| Ref | Part Number | Description |
|---|
| 1 |
531151701 |
SERVICE KIT TUBE TUBE.HANDLE.B This part replaces 532428610. Price: $14.99 |
| 1 |
95-7522 |
AXLE Price: $377.20 |
| 2 |
583765001 |
APPLIQUE BAGGER This part replaces 532447572. Price: $34.99 |
| 2 |
99-7564 |
SEAL-OIL Price: $25.36 |
| 3 |
95-7544 |
CLIP Price: $4.04 |
| 4 |
95-7523 |
SPACER Price: $26.89 |
| 5 |
583570401 |
TCRD.II.UPR.PIVOT TUBE.WLDMT This part replaces 532443762. Price: $109.99 |
| 5 |
99-7555 |
SHIM 0.3 Price: $3.29 |
| 5 |
99-7556 |
SHIM 0.2 Price: $3.29 |
| 5 |
99-7557 |
SHIM 0.5 Price: $3.37 |
| 6 |
95-7524 |
GEAR-BEVEL, 29 TOOTH Price: $222.95 |
| 7 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873900400. Price: $3.99 |
| 7 |
99-7534 |
BEARING-BALL Price: $65.44 |
| 8 |
583825901 |
BAGGER.TOP This part replaces 532447575. Price: $169.99 |
| 8 |
95-7521 |
COVER-AXLE Price: $107.87 |
| 9 |
106-1071 |
O-RING This part replaces 99-7538. Price: $18.43 |
| 10 |
583825801 |
BAGGER.FRAME.LOW.UTUBE.TEX.CRD This part replaces 532443755. Price: $29.99 |
| 10 |
93-7775 |
BEARING-BALL This part replaces 99-7561. Price: $127.75 |
| 11 |
99-7539 |
CLIP Price: $11.07 |
| 12 |
104-2374 |
BOLT This part replaces 99-7596. Price: $6.33 |
| 19 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 21 |
581337103 |
BAGGER.ASM.FABRIC.CRD.GII.HUSQ This part replaces 532445943. Price: $109.99 |
| 25 |
583580301 |
LATCH.BAG.CRD.GEN2 This part replaces 532445528. Price: $5.99 |
| 26 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE This part replaces 817490412. Price: $3.99 |
| 27 |
583580401 |
RUBBER.GROMMET.DUMP.TUBE.CRDII This part replaces 532445529. Price: $4.99 |
| 28 |
532165787 |
GRIP.HANDLE.BLACK Price: $5.99 |
| 42 |
583548101 |
CHRISTMAS.TREE.CLIP This part replaces 532440428. Price: $2.99 |
| 43 |
532126875 |
RIVET,DRILLED Price: $2.99 |
| 44 |
532199687 |
SCREW Price: $2.99 |
| 45 |
583570301 |
TCRD.-GEN2.UPPR.U.FRAME.WLDMT This part replaces 532443754. Price: $99.99 |
| 46 |
583580501 |
LH.BGGR.CRNER.CLOSE-OUT.TEXCRD This part replaces 532445541. Price: $7.99 |
| 47 |
583573001 |
LH.BAG.CRNER.CLOSE-OUT.TEXCRD This part replaces 532444079. Price: $6.99 |
| 48 |
583573101 |
TOP.BGGR.SIDE.CLOSE-OUT.TCRDII This part replaces 532444080. Price: $7.99 |
| 49 |
532171873 |
BOLT, SHOULDER 5/16-18 Price: $4.99 |
| 50 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 51 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 Price: $3.99 |
| 52 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 53 |
583573601 |
BRACKET.DUMP.HANDLE.TEX.CRD.G2 This part replaces 532444195. Price: $8.99 |
| 54 |
583827701 |
BAGGER TOP.FRONT.HANDLE This part replaces 532447218. Price: $12.99 |
| 55 |
596030801 |
Bolts This part replaces 872140512. Price: $3.99 |
| 56 |
532420306 |
PIN.CLEVIS.183 Price: $7.99 |
| 57 |
583254901 |
SCREW.1/4-20X.50-0T30 This part replaces 532199855. Price: $2.99 |
| 58 |
532085179 |
RETAINER CLIP PM Price: $3.99 |
| 59 |
583826601 |
BAGGER SPRD.TUBE.TEX.CRD.GEN2 This part replaces 532444763. Price: $19.99 |
| 60 |
532444105 |
Price: Call Us |
| 61 |
532444106 |
Price: Call Us |
| 62 |
532444542 |
Price: Call Us |
| 63 |
532444110 |
Price: Call Us |
| 64 |
532430422 |
Price: Call Us |
| 65 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 66 |
532446723 |
Price: Call Us |
| 67 |
872110518 |
Price: Call Us |
| 69 |
583392101 |
SCREW,#8.FLAT.HEAD.DRILL.TIP This part replaces 532421801. Price: $3.99 |
| 70 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
