| Ref | Part Number | Description |
|---|
| 1 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 1 |
532180375 |
Rail, Kit RH Price: $59.99 |
| 2 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 2 |
532175282 |
Drawbar, Gt Price: $55.99 |
| 3 |
49-6440-03 |
PEDAL-FORWARD Price: $84.90 |
| 4 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 5 |
532196091 |
DASH, STEALTH This part replaces 532196136. Price: $116.99 |
| 5 |
75-2970 |
PEDAL-TRACTION Price: $135.64 |
| 6 |
5321578-82 |
Dash, 1PCS, Lower Price: $29.99 |
| 6 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 7 |
539990071 |
HCS.1/4-20.X1/2 This part replaces 817720408. Price: $1.99 |
| 7 |
75-6550 |
DISC-FRICTION Price: $7.96 |
| 8 |
532185518 |
KIT, SUPPORT, BATTERY This part replaces 532184668. Price: $28.65 |
| 8 |
75-6490 |
LEVER ASM Price: $78.45 |
| 9 |
233-42 |
KNOB Price: $12.88 |
| 11 |
112-5084 |
BRACKET-LEVER This part replaces 75-6510. Price: $61.39 |
| 12 |
75-6580 |
CABLE-PEDAL Price: $34.72 |
| 13 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 14 |
3272-2 |
PIN-COTTER Price: $2.29 |
| 14 |
532188208 |
HOOD.ASM.STEALTH.STV.2004 This part replaces 532190055. Price: $134.99 |
| 15 |
3290-461 |
WASHER-SPRING Price: $3.89 |
| 15 |
532161841 |
Lens LH Price: $20.99 |
| 16 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 16 |
532121794 |
Cover, Access Price: $3.99 |
| 17 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 17 |
817000612 |
Screw, 3/8-16 x 3/4 Price: $2.99 |
| 18 |
256-236 |
BEARING-MOUNT, FLANGE Price: $27.99 |
| 18 |
532182873 |
Grille Price: $140.99 |
| 19 |
322-3 |
SCREW-HH Price: $0.79 |
| 20 |
874780616 |
Bolt, Fin Hex 3/8-16 x 1 Price: $3.99 |
| 20 |
93-8742 |
FOOTPAD-BRAKE Price: $27.95 |
| 21 |
873680600 |
Nut This part replaces 873800600. Price: $1.99 |
| 23 |
63-7880 |
PIN-LATCH, BRAKE Price: $6.04 |
| 24 |
532182508 |
FOOTREST.RH This part replaces 532181058. Price: $17.99 |
| 24 |
63-7733 |
LH BRAKE CABLE ASM Price: $210.39 |
| 25 |
532161842 |
Lens RH Price: $44.99 |
| 25 |
63-7732 |
RH BRAKE CABLE ASM Price: $210.39 |
| 26 |
3256-69 |
WASHER-FLAT Price: $0.62 |
| 27 |
32121-16 |
PIN-SPRING Price: $0.41 |
| 28 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 28 |
532182507 |
FOOTREST.LH This part replaces 532181057. Price: $17.99 |
| 29 |
75-1440-03 |
PEDAL-BRAKE, LH Price: $207.74 |
| 30 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 30 |
532145052 |
Saddle Price: $4.99 |
| 31 |
32121-50 |
PIN-SPRING Price: $1.21 |
| 31 |
532161419 |
Bracket Supt 1-pc Vgt Steering Price: $4.99 |
| 32 |
532161327 |
Bracket, Frame Pivot Lh Price: $4.99 |
| 32 |
75-1430 |
RH BRAKE PEDAL ASM Price: $255.51 |
| 33 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 33 |
532161326 |
Bracket, Frame Pivot Rh Price: $3.99 |
| 34 |
532177018 |
Plate Asm Engine Chassis Price: $26.99 |
| 34 |
75-3270-03 |
HUB-PIVOT, TRACTION Price: $144.73 |
| 35 |
75-1470 |
PIN-PIVOT, BRAKE Price: $45.68 |
| 36 |
532171877 |
Bolt 5/16-18 unc x 3/4 This part replaces 817060512. Price: $3.99 |
| 36 |
75-2170-03 |
TUBE-CONTROL, PUMP Price: $103.73 |
| 37 |
3220-3 |
NUT-HJ Price: $0.28 |
| 37 |
532196023 |
KIT FENDER.YTGT.W/S.ORANGE This part replaces 532194879. Price: $147.99 |
| 38 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 39 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 39 |
532175278 |
Bracket, Axle Front Price: $8.99 |
| 40 |
323-9 |
SCREW-HH Price: $1.29 |
| 43 |
532136939 |
Bracket, Spnsn Front Lh Price: $11.99 |
| 44 |
532136940 |
Bracket, Spnsn Front Rh Price: $11.99 |
| 45 |
532187270 |
Bracket, Susp Arm Price: $5.99 |
| 47 |
817490608 |
Screw Thdrol 3/8-16 x 1/2 Price: $3.99 |
| 50 |
532175476 |
Bracket, Chassis Front Price: $12.99 |
| 56 |
532176016 |
Bracket Asm., Susp Chassis Lh Price: $8.99 |
| 58 |
532183569 |
Bracket Asm., Fender Price: $9.99 |
| 68 |
817490508 |
Screw, Hex Washer Head Threaded, Rolling 5/16-18 x 1/2 Price: $3.99 |
| 84 |
532188164 |
Upstop 54" Price: $9.99 |
| 86 |
874780716 |
Bolt, Fin Hex 7/16-14 unc Price: $2.99 |
| 91 |
532180374 |
Rail, Kit Lh Price: $57.99 |
| 99 |
532177143 |
Rod Asm. Bypass Price: $14.99 |
| 122 |
532192512 |
Screw Hex WSHD 8-18 x 7/8 Price: $2.99 |
| 130 |
532416358 |
SCREW, NO. 10 This part replaces 532191611. Price: $2.99 |
| 138 |
532191121 |
CUPHOLDER.TWIST.LOCK.GREY This part replaces 532194880. Price: $5.99 |
| 139 |
532179032 |
BOLT SHOULDER This part replaces 532171873. Price: $3.99 |
| 142 |
532161897 |
Bracket Dash Stealth RH Price: $4.99 |
| 143 |
532177586 |
Skirt Grille RH Price: $24.99 |
| 144 |
532161900 |
Bracket Dash Stealth LH Price: $4.99 |
| 146 |
532177587 |
Skirt Grille LH Price: $23.99 |
| 148 |
532164655 |
Extrusion Bumper Price: $4.99 |
| 150 |
532190309 |
Duct Heat Hood Price: $27.99 |
| 152 |
532177956 |
Shield, Browning Price: $26.99 |
| 153 |
532188212 |
Lightbox Asm. Price: $83.99 |
| 156 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $2.49 |
| 158 |
817670608 |
Screw 3/8-16 x 1/2 Price: $2.99 |
| 159 |
817000612 |
Screw Hexwsh Thdr. 3/8-16 x 3/4 Price: $2.99 |
| 161 |
532181787 |
Cosole Fuel Window Price: $17.99 |
| 162 |
532142432 |
Screw 1/4-1/2 Unc Price: $3.99 |
| 165 |
532183554 |
Bracket Support Tank Price: $64.99 |
| 166 |
873680700 |
Nut, Lock Hex 7/16-14 unc Price: $2.99 |
| 167 |
532184672 |
Bushing Snap Nylon 1.250 Price: $2.99 |
| 169 |
532188598 |
Bracket Price: $6.99 |
