| Ref | Part Number | Description |
|---|
| 1 |
138-1921 |
HOUSING-LOWER This part replaces 110-3071. Price: $1,467.48 |
| 2 |
149723 |
Muffler Price: Call Us |
| 3 |
21-8270 |
PIN-DOWEL Price: $6.65 |
| 4 |
72-9420 |
VENT Price: $6.85 |
| 5 |
94-6934 |
SCREW-HH Price: $6.99 |
| 6 |
24-8840 |
RING-RETAINING, WHEEL BEARING Price: $37.15 |
| 7 |
99-6969 |
SEAL-OIL, WHEEL END This part replaces 92-1774. Price: $14.71 |
| 8 |
21-8180 |
BEARING ASM Price: $65.11 |
| 9 |
194319 |
Keeper Belt Engine Price: Call Us |
| 9 |
28-0670 |
SEAL-GREASE Price: $19.74 |
| 12 |
110-3072 |
DRUM-BRAKE Price: $431.48 |
| 12 |
405140 |
Pulley Engine Price: Call Us |
| 13 |
106-9205 |
STUD-WHEEL Price: $7.80 |
| 14 |
110-3073 |
SHAFT-AXLE, RH Price: $863.09 |
| 15 |
110-3074 |
SHAFT-AXLE, LH Price: $863.09 |
| 15 |
400021 |
Tank Fuel 3.0 Price: Call Us |
| 18 |
121-4698 |
NUT-KEPS This part replaces 32149-5. Price: $1.15 |
| 18 |
195951 |
Cap Asm Price: Call Us |
| 19 |
3210-8 |
SCREW-HH Price: $1.02 |
| 20 |
110-4136 |
DIFFERENTIAL CASE ASM This part replaces 110-3075. Price: $796.59 |
| 20 |
175437X428 |
Control Throttle Price: Call Us |
| 21 |
191611 |
Screw 10 x 3/4 Single Lead-Hex Price: Call Us |
| 21 |
254-65 |
BEARING-ROLLER, CONE Price: $62.13 |
| 22 |
187767X428 |
Control Choke Price: Call Us |
| 22 |
254-66 |
CUP-BEARING, ROLLER Price: $17.92 |
| 23 |
21-8090 |
SHIM-BEARING, DIFFERENTIAL (.003) Price: $1.09 |
| 23 |
21-8100 |
SHIM-BEARING, DIFFERENTIAL (.005) Price: $3.46 |
| 23 |
21-8110 |
SHIM-BEARING, DIFFERENTIAL (.010) Price: $3.73 |
| 23 |
21-8120 |
SHIM-BEARING, DIFFERENTIAL (.030) Price: $5.43 |
| 24 |
93-3618 |
GEAR AND PINION ASM This part replaces 92-1676. Price: $1,107.66 |
| 25 |
21-7770 |
SCREW-GEAR, DRIVE Price: $1.97 |
| 26 |
92-1773 |
SCREW-HHF Price: $3.05 |
| 28 |
110-3076 |
CARRIER ASM Price: $1,291.10 |
| 28 |
401135 |
Fuel Line Price: Call Us |
| 29 |
137180 |
Spark Arrester Kit Price: Call Us |
| 29 |
43-6760 |
BEARING-ROLLER, CONE TAPER Price: $113.20 |
| 30 |
43-6750 |
BEARING-TAPER, CUP Price: $69.64 |
| 31 |
43-6710 |
SHIM-PINION (.003) Price: $2.17 |
| 31 |
43-6711 |
SHIM-PINION (.005) Price: $3.80 |
| 31 |
43-6712 |
SHIM-PINION (.010) Price: $3.19 |
| 31 |
43-6713 |
SHIM-PINION (.030) Price: $6.99 |
| 32 |
21-8020 |
SPACER-BEARING Price: $28.84 |
| 33 |
254-90 |
BEARING-CUP Price: $11.29 |
| 34 |
254-91 |
CONE-BEARING Price: $18.65 |
| 35 |
72-3572 |
SHIM-BEARING, FRONT (.098) This part replaces 72-3570. Price: $23.68 |
| 35 |
72-3573 |
SHIM-BEARING, FRONT (.100) Price: $24.63 |
| 35 |
72-3574 |
SHIM-BEARING, FRONT (.102) Price: $23.68 |
| 35 |
72-3575 |
SHIM-BEARING, FRONT (.104) Price: $22.53 |
| 35 |
72-3576 |
SHIM-BEARING, FRONT (.106) Price: $23.68 |
| 35 |
72-3577 |
SHIM-BEARING, FRONT (.108) Price: $22.53 |
| 35 |
72-3578 |
SHIM-BEARING, FRONT (.110) Price: $22.53 |
| 35 |
72-3580 |
SHIM-BEARING, FRONT (.112) Price: $22.53 |
| 35 |
72-3581 |
SHIM-BEARING, FRONT (.114) Price: $22.53 |
| 35 |
72-3582 |
SHIM-BEARING, FRONT (.116) Price: $22.53 |
| 35 |
72-3583 |
SHIM-BEARING, FRONT (.118) Price: $56.93 |
| 35 |
72-3584 |
SHIM-BEARING, FRONT (.120) Price: $24.63 |
| 35 |
72-3585 |
SHIM-BEARING, FRONT (.125) Price: $22.53 |
| 35 |
72-3586 |
SHIM-BEARING, FRONT (.127) Price: $22.53 |
| 35 |
72-3587 |
SHIM-BEARING, FRONT (.129) Price: $23.68 |
| 35 |
72-3588 |
SHIM-BEARING, FRONT (.131) Price: $22.53 |
| 35 |
72-3590 |
SHIM-BEARING, FRONT (.133) Price: $22.53 |
| 35 |
72-3591 |
SHIM-BEARING, FRONT (.135) Price: $21.44 |
| 35 |
72-3592 |
SHIM-BEARING, FRONT (.137) Price: $22.53 |
| 35 |
72-3593 |
SHIM-BEARING, FRONT (.139) Price: $23.68 |
| 35 |
72-3594 |
SHIM-BEARING, FRONT (.141) Price: $23.68 |
| 35 |
72-3595 |
SHIM-BEARING, FRONT (.143) Price: $22.53 |
| 35 |
72-3596 |
SHIM-BEARING, FRONT (.145) Price: $22.53 |
| 35 |
72-3597 |
SHIM-BEARING, FRONT (.147) Price: $22.53 |
| 35 |
72-3598 |
SHIM-BEARING, FRONT (.149) Price: $24.63 |
| 35 |
72-3600 |
SHIM-BEARING, FRONT (.151) Price: $23.68 |
| 36 |
71-4330 |
SEAL Price: $36.26 |
| 37 |
123487X |
Clamp Hose Price: Call Us |
| 37 |
68-7010 |
FLANGE Price: $306.32 |
| 38 |
71-4340 |
WASHER Price: $15.47 |
| 39 |
71-4350 |
NUT Price: $3.46 |
| 40 |
86-7230 |
GEAR-INPUT, TRANSMISSION Price: $610.12 |
| 42 |
10040700 |
Washer Lock 7/16 Price: Call Us |
| 42 |
21-7830 |
COVER-GEAR Price: $26.87 |
| 43 |
12-5450 |
SCREW Price: $7.99 |
| 44 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 45 |
73510400 |
Nut Keps Hex 1/4-20 unc Price: Call Us |
| 62 |
146629 |
Shield Heat Muffler Price: Call Us |
| 69 |
165391 |
Gasket Price: Call Us |
| 70 |
159955 |
Exhaust Tube RH Price: Call Us |
| 71 |
160589 |
Exhaust Tube LH Price: Call Us |
| 79 |
183906 |
Screw Socket Head 5/16-18 x 1 Price: Call Us |
| 81 |
148456 |
Tube Drain Oil Easy Price: Call Us |
| 82 |
181654 |
Plug Drain Oil Price: Call Us |
| 84 |
17060620 |
Screw 3/8-16 x 1-1/4 Price: Call Us |
| 85 |
173937 |
Bolt Hex 7/16-20 x 4 x 5 Ga.-1.5 Price: Call Us |
| 87 |
171877 |
Bolt 5/16-18 x 3/4 Price: Call Us |
