| Ref | Part Number | Description |
|---|
| 0 |
640225A |
CARBURETOR Price: $78.00 |
| 1 |
532159460 |
WIRE ASM INNER W/ PLUNGER LT Price: $8.99 |
| 1 |
631255 |
SHAFT & LEV Price: $6.36 |
| 1 |
ZNK1L000U |
HEX.DOME NUT M12 Price: $1.88 |
| 2 |
532159471 |
SHAFT ASM R HANDLE Price: $39.99 |
| 2 |
631767 |
SPRING Price: $1.25 |
| 2 |
ZNL1L000U |
HEX LOCKNUT M12 Price: $1.44 |
| 3 |
532105767 |
PIN GROOVE. Price: $2.99 |
| 3 |
876064W |
ROLLER MOUNTING W/A Price: $91.66 |
| 4 |
10-11-017 |
GREASE NIPPLE 1/8BSP STR Price: $1.44 |
| 4 |
631184 |
WASHER Price: $1.25 |
| 4 |
812000002 |
RETAINING RING LT Price: $3.99 |
| 5 |
631183 |
WASHER Price: $1.25 |
| 5 |
819211621 |
WASHER Price: $3.99 |
| 5 |
876099 |
DISC SPRING DIA 25* DIA 12,2*1,5MMTHK Price: $1.40 |
| 6 |
532120183 |
BEARING.NYLON Price: $2.99 |
| 6 |
63-01-960 |
REAR ROLLER ADJUSTING STUD Price: $28.47 |
| 6 |
631036 |
SHUTTER Price: $1.20 |
| 7 |
111-9450 |
SHAFT-ADJUSTER, ROLLER This part replaces 876027. Price: $63.35 |
| 7 |
532125631 |
GRIP HANDLE Price: $3.99 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
532170770 |
Price: Call Us |
| 8 |
63-02-123 |
REAR ROLLER ADJ SPACER Price: $10.76 |
| 10 |
631605 |
SHAFT & LEV Price: $7.84 |
| 10 |
876062 |
NUT ROLLER Price: $11.05 |
| 11 |
532145537 |
LIFT LINK LH This part replaces 532139865. Price: $14.99 |
| 11 |
632042 |
SPRING Price: $3.00 |
| 12 |
532145536 |
LIFT LINK RH This part replaces 532139866. Price: $7.99 |
| 12 |
876006 |
SMOOTH ROLLER (SERVICEABLE) Price: $153.04 |
| 13 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 13 |
876098 |
CAP PRESSURE CONTROL Price: $8.40 |
| 14 |
31837 |
SHUTTER Price: $1.18 |
| 14 |
63-07-072 |
SCRAPER WIRE Price: $17.04 |
| 15 |
532173288 |
LINK.SUSPENSION.FRONT Price: $8.99 |
| 15 |
630735 |
SPRING Price: $1.25 |
| 15 |
876013W |
HANDWHEEL Price: $18.57 |
| 16 |
09730 |
PIN SPIROL Price: $1.42 |
| 16 |
632164 |
FUEL FITTING Price: $5.95 |
| 16 |
873350800 |
NUT.HEX.JAM.1/2-13 Price: $1.99 |
| 17 |
651025 |
SCREW Price: $1.18 |
| 17 |
876034 |
DISC SPRING Price: $1.65 |
| 18 |
214053 |
DECAL HEIGHT OF CUT Price: $1.63 |
| 18 |
539101331 |
NUT 1/2-13 HEX NYLOC ZD This part replaces 873800800. Price: $1.99 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 19 |
532139868 |
ARM.REAR.SUSPENSION Price: $11.99 |
| 19 |
631201 |
CHECK VALVE Price: $15.40 |
| 19 |
876082 |
BEARING Price: $5.65 |
| 20 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $1.99 |
| 20 |
631562 |
ADJ SCREW Price: $3.74 |
| 20 |
876047 |
TRUNNION Price: $32.01 |
| 21 |
630738 |
SPRING Price: $1.25 |
| 21 |
876085 |
SLEEVE ADJUSTER Price: $31.75 |
| 22 |
630739 |
WASHER Price: $1.25 |
| 22 |
876003 |
SPRING COMPRESSION Price: $2.52 |
| 23 |
532110807 |
NUT T Price: $3.99 |
| 23 |
630740 |
O RING Price: $1.49 |
| 23 |
876053 |
CAGE BACKLASH Price: $20.69 |
| 24 |
819131016 |
WASHER This part replaces 532067510. Price: $3.99 |
| 24 |
876054 |
NUT BACKLASH Price: $13.28 |
| 25 |
532002876 |
SPRING Price: $3.99 |
| 25 |
876004 |
SWING BOLT Price: $21.66 |
| 26 |
532169484 |
RETAINER CLIP Price: $4.99 |
| 26 |
876035 |
BEARING Price: $3.25 |
| 27 |
09599 |
WASHER Price: $1.42 |
| 27 |
532126971 |
ROD ADJ LIFT Price: $4.99 |
| 28 |
09454 |
NUT M12 PLAIN HEX PLATED Price: $1.36 |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $3.99 |
| 29 |
532138057 |
KNOB INF 3/8-16 Price: $5.99 |
| 29 |
876022 |
PIN PIVOT Price: $8.77 |
| 30 |
532150233 |
TRUNNION Price: $7.99 |
| 30 |
876009W |
COUNTERWEIGHT Price: $44.64 |
| 31 |
532169865 |
BEARING.PIVOT.LIFT Price: $3.99 |
| 31 |
ZWQ1J000U |
PLAIN HEAVY WASHER M10 Price: $1.38 |
| 32 |
09480 |
WASHER M10 SC SPRING Price: $1.36 |
| 32 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $1.99 |
| 33 |
ZCS1J030U |
SOC.HD.CAP Price: $1.31 |
| 34 |
876032 |
O RING Price: $1.65 |
| 35 |
63-07-008 |
CIRCLIP INTERNAL 52DIA Price: $2.55 |
| 36 |
532155097 |
POINTER, HEIGHT INDICATOR Price: $3.99 |
| 36 |
63-07-036 |
BEARING Price: $9.69 |
| 37 |
532123935 |
PLUG,HOLE Price: $3.99 |
| 37 |
63-07-038 |
SEAL DOUB.LIP 30*52*10W Price: $10.87 |
| 38 |
817060516 |
SCREW 5/16-18X1 Price: $3.99 |
| 38 |
876007W |
CASTING BEARING Price: $128.11 |
| 39 |
134-0498 |
REEL-8 IN,6 BLD,LH HELIX This part replaces 111-3415. Price: $381.94 |
| 40 |
640223 |
RESTRICTOR Price: $3.86 |
| 40 |
819112410 |
WASHER Price: $3.99 |
| 40 |
ZNB1J000U |
M10 BINX SELF LOCKING NUT Price: $1.27 |
| 40A |
640053 |
CAP Price: $0.81 |
| 41 |
532155098 |
IND. HEIGHT STLT Price: $3.99 |
| 41 |
63-11-019 |
HEX HD SCREW(DURLOCK) M10X16 Price: $2.47 |
| 44 |
63-13-039 |
DECAL HEIGHT OF CUT ADJ Price: $1.44 |
| 45 |
40-07-017 |
CIRCLIP EXT.25MM DIA Price: $1.40 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 48 |
632554 |
WELCH PLUG Price: $1.17 |
| 48 |
ZNN1J000U |
HEX.NUT NYLOC M10 Price: $1.42 |
| 49 |
09479 |
WASHER M10 X 21 X 1.45 THK (P) Price: $1.39 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $2.99 |
| 50 |
630978 |
DIAPHRAGM Price: $4.49 |
| 51 |
09438 |
NUT M6 X 1.5 PLAIN Price: $1.39 |
| 51 |
630750A |
GASKET Price: $3.00 |
| 52 |
631653 |
COVER Price: $7.61 |
| 52 |
ZDH1L016U |
HEX HD.SET SCW.M12*16 Price: $1.35 |
| 53 |
650545 |
SCREW Price: $1.20 |
| 53 |
876069 |
PIN BEARING ADJUSTER Price: $26.70 |
| 55 |
09362 |
SCREW M6 X 16 HEX HD ZINC Price: $1.42 |
| 55 |
630932A |
INLET NEEDLE Price: $4.39 |
| 56 |
09738 |
BOLT CARRIAGE Price: $1.42 |
| 56 |
630742 |
GASKET Price: $1.25 |
| 57 |
631049 |
SPRING Price: $1.20 |
| 58 |
HY4200 |
WASHER Price: $1.34 |
| 59 |
ZNB1L000U |
HEX.NUT M12 BINX Price: $1.59 |
| 60 |
631893A |
REPAIR KIT This part replaces 631893. Price: $16.83 |
| 60 |
ZWP1L000U |
PLAIN WASHER M12 Price: $1.44 |
| 62 |
876065 |
BUSH Price: $8.47 |
| 65 |
876060W |
BOTTOM BLADE ASSY Price: $280.94 |
| 66 |
922115W |
CASTING-PIVOT, FIXED Price: $121.27 |
| 67 |
ZDH1P050U |
SETSCREW M16*50 Price: $1.35 |
| 68 |
09598 |
SETSCREW HEX.HD. Price: $1.44 |
| 69 |
HY09485 |
WASHER M12 PLAIN Price: $1.40 |
| 70 |
40-13-010 |
DECAL - C/HEAD MIND TOES&FING Price: $1.44 |
| 71 |
340154 |
BUSHING Price: $4.85 |
