| Ref | Part Number | Description |
|---|
| 1 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 2 |
139-2650 |
CYLINDER, HYD This part replaces 94-6357. Price: $608.23 |
| 2 |
532186211 |
KEY.SQUARE.187X2.500 Price: $3.99 |
| 3 |
HY4486 |
NUT UNF 1/2"NYLOC EXT THIN5/16 This part replaces 283-8. Price: $1.36 |
| 4 |
93-2403 |
DISCONTINUED Price: Call Us |
| 5 |
92-8995 |
BUSHING Price: $8.90 |
| 6 |
94-9610 |
BUSHING-FLANGE This part replaces 93-2361. Price: $2.37 |
| 7 |
531170101 |
SERVICE.KIT HUB ASM HUB.ASM.WH This part replaces 532199844. Price: $49.99 |
| 7 |
93-2350 |
DISCONTINUED Price: Call Us |
| 8 |
3256-7 |
WASHER-FLAT Price: $0.75 |
| 9 |
596218701 |
Bolts This part replaces 532140080. Price: $2.99 |
| 9 |
94-3483-01 |
DISCONTINUED This part replaces 94-3483. Price: Call Us |
| 10 |
93-2368 |
BUSHING-FLANGE Price: $2.10 |
| 11 |
104-2091 |
ROLLER-ANTI SCALP This part replaces 93-2362. Price: $45.52 |
| 12 |
104-2078 |
SHAFT-ROLLER This part replaces 93-2363. Price: $73.88 |
| 13 |
3296-19 |
NUT-HEX Price: $0.65 |
| 14 |
3213-1 |
SCREW-HH Price: $1.42 |
| 15 |
104-7719 |
BALL JOINT ASM This part replaces 93-2133. Price: $137.95 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 16 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 17 |
532197296 |
SPRING.BRAKE.HG3000/3500 Price: $5.99 |
| 17 |
85-9720 |
FITTING-STR, ORIFICE Price: $119.77 |
| 18 |
32120-72 |
RING-SNAP Price: $2.09 |
| 19 |
63-2290 |
WASHER-THRUST Price: $2.27 |
| 20 |
93-2258 |
HYD HOSE ASM Price: $43.64 |
| 21 |
94-3452 |
PIN Price: $10.04 |
| 22 |
94-8199 |
TUBE-PIVOT This part replaces 94-1398. Price: $23.74 |
| 23 |
3296-53 |
NUT-LOCK, NI Price: $1.47 |
| 24 |
327-17 |
SCREW-HH Price: $8.50 |
| 25 |
3211-2 |
SCREW-HH Price: $2.17 |
| 26 |
532199679 |
SPRING.RETURN.CRUISE Price: $3.99 |
| 26 |
94-3477 |
HYD HOSE ASM Price: $65.92 |
| 27 |
325-6 |
SCREW-HH Price: $1.42 |
| 28 |
3218-5 |
NUT-JAM Price: $0.27 |
| 29 |
137-9706 |
DECAL-WARNING This part replaces 93-8064. Price: $4.48 |
| 29 |
532199467 |
ROD.BRAKE.0610.PEDAL.CONTROL Price: $37.99 |
| 30 |
237-21 |
O-RING Price: $0.70 |
| 31 |
237-78 |
O-RING Price: $3.85 |
| 32 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 33 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 33 |
812000011 |
Ring E Price: Call Us |
| 34 |
94-4548 |
BUMPER-RECESSED Price: $4.68 |
| 35 |
32144-44 |
SCREW-HWH, THREAD ROLL Price: $1.39 |
| 35 |
583864502 |
Rods This part replaces 532199591. Price: $6.99 |
| 36 |
93-2553 |
DISCONTINUED Price: Call Us |
| 37 |
532121749 |
WASHER Price: $2.99 |
| 37 |
93-2552 |
RETAINER - BASKET SEAL Price: $19.71 |
| 38 |
93-2551 |
SEAL-BASKET Price: $7.89 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 49 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 56 |
532140218 |
V-BELT. Price: $49.99 |
| 64 |
532197865 |
SHAFT.ASM.PEDAL.BRK.CNTR Price: $44.99 |
| 70 |
532439661 |
CONSOLE.ASM.RH.GT.FC.HUSQ This part replaces 532400530. Price: $79.99 |
| 74 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 80 |
532400507 |
BRKT.STRP.TRQ.LT.HYD.C Price: $12.99 |
| 96 |
595305701 |
Screws This part replaces 874760520. Price: $3.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 148 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 153 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT This part replaces 532195403. Price: $9.99 |
| 162 |
580457401 |
SPACER.TRANSAXLE.1" This part replaces 532195785. Price: $12.99 |
| 163 |
532199000 |
ROD.PEDAL.CONTROL.0510 Price: $27.99 |
| 166 |
532429164 |
NUT.PUSH.625 This part replaces 532197290. Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532196211. Price: $2.99 |
| 169 |
583613301 |
BOLT.HEX.FLNG.5/16-18X3.75 This part replaces 874490560. Price: $4.99 |
| 170 |
532194322 |
KEEPER.V-IDLER.CENTER. Price: $5.99 |
| 171 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 183 |
532400424 |
SPACER.SPLIT.800X.350 Price: $4.99 |
| 184 |
532196439 |
HANDLE.PARKING.BRAKE.H (BLK) This part replaces 532403118. Price: $9.99 |
| 185 |
596435101 |
Bolts This part replaces 872110620. Price: $2.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG This part replaces 532194323. Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 196 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 197 |
532199769 |
BRKT.ANIT-ROTATION.CLUTCH Price: $6.99 |
| 203 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 206 |
532448596 |
BRACKET.MOUNT.CRUISE.LATCH This part replaces 532197867. Price: $4.99 |
| 207 |
587031402 |
Latch This part replaces 532197868. Price: $5.99 |
| 208 |
596564101 |
Gears This part replaces 532197869. Price: $4.99 |
| 209 |
596869801 |
Rods This part replaces 532199592. Price: $5.99 |
| 210 |
532197860 |
ROCKER.ASM.PEDAL.CONTR Price: $44.99 |
| 211 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 213 |
532403119 |
KNOB.CONTROL.CRUSIE.HU Price: $8.99 |
| 214 |
532421263 |
PEDAL.FORWARD.PAD.TEX This part replaces 532401722. Price: $6.99 |
| 215 |
532401723 |
PEDAL.REVERSE.TEX.GT.4 Price: $12.99 |
| 216 |
532196131 |
BRACKET.PULLEY.IDLER.W/TEX Price: $6.99 |
| 218 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 219 |
532195780 |
SPACER.FENDER Price: $5.99 |
| 220 |
532198908 |
REFLECTOR.RH.TEX GT Price: $14.99 |
