| Ref | Part Number | Description |
|---|
| 2 |
983-05396 |
DECK BRAKE ASSEMBLY Price: $88.32 |
| 3 |
987-05169 |
IDLER PIVOT ASSEMBLY BRACKET Price: $40.16 |
| 5 |
710-0347 |
HEX SCREW 3/8-16 x 1.75 GR5 Price: $4.39 |
| 6 |
710-0376 |
SCREW 5/16-18 x 1.0 GR5 Price: $3.66 |
| 7 |
710-0521 |
SCREW 3/8-16 x 3 GR8 Price: $4.54 |
| 8 |
710-06133 |
SCREW M6-1 x .625 Price: $3.08 |
| 9 |
710-1260A |
SCREW 5/16-18 x .750 Price: $3.34 |
| 10 |
712-04063 |
FLANGE LOCK NUT 5/16-18 Price: $3.56 |
| 12 |
712-04217 |
FLANGE LOCK NUT Price: $3.75 |
| 13 |
712-05194 |
U NUT M6-1 Price: $3.33 |
| 14 |
714-04043 |
PIN:COTTER Price: $4.24 |
| 15 |
720-05010 |
VINYL CAP Price: $3.70 |
| 16 |
720-05150 |
HANDLE PLUG Price: $4.98 |
| 17 |
921-04041 |
WATER NOZZLE Price: $20.19 |
| 18 |
731-07487 |
DECK WASH NOZZLE Price: $3.86 |
| 20 |
732-05151A |
TORSION SPRING Price: $3.70 |
| 21 |
732-05520A |
EXTENSION SPRING (.750 DIA x 6.70 ) Price: $6.22 |
| 22 |
736-0227 |
WASHER:FLAT: .390 x 1.50 x .134 This part replaces 936-0227. Price: $5.78 |
| 23 |
736-3078 |
FLAT WASHER 344X1.00 Price: $3.95 |
| 24 |
738-04502 |
SHOULDER SCREW 1/4-20 x .50 Price: $3.75 |
| 25 |
738-05099 |
SHOULDER SPACER Price: $6.47 |
| 26 |
738-05272 |
DOUBLE SHOULDER SPACER .750 X .135 Price: $6.24 |
| 28 |
747-06506 |
ROD HOOK Price: $5.52 |
| 29 |
747-06583 |
DECK BRAKE ROD Price: $12.76 |
| 30 |
747-06626 |
ENGINE PULLEY BELT KEEPER ROD Price: $7.30 |
| 31 |
748-05029A |
SHOULDER SPACER Price: $4.19 |
| 32 |
750-06031 |
SPACER Price: $4.69 |
| 33 |
954-05106A |
V-BELT A SEC x 60.0 Price: $41.58 |
| 34 |
756-05034A |
IDLER PULLEY 4.50" DIA Price: $40.14 |
| 35 |
783-08389 |
IDLER PULLEY CAP Price: $5.23 |
