| Ref | Part Number | Description |
|---|
| 1 |
51525900 |
KIT, ZOOM/ZT FRAME W/ DECALS Price: $540.95 |
| 2 |
03768600 |
FENDER, RH Price: $71.45 |
| 3 |
03768700 |
FENDER, LH Price: $59.95 |
| 4 |
07500125 |
RIVET, .25 NYLON PANEL Price: $0.95 |
| 5 |
03769053 |
PLATE, FENDER Price: $30.95 |
| 6 |
03368553 |
WMT, CASTER FORK Price: $66.45 |
| 7 |
07100124 |
TIRE/WHEEL ASSY, 11X4-5 Price: $72.95 |
| 8 |
05500934 |
BSHG-FLG 1.00X1.25X1.50X1.50 Price: $6.95 |
| 9 |
00278500 |
SPACER, ROLLED WHEEL Price: $13.95 |
| 10 |
05901907 |
BLT, HEX .50-13X6.50 GR5 ZCC This part replaces 05964400. Price: $6.95 |
| 12 |
04240751 |
WLDMNT, LH FENDER MOUNT Price: $75.45 |
| 13 |
06500907 |
NUT-LK-TOP-FLG .500-13 GF ZCC This part replaces 06543600. Price: $1.45 |
| 14 |
05901905 |
BLT, HEX .50-13X5.00 GR5 ZCC This part replaces 05962200. Price: $4.95 |
| 15 |
06401022 |
WSHR-FL-STL.511X1.44X.125ZC120 This part replaces 06436400. Price: $2.95 |
| 16 |
06500822 |
NUT-LK-TOP-FLG .38-16 ZC120 This part replaces 06542000. Price: $0.95 |
| 17 |
07056700 |
BOLT-SHLDR .375-16X.150 Price: $3.95 |
| 18 |
07503100 |
BUMPER GROMMET Price: $3.45 |
| 19 |
00363100 |
SPACER, CASTER .50X1.00X1.84 Price: $6.95 |
| 20 |
08553700 |
BSHG-SLV .391X.688X.52 PM Price: $5.45 |
| 21 |
06500809 |
NUT,NYL-FLG .31-18 GF ZCC This part replaces 06545400. Price: $1.45 |
| 22 |
06200307 |
BLT, RHSN .25-20X.750 G5 ZCC This part replaces 06219900. Price: $0.95 |
| 23 |
04085753 |
BRACE, HOOD Price: $30.45 |
| 24 |
06443300 |
WSHR-FL-NYL .518X1.000X.080 Price: $0.45 |
| 25 |
04411853 |
HOOD, ZT Price: $132.95 |
| 26 |
06200306 |
BLT, RHSN .25-20X.500 G5 ZCC This part replaces 06220600. Price: $0.95 |
| 27 |
06500813 |
NUT,NYL-FLG .25-20 GF ZCC This part replaces 06500012. Price: $1.45 |
| 28 |
07400122 |
SCR-TAP .25-20X.50 HWH ZCC This part replaces 07412000. Price: $0.45 |
| 29 |
06500903 |
NUT-LK-TOP-FLG .250-20 GF ZCC This part replaces 06543500. Price: $0.95 |
| 31 |
06500705 |
NUT-PUSH, .50 Price: $3.45 |
| 32 |
04400000 |
TANK, FUEL EXPANSION Price: $43.95 |
| 33 |
04082700 |
GROMMET, REMOTE VENT NITRILE Price: $3.45 |
| 35 |
07500206 |
BSHG-FLG .375X1.062X.625 NITR Price: $1.95 |
| 36 |
04382700 |
FITTING, STRAIGHT FUEL PLASTIC Price: $5.45 |
| 39 |
04082500 |
CARBON CANISTER, 300CC Price: $56.95 |
| 40 |
04086551 |
BRKT-MOUNT, CANISTER BBZ Price: $16.95 |
| 41 |
04102900 |
P-PLASTIC TIE STRAP LARGE Price: Call Us |
| 42 |
04097700 |
CLAMP-HOSE- SPRING .188 Price: $1.45 |
| 43 |
03278800 |
CLAMP, FUEL LINE Price: $0.95 |
| 44 |
06500810 |
NUT,NYL-FLG .50-13 GF ZCC This part replaces 06500010. Price: $1.45 |
| 45 |
06200330 |
BLT,RHSN .50-13X1.75 G5 ZCC This part replaces 06224800. Price: $5.45 |
| 46 |
04192901 |
TUBE, UPPER CONTROL PIVOT Price: $6.45 |
| 47 |
04188353 |
FOOTREST Price: $61.45 |
| 48 |
04097000 |
FITTING-3/16X1/4 90DEGREE VAC Price: $13.45 |
| 51 |
04192700 |
CUPHOLDER, SNAP-IN 3.75OD Price: $20.95 |
| 52 |
07500103 |
EDGING, CLUTCH PADDLE - 2.00" Price: Call Us |
| 53 |
06200232 |
BLT,RHSN .31-18X.75 G5 ZCC This part replaces 06215700. Price: $2.45 |
