| Ref | Part Number | Description |
|---|
| 1 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 2 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 2 |
532069180 |
SUB= 69180 Price: $2.69 |
| 3 |
106-1053 |
CLUTCH KIT This part replaces 100-2559. Price: $778.11 |
| 3 |
532127533 |
SUB= 127533 Price: $11.99 |
| 4 |
532171061 |
COVER ASM Price: $79.99 |
| 4 |
68-3220 |
KEY-STOCK Price: $4.60 |
| 5 |
532139569 |
SUB= 139569 Price: $70.99 |
| 5 |
86-1740 |
SPACER Price: $19.95 |
| 6 |
818021008 |
SCREW, SPECIAL #10-14X1/2 Price: $3.99 |
| 6 |
84-0780-01 |
PULLEY-SPINDLE Price: $290.34 |
| 7 |
253-154 |
SEAL-OIL Price: $5.48 |
| 7 |
532140572 |
SUB= 140572 Price: $4.99 |
| 8 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 8 |
874981024 |
SCREW.PAN.HEAD This part replaces 532087175. Price: $5.99 |
| 9 |
69-1530 |
HOUSING-SPINDLE Price: $227.62 |
| 9 |
819061216 |
WASHER 3/16X3/4X16 GA Price: $2.69 |
| 10 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 10 |
532007206 |
SUB= 7206J Price: $3.99 |
| 11 |
539108086 |
NUT.#10-24 ACORN.ZD This part replaces 532060867. Price: $1.99 |
| 11 |
95-4388 |
SPINDLE SHAFT ASM-CLUTCH This part replaces 86-2360. Price: $279.56 |
| 12 |
138-6416 |
SPACER-SPINDLE, SHAFT This part replaces 69-6950. Price: $18.44 |
| 12 |
810071000 |
WASHER, LOCK Price: $2.99 |
| 13 |
532109808 |
SUB= 109808X Price: $2.69 |
| 13 |
86-0010-03 |
BLADE-19" Price: $32.86 |
| 14 |
532002029 |
NUT.WELD.#10-24 This part replaces 532125004. Price: $2.69 |
| 14 |
72-9361 |
CUP-SCALP, ANTI Price: $39.78 |
| 15 |
874930620 |
Bolt, Hex Head 3/8-16 x 1-1/4 Price: $3.99 |
| 15 |
94-8013 |
WASHER-THRUST Price: $2.99 |
| 16 |
819131612 |
Washer 13/32 x 1 x 12 Ga. This part replaces 819131616. Price: $3.99 |
| 16 |
92-5816 |
BOLT-BLADE Price: $4.93 |
| 17 |
86-1480 |
WASHER Price: $4.82 |
| 17 |
873770600 |
LOCKNUT 3/8-16 NLA This part replaces 873750600. Price: Call Us |
| 18 |
532131970 |
CHUTE, LOWER Price: $72.99 |
| 19 |
532135651 |
SUB= 135651 Price: $3.99 |
| 20 |
871081010 |
Screw #10-24 x 5/8 This part replaces 871161010. Price: $3.49 |
| 21 |
532132796 |
SUB= 132796 Price: $2.99 |
| 22 |
532133235 |
SUB= 133235 Price: $3.99 |
| 23 |
532132983 |
SUB= 132983 Price: $2.99 |
| 24 |
532180925 |
POST.SUPPORT.BAGGER.2BIN This part replaces 532126813. Price: $28.99 |
| 25 |
532063124 |
SUB= 73690500 Price: $0.99 |
| 26 |
532085902 |
RETAINER SPRING This part replaces 532124670. Price: $1.99 |
| 27 |
539976934 |
HCS.5/16-18X3/4 This part replaces 874760512. Price: $1.99 |
| 28 |
532170053 |
BRACKET, MOUNTING Price: $9.99 |
| 29 |
532170165 |
BOLT SHOULDER Price: $2.99 |
| 30 |
532131137 |
SUB= 131137 Price: $6.99 |
| 31 |
532174083 |
Plug, Tubing End This part replaces 532134496. Price: $3.99 |
| 32 |
532126919 |
SUB= 126919X Price: $59.99 |
| 33 |
532192786 |
Pin, Hinge This part replaces 532128600. Price: $7.99 |
| 34 |
532127534 |
SUB= 127534 Price: $8.99 |
| 35 |
532183286 |
Container, Top This part replaces 532129585. Price: $17.99 |
| 36 |
532129586 |
SUB= 129586 Price: $62.99 |
| 38 |
532130895 |
SUB= 130895 Price: $3.99 |
| 39 |
532155042 |
STRIP.REINFORCEMENT Price: $11.99 |
