| Ref | Part Number | Description |
|---|
| 2 |
48030-17 |
CLAMP, CABLE - .38 DIA This part replaces 48030. Price: Call Us |
| 10 |
48019 |
SAFETY SWITCH - BLADE CLUTCH Price: Call Us |
| 11 |
48030-17 |
CLAMP, CABLE - .38 DIA This part replaces 48030. Price: Call Us |
| 14 |
48104-01 |
BEARING, PILLOW BLOCK This part replaces 48104. Price: Call Us |
| 16 |
04041-08 |
THRUST WASHER Price: Call Us |
| 17 |
04050-02 |
RETAINING RING Price: Call Us |
| 18 |
48010-01 |
DRIVE WHEEL ASSY. WITH BRAKE ADAPTER Price: Call Us |
| 18A |
481893 |
Tire Only This part replaces 48004-02. Price: Call Us |
| 18B |
481890 |
Rim Assy This part replaces 48010-03. Price: Call Us |
| 19 |
48100-05 |
BRONZE BEARING Price: Call Us |
| 20 |
46144 |
IDLER ARM WILD.(INCL. 14 & 22) This part replaces 45018. Price: Call Us |
| 21 |
48100-05 |
BRONZE BEARING Price: Call Us |
| 22 |
48114-04 |
Fitting, Grease This part replaces 48114-01. Price: Call Us |
| 23 |
45014 |
BELT GUIDE - IDLER PULLEY Price: Call Us |
| 24 |
48047 |
FOOT CLUTCH CABLE ASSY. Price: Call Us |
| 26 |
04001-29 |
BOLT, HEX HD., 7/16-20 X 1-1/2 Price: Call Us |
| 27 |
43048 |
SPACER CRANKSHAFT Price: Call Us |
| 28 |
482744 |
Pulley, 5.75 OD Taper Bore This part replaces 48070. Price: Call Us |
| 29 |
04050-06 |
RETAINING RING Price: Call Us |
| 30 |
48102 |
BEARING, IDLER PULLEY Price: Call Us |
| 31 |
48065 |
PULLEY, IDLER Price: Call Us |
| 32 |
04050-06 |
RETAINING RING Price: Call Us |
| 33 |
43044 |
SLEEVE Price: Call Us |
| 36 |
48063 |
PULLEY, ENGINE Price: Call Us |
| 37 |
45015 |
IDLER PIVOT WELDMENT Price: Call Us |
| 39 |
04062-01 |
HAIRPIN Price: Call Us |
| 40 |
04029-03 |
Knob This part replaces 04022-04. Price: Call Us |
| 41 |
42060 |
SPRING MOUNTING BRACKET Price: Call Us |
| 42 |
48051 |
SPRING, BELT CLUTCH Price: Call Us |
| 45 |
43031 |
BELT CLUTCH ROD Price: Call Us |
| 46 |
43043 |
SLEEVE Price: Call Us |
| 47 |
04062-01 |
HAIRPIN Price: Call Us |
| 48 |
48064 |
PULLEY, TRANSAXLE Price: Call Us |
| 48A |
04063-07 |
WOODRUFF KEY #9 Price: Call Us |
| 50 |
04063-04 |
KEY, 3/16 X 3/16 X 3-1/2 Price: Call Us |
| 51 |
48003 |
TRANSAXLE Price: Call Us |
| 52 |
04041-09 |
THRUST WASHER Price: Call Us |
| 54 |
43049 |
FOOT CABLE SLEEVE Price: Call Us |
| 58 |
42061 |
SHIFT LEVER Price: Call Us |
| 59 |
48122-01 |
FIBER WASHER - .010 Price: Call Us |
| 59 |
48122-02 |
FIBER WASHER - .020 Price: Call Us |
| 60 |
48021 |
NEUTRAL SAFETY SWITCH Price: Call Us |
| 61 |
43029 |
SHIFT CONNECTOR ROD Price: Call Us |
| 62 |
48118 |
BALL JOINT Price: Call Us |
| 64 |
42052 |
BATTERY SUPPORT Price: Call Us |
| 65 |
42051 |
BATTERY SHELF Price: Call Us |
| 66 |
48016 |
STARTER SOLENOID Price: Call Us |
| 67 |
45027-01 |
HITCH BRACKET WELDMENT - RH Price: Call Us |
| 68 |
42042 |
FUEL TANK BRACKET, FRONT Price: Call Us |
| 69 |
42044 |
FUEL TANK BRACKET, REAR Price: Call Us |
| 70 |
04003-39 |
Bolt, Carriage 1/4-20 x 6" This part replaces 04003-01. Price: Call Us |
| 71 |
04029-01 |
Wing Nut, 1/4-20 x .75" This part replaces 04022-01. Price: Call Us |
| 72 |
42024 |
BATTERY COVER Price: Call Us |
| 73 |
48015 |
BATTERY Price: Call Us |
| 74 |
42055 |
BATTERY CLAMP Price: Call Us |
| 75 |
42048 |
FUEL TANK STRAP Price: Call Us |
| 76 |
48054 |
FUEL TANK, 3 GALLON Price: Call Us |
| 77 |
48055 |
FUEL TANK CAP Price: Call Us |
| 78 |
48056 |
FUEL SHUT-OFF VALVE Price: Call Us |
| 80 |
48059-01 |
Clamp, Fuel Hose 1/4" Hose ID This part replaces 48059. Price: Call Us |
| 81 |
48057 |
FUEL FILTER Price: Call Us |
| 82 |
48059-01 |
Clamp, Fuel Hose 1/4" Hose ID This part replaces 48059. Price: Call Us |
| 84 |
48059-01 |
Clamp, Fuel Hose 1/4" Hose ID This part replaces 48059. Price: Call Us |
| 86 |
42075 |
SPACER, TRANSAXLE MOUNTING Price: Call Us |
| 87 |
42076 |
REAR BRACE, TRANSAXLE Price: Call Us |
| 88 |
43039 |
SPACER, IDLER PULLEY Price: Call Us |
| 89 |
48052 |
SPRING, BRAKE RETURN Price: Call Us |
| 90 |
48099 |
BATTERY COVER INSULATION Price: Call Us |
| 92 |
45057 |
SAFETY REVERSE WELDMENT Price: Call Us |
| 93 |
43066 |
SAFETY REVERSE ROD Price: Call Us |
