| Ref | Part Number | Description |
|---|
| 1 |
133741 |
SUB= 150547 Price: Call Us |
| 1 |
139-2651 |
CYLINDER, HYD This part replaces 105-3821. Price: $671.34 |
| 2 |
165854 |
AXLE ASSY Price: Call Us |
| 2 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 3 |
169840 |
SPINDLE ASM Price: Call Us |
| 3 |
93-2255 |
HYD HOSE ASM Price: $52.69 |
| 4 |
169839 |
SPINDLE ASM Price: Call Us |
| 4 |
93-2256 |
HYD HOSE ASM Price: $52.48 |
| 5 |
140-5248 |
PIN-PIVOT RAM, WELDED This part replaces 10-6060. Price: $25.64 |
| 5 |
6266H |
WASHER .T Price: Call Us |
| 6 |
121748X |
WASHER Price: Call Us |
| 6 |
94-8198 |
PIN Price: $31.05 |
| 7 |
19272016 |
WASHER Price: Call Us |
| 7 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 8 |
12000029 |
RING Price: Call Us |
| 8 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 9 |
283-68 |
PIN-CLEVIS Price: $11.26 |
| 10 |
169832 |
LINK DRAG Price: Call Us |
| 11 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 11 |
99-4115 |
FRONT LIFT FRAME ASM Price: $384.07 |
| 12 |
33096-00 |
WASHER-FLAT Price: $1.76 |
| 13 |
105-3838 |
SPACER Price: $10.45 |
| 13 |
136518 |
SPACER BEARING Price: Call Us |
| 15 |
145212 |
NUT.HXFLG.LOCK. Price: Call Us |
| 15 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 16 |
99-4201 |
TUBE-SPACER Price: $10.91 |
| 17 |
156546 |
SHAFT ASM STEERIN Price: Call Us |
| 17 |
99-4258 |
RH LINK BRACKET ASM Price: $51.12 |
| 18 |
57079 |
THRUST WASHER Price: Call Us |
| 18 |
99-4260 |
LH LINK BRACKET ASM Price: $51.12 |
| 19 |
105-3809 |
SPRING-TORSION, RH Price: $14.89 |
| 19 |
160395 |
SUPPORT.SHAFT.STEER Price: Call Us |
| 20 |
105-3818 |
SPRING-TORSION, LH Price: $14.89 |
| 21 |
99-4213 |
RH LIFT ARM ASM Price: $303.22 |
| 22 |
165857 |
SCREW.HX.WSH.HD Price: Call Us |
| 22 |
99-4212 |
LH LIFT ARM ASM Price: $303.22 |
| 23 |
165851 |
SHAFT.ASM.PITMAN Price: Call Us |
| 23 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 24 |
93-2254 |
HYD HOSE ASM Price: $65.17 |
| 25 |
154406 |
BRKT-STEERING Price: Call Us |
| 26 |
325-6 |
SCREW-HH Price: $1.42 |
| 27 |
136874 |
GEAR SECTOR Price: Call Us |
| 27 |
3218-5 |
NUT-JAM Price: $0.27 |
| 28 |
93-2384 |
SPACER-CARRIER Price: $9.09 |
| 29 |
17060612 |
SCREW Price: Call Us |
| 31 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 32 |
170162 |
TIE ROD Price: Call Us |
| 33 |
19111216 |
WASHER M Price: Call Us |
| 34 |
10040500 |
LOCKWASHER Price: Call Us |
| 34 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 35 |
73810500 |
NUT.LOCK.5/16-24 Price: Call Us |
| 35 |
74-3730 |
SPACER-SPINDLE, REAR Price: $5.06 |
| 36 |
155099 |
BUSHING.STEERING Price: Call Us |
| 38 |
133742 |
ST WHL INSERT CAP Price: Call Us |
| 38 |
32144-69 |
SCREW-HWHTF Price: $1.58 |
| 39 |
19133812 |
WASHER Price: Call Us |
| 39 |
325-4 |
SCREW-HH Price: $0.95 |
| 40 |
325-14 |
SCREW-HH Price: $2.64 |
| 40 |
7810H |
GRIPCO NUT Price: Call Us |
| 41 |
100711L |
ADAPTER LT Price: Call Us |
| 41 |
3296-54 |
NUT-LOCK Price: $3.59 |
| 42 |
145054X428 |
BOOT.STEERING.DASH.P/L Price: Call Us |
| 42 |
3250-17 |
SCREW-PPH Price: $1.76 |
| 43 |
121749X |
WASHER Price: Call Us |
| 43 |
99-4111-01 |
PLATE-TRANSPORT, 1 AND 3 Price: $49.03 |
| 44 |
153720 |
EXT SHAFT STEERIN Price: Call Us |
| 44 |
99-4112-01 |
PLATE-TRANSPORT, 2 Price: $47.73 |
| 46 |
121232X |
CAP Price: Call Us |
| 47 |
6855M |
ZERK M Price: Call Us |
| 51 |
73800500 |
NUT Price: Call Us |
| 51 |
99-4225 |
PAD-WEAR Price: $10.18 |
| 54 |
74780520 |
BOLT Price: Call Us |
| 62 |
167902 |
KIT.STEER.ASM Price: Call Us |
| 63 |
74780616 |
BOLT Price: Call Us |
| 67 |
72140618 |
BOLT RDHD 3/8-16 Price: Call Us |
| 68 |
169827 |
BRACE AXLE Price: Call Us |
| 79 |
19132012 |
WASHER Price: Call Us |
| 80 |
74950612 |
BOLT.HX.NYLON3/8-16X3/ Price: Call Us |
| 82 |
169835 |
BRKT SUSP CHASSIS FRT Price: Call Us |
| 84 |
170016 |
BRACKET CABLE CLUTCH CHASSIS Price: Call Us |
