| Ref | Part Number | Description |
|---|
| 1 |
66-6370 |
LIFT ARM ASM Price: $430.43 |
| 2 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 2 |
532183567 |
CABLE.ENGINE BRAKE.MZR Price: $14.99 |
| 3 |
32136-2 |
NUT-SHH Price: $3.55 |
| 3 |
532850733 |
BRACKET.UPSTOP This part replaces 532125162. Price: $4.99 |
| 4 |
21-3020-01 |
MOUNT-BALLJOINT, RH This part replaces 21-3020. Price: $178.87 |
| 4 |
532166649 |
PLUG.MULCH.22RD Price: $27.99 |
| 5 |
21-1830 |
SPRING-EXTENSION Price: $34.62 |
| 5 |
532007192 |
WIRE TIE This part replaces 532066426. Price: $7.99 |
| 6 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 6 |
532185577 |
HANDLE.KNOB.BLACK This part replaces 532191856. Price: $7.99 |
| 7 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 7 |
532750634 |
SCREW Price: $2.99 |
| 8 |
3217-8 |
NUT-HEX Price: $1.34 |
| 8 |
532187940 |
BAIL.DSTRT.FL.AW.ORANGE This part replaces 532190620. Price: $17.99 |
| 9 |
66-7150 |
ARM-PUSH, RH Price: $536.26 |
| 10 |
3272-24 |
PIN-COTTER Price: $0.54 |
| 10 |
532128415 |
RIVET BLIND Price: $3.99 |
| 11 |
24-9510 |
PIN Price: $77.49 |
| 11 |
532150050 |
SCREW.HXTAP.10-24 Price: $2.99 |
| 12 |
532054583 |
SCREW Price: $4.99 |
| 12 |
55-4300 |
DECAL-WARNING Price: $13.99 |
| 13 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 13 |
532150182 |
CAP.HUB.ARC.SPOKE.8".LP This part replaces 532180626. Price: $3.99 |
| 14 |
46-8840-01 |
SPRING-LIFT ARM This part replaces 46-8840. Price: $35.71 |
| 14 |
532195622 |
PLATE.BACK.22.RD/VE/STD This part replaces 532197076. Price: $12.99 |
| 15 |
5-1754 |
WASHER-FLAT Price: $2.17 |
| 15 |
532138860 |
SIDE BAFFLE Price: $3.16 |
| 16 |
256-126 |
BUSHING Price: $9.36 |
| 16 |
532176655 |
BAFFLE.DISCHRG.22RD.VE.N/SLOTS This part replaces 532177133. Price: $8.99 |
| 17 |
3272-33 |
PIN-COTTER Price: $0.54 |
| 17 |
532140661 |
BAFFLE.REAR.HSG.ASM.QT.22.BLAC This part replaces 532148941. Price: $6.99 |
| 18 |
23-1950-01 |
SUPPORT-REINFORCEMENT This part replaces 23-1950. Price: $69.64 |
| 18 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532132004. Price: $1.99 |
| 19 |
324-4 |
SCREW-HH Price: $0.95 |
| 19 |
586122501 |
KIT.ROPE.GUIDE.T-KNOB This part replaces 532179585. Price: $7.99 |
| 20 |
3-7292 |
PIN-CLEVIS Price: $44.11 |
| 20 |
532413160 |
SKIRT.REAR.22RD/SD.FO/VE This part replaces 532189008. Price: $11.99 |
| 21 |
5-3126 |
PIN-LYNCH Price: $0.73 |
| 21 |
532170938 |
DOOR SPRING LH Price: $4.99 |
| 22 |
3241-7 |
SCREW-SQH This part replaces 324-12. Price: $3.39 |
| 24 |
21-2860-01 |
PUSH ARM BRACKET ASM This part replaces 21-2860. Price: $154.46 |
| 24 |
532170939 |
DOOR SPRING RH Price: $5.99 |
| 25 |
32121-84 |
PIN-SPIRAL Price: $1.29 |
| 25 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532083923. Price: $3.99 |
| 26 |
21-2990 |
SHAFT-PIVOT Price: $227.21 |
| 26 |
532184193 |
BOLT Price: $4.99 |
| 27 |
32128-42 |
NUT-HF Price: $0.98 |
| 27 |
532150339 |
WHEEL.8X2.PR.LP.RADII.BLK Price: $32.99 |
| 28 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 28 |
532174719 |
BOLT SHOULDER 3/8 -16X1 This part replaces 532142748. Price: $7.99 |
| 29 |
21-2960 |
ARM-PUSH, LH Price: $519.38 |
| 29 |
532062335 |
WASHER.BELLEVILLE (3 2 LB) Price: $7.99 |
| 30 |
21-2900-01 |
SPRING-TORSION, LH This part replaces 21-2900. Price: $566.83 |
| 30 |
532145935 |
ARM.AXLE.ASM.BZP This part replaces 532149857. Price: $4.99 |
| 31 |
21-2890-01 |
SPRING-TORSION, RH This part replaces 21-2890. Price: $566.83 |
| 31 |
532196401 |
KNOB.DELUXE.GRAY Price: $3.99 |
| 32 |
21-3050-01 |
LH BALL JOUNT MOUNT ASM This part replaces 21-3050. Price: $153.41 |
| 32 |
532401621 |
SPRING.SELECTOR.5POS.BZP This part replaces 532141730. Price: $4.99 |
| 33 |
532197029 |
DOOR.MULCH.22.REAR.FWGD.GREY Price: $11.99 |
| 33 |
86-8100-01 |
BALL JOINT ASM This part replaces 86-8100. Price: $137.53 |
| 34 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 34 |
532401629 |
SPACER.HEIGHT.ADJUSTER This part replaces 532146630. Price: $3.99 |
| 35 |
21-3000-01 |
NUT-JAM, PUSH ARM This part replaces 21-3000. Price: $37.02 |
| 35 |
532407492 |
BRACKET.ADJ.5.IDL.RTAB.ADS This part replaces 532140996. Price: $3.99 |
| 36 |
3-1365 |
CHAIN Price: $72.97 |
| 36 |
532175735 |
BRACKET.ASM.HINGE.21.FWGD. Price: $4.99 |
| 37 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532150078. Price: $4.99 |
| 37 |
68-3270 |
BUMPER-RUBBER This part replaces 67-9800. Price: $37.99 |
| 38 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 38 |
532402574 |
DEFLECTOR.CLIPPING.22.FGD.BLAC This part replaces 532197030. Price: $10.99 |
| 39 |
5-2942 |
SHACKLE Price: $16.99 |
| 39 |
532195916 |
BRKT.ASM.HANDLE.LT This part replaces 532197028. Price: $8.99 |
| 40 |
532195917 |
BRKT.ASM.HANDLE.RT.BLACK This part replaces 532197027. Price: $8.99 |
| 41 |
532150406 |
BOLT 3/8-16X1-1/8 Price: $4.99 |
| 42 |
532193000 |
SPRING.TORSION Price: $5.99 |
| 43 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 45 |
532175650 |
ROD.HINGE.21 Price: $4.99 |
| 46 |
532443950 |
KIT.BLADE.ADAPTOR.BELT.GUIDE. This part replaces 532194037. Price: $49.99 |
| 47 |
532141114 |
BLADE 22" Price: $24.99 |
| 48 |
532851074 |
WASHER,HARDEN Price: $3.99 |
| 49 |
596238701 |
Washers This part replaces 532850263. Price: $3.99 |
| 50 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 51 |
532170031 |
FRONT BAFFLE KIT Price: $22.99 |
| 52 |
581579101 |
DECAL.CUTFINGER.CE.02 This part replaces 532107339. Price: $3.99 |
| 53 |
817600406 |
SCREW 1/4X20 Price: $2.99 |
| 55 |
596322601 |
Nuts This part replaces 532751592. Price: $2.99 |
| 56 |
532088652 |
HINGE SCREW Price: $3.99 |
| 57 |
532051793 |
HAIRPIN COTTER Price: $5.99 |
| 58 |
532151590 |
HANDLE.LOWR.DLX.20RD.CLIP.BLAC This part replaces 532153406. Price: $19.99 |
| 59 |
532191574 |
BOLT, HANDLE 5/16-18X1.75 Price: $5.99 |
| 62 |
532413032 |
KIT.SHIELD.DEBRIS.TORUS. This part replaces 532197153. Price: $19.99 |
| 63 |
532192325 |
SCREW.HEX.WSH Price: $4.99 |
| 67 |
532195504 |
CLIP.WIREFORM.PACKAGIN Price: $6.99 |
| 68 |
532407493 |
WHEEL ADJUSTING BRACKET LH This part replaces 532140836. Price: $3.99 |
| 69 |
532197991 |
CLIP.CABLE.BLK This part replaces 532192770. Price: $3.99 |
| 70 |
532182748 |
GRIP.HANDLE.FOAM.WIDE.(1 SIDE) Price: $7.99 |
| 71 |
532188839 |
BRACKET.DEBRIS.SHIELD.BZP This part replaces 532190939. Price: $4.99 |
| 72 |
532182227 |
SCREW.#8.MACH Price: $3.99 |
| 73 |
532197162 |
KEEPER.BELT.FGD Price: $2.99 |
| 74 |
532182228 |
NUT.HEX.#8 Price: $4.99 |
