| Ref | Part Number | Description |
|---|
| 1 |
115-8047-01 |
NO. 3 LIFT ARM ASM This part replaces 92-9291. Price: $1,059.77 |
| 1 |
539110578 |
HANDLE W/ DECALS Price: $279.99 |
| 2 |
539109809 |
BRACE Price: $8.99 |
| 2 |
68-6480 |
BUSHING-FLANGE Price: $3.19 |
| 3 |
325-17 |
SCREW-HH Price: $2.90 |
| 3 |
539112289 |
DRIVE LEVER LT Price: $59.99 |
| 4 |
323-7 |
SCREW-HH Price: $0.65 |
| 4 |
539112291 |
DRIVE LEVER RT Price: $54.99 |
| 5 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 5 |
539109816 |
TRACKING PLATE Price: $29.99 |
| 6 |
52-6180 |
SPACER Price: $1.65 |
| 6 |
539109822 |
BAIL Price: $18.99 |
| 7 |
539102998 |
WASHER, FRICTION Price: $4.99 |
| 7 |
60-3250 |
WASHER Price: $5.21 |
| 8 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 8 |
539100147 |
KNOB Price: $8.99 |
| 9 |
3256-56 |
WASHER-FLAT Price: $1.15 |
| 9 |
539109817 |
NEUTRAL ARM Price: $5.99 |
| 10 |
539109614 |
FRICTION PLATE Price: $4.99 |
| 10 |
92-9246-03 |
A-FRAME This part replaces 92-9246. Price: $525.35 |
| 11 |
325-7 |
SCREW-HH Price: $1.53 |
| 11 |
539109612 |
ROLLER Price: $3.77 |
| 12 |
115-8046-01 |
NO. 2 LIFT ARM ASM This part replaces 92-9290. Price: $933.22 |
| 12 |
539111115 |
DECAL CROWN H 2-1/4 BLUE Price: $2.99 |
| 13 |
539109820 |
GROUND SPEED LEVER Price: $27.99 |
| 14 |
539109821 |
CROSS SHAFT Price: $12.99 |
| 14 |
60-1280 |
PIN Price: $3.53 |
| 15 |
539100032 |
BUSHING, FLANGED NYLON Price: $5.99 |
| 15 |
58-4380 |
PIN Price: $25.11 |
| 16 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 16 |
539110552 |
FLANGE BUSHING Price: $5.99 |
| 17 |
539109828 |
RIGHT OP Price: $20.99 |
| 18 |
539109826 |
LEFT OP Price: $20.99 |
| 19 |
539109823 |
DECAL, CONSOLE Price: $26.09 |
| 20 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 20 |
539109954 |
CHOKE CONTROL This part replaces 539130208. Price: $37.99 |
| 21 |
597524002 |
THROTTLE This part replaces 539102732. Price: $37.99 |
| 22 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 539101768. Price: $24.99 |
| 23 |
539110862 |
DNO HOUR METER Price: $42.99 |
| 24 |
539911853 |
KEY SWITCH, COMPLETE Price: $19.99 |
| 25 |
237-42 |
O-RING Price: $2.78 |
| 25 |
539103003 |
ADJUSTMENT KNOB Price: $4.99 |
| 26 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 26 |
539101224 |
SPRING Price: $19.99 |
| 27 |
237-22 |
O-RING Price: $2.43 |
| 27 |
539977250 |
SPRING Price: $3.99 |
| 28 |
539919098 |
SWITCH Price: $6.99 |
| 29 |
539102678 |
TAPPED PLATE Price: $12.99 |
| 30 |
596039001 |
Screws This part replaces 539976952. Price: $2.99 |
| 31 |
115-8011 |
CYLINDER-HYD This part replaces 84-6210. Price: $784.12 |
| 31 |
539105842 |
GRIP Price: $4.99 |
| 32 |
539102827 |
SPACER Price: $4.99 |
| 32 |
61-3610 |
WARNING DECAL Price: $16.67 |
| 33 |
539109615 |
SHORT LINKAGE Price: $19.99 |
| 34 |
325-34 |
SCREW-HH Price: $2.37 |
| 34 |
539110598 |
LINKAGE, LOWER Price: $54.99 |
| 35 |
539109149 |
TURNBUCKLE, 3/8 Price: $39.99 |
| 36 |
539101781 |
MODULE Price: $54.99 |
| 37 |
539106599 |
DECAL, ETS Price: $3.11 |
| 38 |
539110509 |
SPRING, SWITCH Price: $2.99 |
| 39 |
539102590 |
BALL JOINT, RIGHT HANDED Price: $19.99 |
| 40 |
597338501 |
Washers This part replaces 539990598. Price: $12.99 |
| 41 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 42 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 43 |
596238701 |
Washers This part replaces 539990118. Price: $3.99 |
| 44 |
596582801 |
Screws This part replaces 539990411. Price: $2.99 |
| 45 |
596582501 |
Bolts This part replaces 539990072. Price: $2.99 |
| 46 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
| 47 |
539990627 |
HCS 5/16C X 1 1/4 This part replaces 539100469. Price: $3.99 |
| 48 |
596582201 |
Bolts This part replaces 539976935. Price: $2.99 |
| 49 |
539976941 |
HCS 3/8C X 1 1/4 GR5 Price: $3.99 |
| 50 |
596040801 |
Hardware This part replaces 539976977. Price: $2.99 |
| 51 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 52 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 53 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 54 |
596040901 |
Hardware This part replaces 539990223. Price: $2.99 |
| 55 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 56 |
539990155 |
NUT 3/8F Price: $2.99 |
| 57 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 58 |
596671501 |
Washers This part replaces 539101949. Price: $2.99 |
| 59 |
539110864 |
DECAL, DUAL HEIGHT Price: $3.29 |
| 60 |
539132133 |
BOOT Price: $3.99 |
