| Ref | Part Number | Description |
|---|
| 1 |
603-0688A |
HYDRO CONTROL ARM Not Available Price: |
| 1 |
603000264 |
FITTING, 1/4-28 THRD FRM GREAS Price: $3.99 |
| 1 |
98-9579 |
BAND-PIPE Price: $5.22 |
| 2 |
603-0712A |
TRANSMISSION BRACKET (RH) Not Available Price: |
| 2 |
603000895 |
SHOCK, COIL OVER, REAR HD Price: $499.99 |
| 2 |
98-9578 |
PIPE-RETURN, WATER Price: $11.28 |
| 3 |
603-0713A-0637 |
MOUNTING BRACKET (LH) Not Available This part replaces 603-0713A. Price: |
| 3 |
603000941 |
WELDMENT, RECEIVER, REAR Price: $379.99 |
| 3 |
98-9713 |
WATER FLANGE ASM Price: $199.09 |
| 4 |
603001292 |
BOLT, FLG, M12X1.75X70 Price: $5.99 |
| 4 |
919-3059 |
TRANSMISSION HOUSING COVER Not Available This part replaces 619-3059. Price: |
| 4 |
98-9580 |
PIPE-RETURN, WATER Price: $4.01 |
| 5 |
603001310 |
WASHER, STRIP, SWINGARM Price: $9.99 |
| 5 |
703-3577 |
FEEDBACK PLATE Not Available Price: |
| 5 |
98-9719 |
THERMOSWITCH Price: $98.79 |
| 6 |
603001311 |
BOLT FLG, M12X1.75X50 Price: $5.99 |
| 6 |
703-3715A |
OIL BAFFLE Not Available This part replaces 703-3715. Price: |
| 7 |
603001312 |
NUT FLG, M12X1.75, NYLON GR 10 Price: $5.99 |
| 7 |
703-05041 |
NEUTRAL ARM (RH) Not Available Price: |
| 8 |
703-05042 |
Arm, Neutral LH Price: $38.12 |
| 9 |
603000944 |
BUSHING, PIVOT, URETHANE Price: $11.99 |
| 9 |
710-0294 |
HEX CAP SCREW 1/4-20 x .375 GR5 Not Available Price: |
| 9 |
98-7777 |
BOLT Price: $1.56 |
| 10 |
603001148 |
BUSHING, TEFLON Price: $19.99 |
| 10 |
710-0591 |
Screw, Hex Cap Lock, 3.8-24 x 1.0 GR5 Price: $3.94 |
| 10 |
98-9471 |
COVER-THERMOSTAT Price: $34.62 |
| 11 |
105-3748 |
GASKET-THERMOSTAT This part replaces 98-7776. Price: $4.31 |
| 11 |
603004117 |
SWINGARM, REAR, AWD Price: $279.99 |
| 11 |
710-0833 |
Screw, Hex Cap, 5/16-18 x 5.25 GR5 Price: $8.31 |
| 12 |
710-1633 |
Screw, Plug, M14 x 1.5 x .827 Price: $13.06 |
| 12 |
98-7778 |
THERMOSTAT ASM Price: $61.89 |
| 13 |
603001597 |
PIN, SWINGARM, WELDMENT Price: $119.99 |
| 13 |
710-1853 |
SCREW 5/16-18 x .625 GR2 Not Available Price: |
| 13 |
98-9638 |
GASKET-FLANGE, WATER Price: $3.74 |
| 14 |
603001599 |
WASHER, M12 HARD REGULAR Price: $2.99 |
| 14 |
710-3005 |
Screw, Hex Cap, 3/8-16 x 1.25 GR5 Price: $3.61 |
| 14 |
98-7692 |
BOLT Price: $0.92 |
| 15 |
603001602 |
NUT Price: $2.99 |
| 15 |
710-3013 |
Screw, Hex Cap, 1/4-20 x .5 GR5 Price: $4.02 |
| 15 |
98-9356 |
BOLT Price: $2.06 |
| 16 |
603001606 |
BRKT, LINE, HYD, SHK MNT, DRV Price: $9.99 |
| 16 |
710-3032 |
Screw, Hex Cap, 1/2-13 x 1.25 GR5 Price: $5.66 |
| 17 |
603001607 |
BRKT, LINE, HYD, SHK MNT, PASS Price: $9.99 |
| 17 |
710-3120 |
Screw, Hex Cap Lock, 3/8-16 x 1.5 GR5 Price: $3.64 |
| 18 |
710-3262 |
SCREW 3/8-16 x .750 Not Available Price: |
| 19 |
711-1355 |
ROCK SHAFT Not Available Price: |
| 20 |
912-0431 |
Nut, Hex Flange Lock, 3/8-16 This part replaces 7120431. Price: $4.29 |
| 21 |
716-0111 |
Ring, Retaining Price: $5.78 |
| 22 |
716-0195 |
RETAINING RING Not Available Price: |
| 23 |
717-3507 |
HYDROSTATIC PUMP Not Available Price: |
| 24 |
718-3131 |
AUXILIARY PUMP Not Available Price: |
| 25 |
719-3166 |
UPPER HITCHARM (RH) Not Available Price: |
| 26 |
719-3167 |
UPPER HITCHARM (LH) Not Available Price: |
| 27 |
721-0501 |
O-RING 2.987 x .103 Not Available Price: |
| 28 |
721-0510 |
OIL SEAL 1.5X2.0X.250 Not Available Price: |
| 30 |
923-3014 |
Filter, Oil This part replaces 723-3014. Price: $18.90 |
| 31 |
723-3021 |
Breather, Transmission Price: $20.30 |
| 32 |
725-3272 |
Sensor, RPM Price: Call Us |
| 33 |
727-3012 |
Fitting, 90 degree Price: $23.35 |
| 34 |
727-3176 |
AUX PUMP SUCTION TUBE Not Available Price: |
| 35 |
727-3181 |
HYDRO SUCTION TUBE Not Available Price: |
| 36 |
731-04018 |
GROMMET Not Available Price: |
| 37 |
732-1162 |
Spring, Extension Price: $7.61 |
| 38 |
736-3052 |
Washer, Flat, .406 x 1.0 x .105 Price: $4.02 |
| 39 |
737-0146 |
Fitting, Grease Price: $4.46 |
| 40 |
737-0349 |
FITTING PLUG Not Available Price: |
| 41 |
737-3105 |
FILTER NIPPL FITTING Not Available Price: |
| 44 |
737-3112 |
HYDRO FITTING Not Available Price: |
| 45 |
737-3113 |
HYDRO FITTING Not Available Price: |
| 46 |
938-0108 |
Shoulder Bolt .498" Dia. This part replaces 738-0108. Price: $6.24 |
| 47 |
738-0430 |
Screw, Shoulder, .50 Dia x .685 Price: $10.55 |
| 48 |
738-04001 |
SHOULDER SCREW Not Available Price: |
| 49 |
741-1110 |
SLEEVE BEARING Not Available Price: |
| 50 |
750-1208 |
SPACER .40X1.0X Not Available Price: |
| 51 |
750-1239 |
SPACER 1.52X2.25X Not Available Price: |
| 77462DX6US |
HYD/TRANS |
FLUID-VOC MULTI G 12/1QT This part replaces 737-3025. Price: $10.59 77462DX6US |
| 77462JX2US |
HYD/TRANS |
FLUID-VOC MULTI G 3X1GAL This part replaces 737-3062. Price: $63.59 77462JX2US |
| 77462PQ1US |
HYD/TRANS |
FLUID-VOC MULTI G 1X5GAL This part replaces 737-3035. Price: $264.99 77462PQ1US |
