| Ref | Part Number | Description |
|---|
| 1 |
117-0655-03 |
BRACKET-PUMP Price: $298.43 |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S Price: $39.99 |
| 3 |
145-3382 |
PUMP ASM This part replaces 132-7768. Price: $5,506.64 |
| 6 |
139-3093 |
AGITATION HOSE ASM This part replaces 132-4309. Price: $414.66 |
| 7 |
110-5331 |
SPRING-COMPRESSION Price: $22.18 |
| 8 |
117-8040-03 |
PLATE-MOUNT, MOTOR Price: $29.58 |
| 9 |
117-8045 |
COUPLER Price: $61.81 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 11 |
100-8635 |
FORK Price: $4.91 |
| 12 |
586478501 |
ENGINE.PULLEY This part replaces 532405471. Price: $27.99 |
| 13 |
100-6116 |
SCREW-HHF Price: $6.41 |
| 14 |
110-5057 |
CAPSCREW-HHF Price: $2.71 |
| 15 |
108-3745 |
NUT-HHF, WHIZ Price: $1.15 |
| 15 |
581289901 |
FUEL.TANK.ASM.NON-EPA This part replaces 532407545. Price: $44.99 |
| 16 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 17 |
3241-7 |
SCREW-SQH Price: $3.39 |
| 18 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532430220. Price: $22.99 |
| 19 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 20 |
532176636 |
CONTROL.TH/CK.C.BLACK This part replaces 532183897. Price: $27.99 |
| 21 |
120-0628-03 |
GUARD-SHAFT, PUMP Price: $22.59 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
117-0706 |
HYD MOTOR ASM Price: $793.55 |
| 24 |
106-1990 |
KEY-WOODRUFF Price: $3.81 |
| 27 |
322-14 |
SCREW-HH Price: $1.01 |
| 28 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 29 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 32 |
136-0376-03 |
BRACKET-VALVE, AGITATION Price: $33.11 |
| 33 |
107-3073 |
U-BOLT Price: $14.49 |
| 34 |
33113-012 |
SCREW-HH Price: $0.71 |
| 35 |
136-2286-03 |
MOUNT-PLATE, SUPPORT Price: $15.47 |
| 36 |
132-4302 |
MOUNT-VALVE Price: $38.41 |
| 37 |
131-0249 |
ON/OFF 2-WAY VALVE KIT Price: $220.85 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 38 |
131-0264 |
AGITATION THROTTLING HANDLE KIT Price: $28.04 |
| 39 |
132-4310 |
AGIATION SUPPLY HOSE ASM Price: $133.74 |
| 40 |
130-8202 |
TRANSDUCER-PRESSURE Price: $382.14 |
| 41 |
127-9829 |
CLAMP/GASKET KIT Price: $40.32 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
127-1185 |
FITTING-CAP, PORT Price: $22.48 |
| 44 |
138-6262 |
SERVICE KIT - FLOW METER ASM This part replaces 106-1038. Price: $1,138.30 |
| 45 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 83 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 86 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 94 |
583955301 |
TUBE.EXHAUST.KOHLER.COURAGE This part replaces 532188654. Price: $27.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 122 |
532421922 |
EXTENSION DRAIN OIL Price: $24.99 |
