| Ref | Part Number | Description |
|---|
| 1 |
532439822 |
SEAT.TH150.MS498.GRY.HUSQ.TEX Price: $159.99 |
| 1 |
703-1869 |
FRAME ASSEMBLY Not Available Price: |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $11.99 |
| 2 |
703-1726 |
LATCH ASSEMBLY Not Available Price: |
| 3 |
932-3002 |
Extension Spring, .51 x 2.12 This part replaces 732-3002. Price: $7.93 |
| 4 |
738-3001 |
BOLT-SHOUL Not Available Price: |
| 5 |
759-3528 |
FRAME COVER W/DECAL Not Available Price: |
| 6 |
703-0828 |
Bracket, Height Indicator Price: Call Us |
| 7 |
589483501 |
SPRING.COMPRESS.SEAT.TAPERED Price: $7.99 |
| 7 |
726-3008 |
Clip, Cable Price: $4.26 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 8 |
723-3042 |
SNAP BUSHING 7/8 Not Available Price: |
| 9 |
710-3182 |
SCREW 1/2-20X1.0 GR5 Not Available Price: |
| 10 |
596768801 |
KIT.PLATE.SEAT This part replaces 587232002. Price: $49.99 |
| 10 |
703-1943 |
PLATE ASSY, HITCH Not Available Price: |
| 11 |
703-0904-0498 |
DRAW BAR (CUB YELLOW) Not Available This part replaces 703-0904. Price: |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER Price: $2.99 |
| 37 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 40 |
595088102 |
Handles This part replaces 532197661. Price: $4.99 |
| 41 |
532198200 |
SPRING.LATCH.SEAT.TEX Price: $3.99 |
| 43 |
874760612 |
BOLT Price: $3.99 |
| 44 |
501051801 |
WASHER.WINGED.3/8ID.1.5OD Price: $3.99 |
| 46 |
588090401 |
BOLT.3/8-16X1;1.25OD.WSHR.SEMS Price: $5.99 |
