| Ref | Part Number | Description |
|---|
| 1 |
22-8330 |
PLUG Price: $64.59 |
| 2 |
237-42 |
O-RING Price: $2.78 |
| 2 |
539112170 |
MANDREL.DECK.ASSEMBLY Price: $69.99 |
| 3 |
22-8340 |
SPRING Price: $19.09 |
| 3 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 4 |
22-8350 |
BALL Price: $12.28 |
| 4 |
532174375 |
PULLEY.DRIVEN.DECK.48' Price: $34.99 |
| 5 |
22-8370 |
SEAT-VALVE Price: $88.05 |
| 5 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 6 |
22-8360 |
PIN Price: $43.02 |
| 7 |
121-9070 |
VALVE ASM This part replaces 43-1730. Price: $458.43 |
| 7 |
539110732 |
DISCHARGE CHUTE 48" Price: $44.99 |
| 8 |
22-8420 |
SPOOL Price: $437.22 |
| 8 |
596646001 |
Springs This part replaces 539110735. Price: $3.99 |
| 9 |
595935501 |
Pins This part replaces 539110736. Price: $2.99 |
| 10 |
22-8380 |
RETAINER Price: $17.86 |
| 10 |
539113425 |
BLADE, 16-1/4" Price: $19.99 |
| 11 |
22-8410 |
SPRING Price: $17.61 |
| 11 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 12 |
22-8390 |
RETAINER Price: $56.56 |
| 12 |
539113427 |
CONFINEMENT PLATE 48" BLK Price: $32.99 |
| 13 |
22-8400 |
SPACER Price: $42.41 |
| 13 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110505. Price: $2.99 |
| 14 |
22-8480 |
RING-SNAP Price: $49.87 |
| 14 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 15 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 17 |
532196104 |
PULLEY.IDLER.MWR.STATI.LH Price: $37.99 |
| 18 |
574827102 |
ARM, IDLER, BLK Price: $27.99 |
| 19 |
532177968 |
PULLEY.IDLER.FLAT Price: $27.99 |
| 20 |
589766102 |
Pulleys This part replaces 539132728. Price: $27.99 |
| 21 |
575224501 |
BUSHING, IDLER Price: $27.99 |
| 22 |
532133957 |
WHEEL GAGE DONUT Price: $11.99 |
| 23 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 24 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 25 |
575224702 |
SHIELD.BELT.LH.ORANGE Price: $29.99 |
| 27 |
539104763 |
U-CLIP 5/16-18 NUT RETAINER Price: $4.99 |
| 28 |
539108271 |
HCS 3/8-16 X 3-1/2 GR5 ZD Price: $4.99 |
| 29 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 30 |
596433701 |
GSPW Washers This part replaces 819141614. Price: $2.99 |
| 31 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 32 |
539990923 |
RHSNB 3/8-16X1-3/4 Price: $2.99 |
| 33 |
596437601 |
Washers This part replaces 539104864. Price: $2.99 |
| 35 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 36 |
531169201 |
SERVICE KIT ARM ARM.SUSPENSION This part replaces 532195185. Price: $12.99 |
| 37 |
596241101 |
Bolts This part replaces 539113621. Price: $2.99 |
| 38 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 39 |
596230801 |
Nuts This part replaces 539200282. Price: $2.99 |
| 40 |
532176066 |
NOSE ROLLER 48" Price: $11.99 |
| 41 |
594092501 |
Rods This part replaces 532179127. Price: $5.99 |
| 42 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 43 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 44 |
575967202 |
SHIELD, BELT, RH 48 ORG Price: $34.99 |
| 45 |
596580801 |
Bolts This part replaces 874780516. Price: $2.99 |
| 46 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 539990187. Price: $2.99 |
| 50 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 51 |
596437001 |
Screws This part replaces 817490408. Price: $2.99 |
| 52 |
596435201 |
Bolts This part replaces 874780740. Price: $2.99 |
| 53 |
574845602 |
BELT, 135" EL Price: $79.99 |
| 54 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 55 |
596240801 |
GSPW Bolts This part replaces 539115574. Price: $3.99 |
| 57 |
596645601 |
Springs This part replaces 539106850. Price: $8.99 |
| 58 |
532110485 |
BEARING Price: $11.99 |
| 59 |
575352901 |
RP PULLEY, COLLECTION 48 Price: $54.99 |
| 60 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 61 |
596274401 |
Rods This part replaces 532400337. Price: $9.99 |
| 62 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 64 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $3.99 |
