 |
3296-5 |
NUT-HEX Price: $3.09 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
66-6380 |
DECAL-DANGER Price: $8.97 |
| 7 |
29-5590-03 |
BRACKET-PIVOT This part replaces 29-5590. Price: $23.25 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
66-1340 |
DECAL-DANGER, THROWN OBJECT Price: $9.07 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 11 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 12 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 13 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
28-9060 |
PLATE-IDLER Price: $137.75 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
5-1077 |
KEY-SQUARE Price: $6.18 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 587016002. Price: $34.99 |
| 16 |
99-1297 |
IDLER ARM ASM This part replaces 27-8580. Price: $133.94 |
| 17 |
65-5940 |
PULLEY-IDLER Price: $35.61 |
| 18 |
7-0081 |
WASHER-FLAT Price: $0.89 |
| 19 |
36-1740 |
ROLLER-DECK Price: $37.03 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 21 |
40-0340 |
SHAFT-ROLLER, REAR Price: $29.99 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 586840201. Price: $7.99 |
| 22 |
27-1160 |
V-BELT Price: $51.80 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 585029802. Price: $14.99 |
| 23 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 24 |
32146-20 |
NUT-HEX Price: $3.23 |
| 25 |
7-4150 |
WASHER Price: $1.19 |
| 26 |
27-0970-03 |
PULLEY ASM This part replaces 27-0970. Price: $51.99 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 27 |
253-139 |
SEAL-OIL Price: $12.45 |
| 27 |
596933401 |
Washers This part replaces 819211616. Price: $2.99 |
| 28 |
46-8530 |
BEARING ASM Price: $93.99 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 30 |
27-7680-03 |
RING-DECK SUPPORT This part replaces 27-7680. Price: $70.99 |
| 31 |
68-8340 |
DECAL-TORQUE Price: $19.99 |
| 32 |
61-4160 |
HOUSING-SPINDLE Price: $131.00 |
| 33 |
32128-21 |
NUT-HF Price: $0.39 |
| 34 |
27-0920 |
SHAFT Price: $158.07 |
| 35 |
27-0990-03 |
BLADE-18 INCH This part replaces 27-0990. Price: $18.94 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 36 |
72-9361 |
CUP-SCALP, ANTI Price: $39.78 |
| 37 |
3253-27 |
WASHER-LOCK Price: $2.24 |
| 38 |
44-2200 |
SCREW-BLADE Price: $4.04 |
| 39 |
27-0950 |
SPACER Price: $29.99 |
| 40 |
72-9210 |
DISCONTINUED Price: Call Us |
| 41 |
40-6400 |
SHAFT-ROLLER Price: $38.99 |
| 42 |
57-0690 |
PIN-SPECIAL Price: $3.66 |
| 43 |
29-4820 |
ROLLER Price: $14.88 |
| 44 |
3211-8 |
SCREW-HH Price: $3.50 |
| 45 |
587016401 |
WASHER.3/8ID.2-3/8OD.12GA.PLTD Price: $2.99 |
| 45 |
65-5950 |
BUSHING-PULLEY Price: $4.44 |
| 46 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 47 |
3211-15 |
SCREW-HH Price: $7.99 |
| 48 |
13-3949 |
DEFLECTOR ASM Price: $214.07 |
| 49 |
67-5360 |
DECAL-DANGER Price: $14.99 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532197246 |
BRKT.UPSTOP.GT/LT.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 585338801. Price: $14.99 |
| 75 |
587738906 |
KIT.SRVC.STEERINGSHAFT.PINION This part replaces 580683701. Price: $4.99 |
| 76 |
580683601 |
SCREW HEAD SOCKET LRVB Price: $2.99 |
| 122 |
583576601 |
CAP.GEAR.SECTOR.TEX This part replaces 532444962. Price: $4.99 |
