Clutch / Drum & Oil Pump
Parts (42)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 70-6940 | SCREW Price: $20.10 |
| 2 | 70-4650 | PUMP SUB ASSEMBLY Price: $132.38 |
| 3 | 70-4630 | GASKET Price: $2.95 |
| 4 | 70-4620 | SPRING Price: $3.08 |
| 5 | 70-4610 | VALVE Price: $9.43 |
| 6 | 70-4760 | BLOCK Price: $13.13 |
| 7 | 70-4730 | TAPPET Price: $45.43 |
| 8 | 70-4740 | ROLLER Price: $11.58 |
| 9 | 70-6820 | RING Price: $3.25 |
| 10 | 70-4750 | PIN Price: $4.68 |
| 11 | 70-5700 | FUEL FEED PUMP This part replaces 70-4600. Price: $796.28 |
| 13 | 70-4790 | FILTER Price: $6.38 |
| 14 | 70-4800 | SCREW Price: $22.40 |
| 15 | 70-4780 | PLUG Price: $10.59 |
| 16 | 70-6700 | WASHER Price: $4.85 |
| 17 | 70-4770 | SPRING Price: $14.96 |
| 18 | 70-4720 | PISTON Price: $27.20 |
| 19 | 70-4660 | ROD BLUE Price: $7.73 |
| 501544102 | 501544102 | OIL SCREEN Price: $14.99 |
| 501893301 | 501893301 | OIL HOSE Price: $17.99 |
| 501893601 | 501893601 | SPRING Price: $3.92 |
| 501893702 | 501893702 | SPRING Price: $3.99 |
| 501897071 | 501897071 | OIL PUMP Price: $159.99 |
| 501897501 | 501897501 | BRACKET Price: $17.99 |
| 501897601 | 501897601 | SCREW Price: $3.86 |
| 501897801 | 501897801 | RECOIL SPRING Price: $3.99 |
| 501898702 | 501898702 | WIRE CPL Price: $24.99 |
| 503133701 | 503133701 | ARM Price: $15.98 |
| 503138401 | 503138401 | PUMP PLUNGER Price: $17.99 |
| 503139901 | 503139901 | SEALING Price: $4.99 |
| 503143204 | 503143204 | CLUTCH DRUM Price: $69.99 |
| 503144901 | 503144903 | CLUTCHES This part replaces 503144901. Price: $99.99 |
| 503145101 | 503145101 | CLUTCH SPRING Price: $7.99 |
| 503202620 | 503202620 | SCREW Price: $2.99 |
| 503230045 | 503230045 | WASHER Price: $2.99 |
| 503230058 | 503230058 | WASHER Price: $3.99 |
| 503253001 | 503253001 | SUPPORT BUSHING Price: $11.99 |
| 503260205 | 503260205 | SEALING RING Price: $11.99 |
| 503896201 | 503896201 | WHEEL Price: $54.99 |
| 723129151 | 723129151 | Screw Price: $1.06 |
| 723228485 | 723228485 | SCREW 4X5 Price: $2.99 |
| 740422200 | 740422200 | O-RING Price: $3.99 |
